D-Link DCS-3410 Technical Specifications

D-Link DCS-3410 Technical Specifications

Fixed network camera
Hide thumbs Also See for DCS-3410:

Advertisement

Quick Links

®
Features
+ Day and Night Monitoring with Optional
Auto Iris Lens or IR Illuminator
+ 1/3" CCD Sensor
+ 0.3 Lux Sensitivity for Low-Light
Conditions
+ 4x Digital Zoom
4
+ Up to 30 Frames Per Second
+ Simultaneous Dual-Stream Support
+ Motion Detection Recording with Email
Alert
+ Built-in Samba Client
+ Built-In Microphone and Speaker Port
+ Digital I/O Support for Sensors and
Alarms
+ RS-485 for P/T Enclosure Connection
+ Built-in 802.3af (PoE)
3
D-ViewCam™ 2.0 Features
+ Manage up to 32 Cameras at once
+ Adjustable Image Size and Quality
+ Custom Recording Schedules
+ Upload a Floor Plan
+ Flip & Mirror Image
DCS-3410 Fixed Network Camera
Day & Night Camera with PoE Support
Low-Light Surveillance
The D-Link
DCS-3410 Fixed Network Camera is a
®
versatile monitoring solution for installations that require
the ability to record in low-light situations. The low lux
enables you to record anytime, day or night, with minimal
lighting. Along with the additional options available
including features such as simultaneous MPEG-4 &
MJPEG streaming, a BNC connector, digital I/O ports, PoE
support, and support for optional low light accessories, the
DCS-3410 provides the versatility needed for professional
surveillance applications.
Low-light Video Capture
The DCS-3410 features 0.3 Lux light sensitivity for low-light
monitoring, enabling you to capture video anytime, day or
night. Additionally, you can attach a CS mount standard
lens such as an auto-iris lens, IR LED lens, or a night vision
illuminator, to record video in environments with little or
no light. The DCS-3410 also comes with a 12V interface to
provide power for an optional LED illumination.
Multiple Streaming
The DCS-3410 supports simultaneous dual-streaming
of MPEG-4 and MJPEG to provide both high quality and
bandwidth efficient compression formats. MJPEG delivers
greater file integrity, making it ideal for detailed monitoring
situations. MPEG-4 video has smaller file sizes, making it
more useful for extended recording periods or for use in
low bandwidth networks.
Flexible Connectivity
The DCS-3410 has a BNC connector for video transmission
to a standard video security monitor or CCTV video server.
It also includes digital ports (2 input & 1 output) allowing
connectivity to external devices such as IR sensors,
switches, and alarm relays. The DCS-3410 also comes
with a RS-485 interface, providing connectivity to an
optional Pan/Tilt enclosure, which effectively adds pan/tilt
functionality to the DCS-3410. Additionally, a 12V interface
provides power for an optional LED illuminator.
3GPP Mobile Surveillance¹
Support for 3GPP Mobile Surveillance¹ allows you to view
a live video feed from your compatible Internet-ready
mobile phone with a 3GPP player installed. This extends
your monitoring capability without requiring the use of a
computer, allowing you to check your camera's video feed
while on-the-go.
Additional Features
The DCS-3410 comes with a built-in microphone and
audio port allowing 2-way audio communication² when an
external speaker is connected. The DCS-3410 also comes
with a built-in Samba client for NAS so there is no need
for a direct connection to a PC or any other hardware or
software to capture and transfer images. Equipped with
802.3af Power over Ethernet (PoE) support³, the DCS-3410
can receive both power and data over a single Ethernet
cable, enabling you to place this camera in locations
without a power outlet.
Convenient Camera Management
The included D-Link D-ViewCam™ 2.0 software enables
you to manage up to 32 network cameras, set e-mail
alert notifications, set recording schedules, and trigger
motion detection to record directly to your hard drive.
D-ViewCam 2.0 also allows you to upload a floor plan of
your business and create a realistic layout of where your
cameras are located, further simplifying the management
process.

Advertisement

loading

Summary of Contents for D-Link DCS-3410

  • Page 1 + Manage up to 32 Cameras at once The DCS-3410 comes with a built-in microphone and no light. The DCS-3410 also comes with a 12V interface to audio port allowing 2-way audio communication² when an + Adjustable Image Size and Quality provide power for an optional LED illumination.
  • Page 2: Technical Specifications

    DCS-3410 Fixed Network Camera Day & Night Camera with PoE Support Technical Specifications Camera General Specifications + Sensor: Color 1/3” CCD + 3A Control: AGC, AWB, AES + Minimum Illumination: 0.3 Lux @ F1.6 (typical); + Resolution: 470 TV Lines Lens mount supports optional...
  • Page 3: Minimum Requirements

    All references to speed are for comparison purposes only. Product specification, size and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. D-Link Systems, Inc. 17595 Mt. Herrmann Street, Fountain Valley, CA 92708 ©2008 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, D-Link logo, D-ViewCam™, and the SecuriCam logo are registered trademarks of D-Link...
