- Page 1 (English version) ZM - RF1 RESERATOR FAN KIT for Higher Water Cooling Performance Please visit our website and watch the ZM-RF1 installation video for easy installation. Please read this manual thoroughly before installation. http://www.zalman.co.kr http://www.zalmanusa.com...
- Page 2 Precautions 1) This product cannot be used by itself and must be used with Zalman’s RESERATOR 1 or RESERATOR 1 Plus. 2) Do not place in dusty or humid conditions, under direct sunlight, or near a heat source such as a room heater.
- Page 3 2. Specifications 1) Duct Assembly - Dimensions : 163.5(L) X 163.5(W) X 190(H)mm - Materials : Poly Carbonate(Duct, Fan Support), ABS Polymer(Grill) - Weight : 334g 2) Fan - Dimensions : 140(L) X 140(W) X 25(H)mm - Bearing Type : 2-Ball Bearing - Rotation Speed : 750rpm 10% (Silent Mode) 1600rpm...
- Page 4 4. Installation 1) Duct Assembly Installation - While holding the Duct Assembly with both hands, align the Duct Assembly's Insert Holes with the Reserator's Round Fins, and mount the Duct Assembly over the Reserator. note 1) The 4 Round Fins must be inserted into the 4 Insert Holes simultaneously. note 2) If mounting cannot be done smoothly,try rotating the Duct Assembly 90 degrees at a time while mounting.
- Page 5 Zalman Noise Prevention System Stable performance and noiseless liquid cooling system can both be achieved with the use of Zalman’s noiseless power supply, noiseless case fan, Northbridge water block, and heat pipe hard disk cooler. Noiseless Power Supply Noiseless Case Fan Northbridge Water Block Heatpipe H.D.D Cooler...
