Yamaha FX WaveRunner 2007 Owner's/Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

2007 WaveRunner
FX
FX Cruiser
OWNER'S/OPERATOR'S MANUAL
U.S.A. Edition
LIT-18626-06-88
READ THIS MANUAL
CAREFULLY BEFORE OPERATION!
F1Y-F8199-11

Advertisement

Table of Contents
loading

Related Manuals for Yamaha FX WaveRunner 2007

Summary of Contents for Yamaha FX WaveRunner 2007

  • Page 1 2007 WaveRunner FX Cruiser OWNER’S/OPERATOR’S MANUAL U.S.A. Edition LIT-18626-06-88 READ THIS MANUAL CAREFULLY BEFORE OPERATION! F1Y-F8199-11...
  • Page 3 Important manual information EJU30180 To the owner/operator NOTE: A NOTE provides key information to make Thank you for choosing a Yamaha watercraft. procedures easier or clearer. This owner’s/operator’s manual contains in- formation you will need for proper operation, EJU30220 maintenance, and care. A thorough under-...

  • Page 4: Table Of Contents

    Engine serial number ......1 Bow eye ........... 36 Emission control information ..2 Stern eyes ........37 Approval label of emission control Yamaha Engine Management certificate ........2 System (YEMS) ......37 Manufactured date label ....2 Multifunction information center ..37 Star labels .........
  • Page 5 Table of contents Post-operation care ...... 71 Consumer information ....96 Transporting ......... 72 Limited warranty ......96 YAMAHA EXTENDED SERVICE Maintenance and care..... 73 (Y.E.S.) ........98 Storage ......... 73 Flushing the cooling system .... 73 Lubrication ........74 Fuel system ........

  • Page 6: General And Important Labels

    Hull Identification Number (HIN), and engine serial number in the spaces provided for assistance when ordering spare parts from a Yamaha dealer. Also record and keep these ID numbers in a separate place in case your watercraft is stolen.

  • Page 7: Emission Control Information

    General and important labels EJU30350 EJU30430 Emission control information Manufactured date label This label is attached to the top of the cylinder This engine conforms to 2006 U.S. Environ- head. mental Protection Agency (EPA) and/or Cali- fornia Resources Board (CARB) regulations for marine SI engines.
  • Page 8 General and important labels One Star - Low Emission exhaust emission standards or the Sterndrive The one-star label identifies engines that and Inboard marine engine 2003-2008 ex- meet the Air Resources Board’s Personal haust emission standards. Engines meeting Watercraft and Outboard marine engine 2001 these standards have 65% lower emissions exhaust emission standards.

  • Page 9: Important Labels

    General and important labels EJU30450 Important labels...

  • Page 10: Warning Labels

    General and important labels EJU35910 Warning labels...
  • Page 11 General and important labels...

  • Page 12: Other Labels

    General and important labels EJU35922 Other labels...
  • Page 13 General and important labels The following label indicates the correct direction to upright a capsized watercraft.

  • Page 14: Safety Information

    The safe use and operation of this water- operate the watercraft craft is dependent upon the use of proper Yamaha recommends a minimum operator riding techniques, as well as upon the age of 16 years old. common sense, good judgment, and ex- Adults must supervise use by minors.

  • Page 15: Cruising Limitations

    Safety information teristics of the watercraft before trying any EJU30760 Cruising limitations difficult maneuvers. Scan constantly for people, objects, and other watercraft. Be alert for conditions that limit your visibility or block your vision of others. Operate defensively at safe speeds and keep a safe distance away from people, ob- jects, and other watercraft.
  • Page 16 Safety information kles, and other bones. Do not jump wakes with another boat, which could result in se- or waves. vere injury or death. Do not operate the watercraft in rough wa- ter, bad weather, or when visibility is poor; this may lead to an accident causing injury or death.

  • Page 17: Operation Requirements

    Safety information know that a helmet could help protect you in EJU30811 Operation requirements certain kinds of accidents and that it could All riders must wear a U.S. Coast Guard injure you in others. (USCG) approved personal flotation device A helmet is designed to provide some head (PFD) that is suitable for personal water- protection.
  • Page 18 Safety information NEVER operate the watercraft after con- Always consult your doctor on whether it is suming alcohol or taking other drugs. safe for you to ride this watercraft if you are pregnant or in poor health. Do not attempt to modify this watercraft! Modifications to your watercraft may reduce safety and reliability, and render the water- craft unsafe or illegal for use.

  • Page 19: Recommended Equipment

    A mirror can also be used as an emergency signal. Contact a Yamaha dealer or the U.S. Coast Guard for more information. Watch A watch is helpful so you will know how long you have been operating the watercraft.

  • Page 20: Hazard Information

    Always operate the watercraft in an This model is equipped with the Yamaha open area. Engine Management System (YEMS) that Do not touch the hot oil tank, muffler, or en-...
  • Page 21 Safety information Reverse can be used to slow down or stop any debris or weeds, which may have col- during slow-speed maneuvering, such as lected around the jet intake. when docking. Once the engine is idling, shift into reverse and gradually increase en- gine speed.

  • Page 22: Water-Skiing

    Safety information is required by law. Let the skier direct the EJU30940 Water-skiing operator’s control of speed and direction You can use the watercraft for water-skiing if with hand signals. it has the seating capacity to carry the opera- The spotter should sit astride the rear of the tor, a rearward-facing spotter, and the water- seat and hold onto the handgrip with both skier when he or she is not skiing.
  • Page 23 Safety information watch the skier’s hand signals and condi- until the watercraft is well away from the ski- tion. er and slack in the ski rope is taken up. Make sure that the rope is not looped around anything. After checking that the skier is ready and that there is no traffic or other obstacles, ap- ply enough throttle to raise the skier.

  • Page 24: Rules Of The Road

    EJU30960 Rules of the Road The vessel which does not have the right-of- Your Yamaha watercraft is legally consid- way has the duty to take positive and timely ered a powerboat. Operation of the water- action to stay out of the way of the stand-on craft must be in accordance with the rules vessel.
  • Page 25 Safety information give-way vessels). Both you and the meeting provided the other vessel gives you the right- vessel must alter course to avoid each other. of-way as it should. Meeting Overtaking If you are meeting another power-driven ves- If you are passing another vessel, you are the sel head on, and are close enough to run the give-way vessel.
  • Page 26 Safety information Fishing vessel right-of-way Many bodies of water used by boaters are en- All vessels fishing with nets, lines, or trawls tirely within the boundaries of a particular are considered to be “fishing vessels” under state. The Uniform State Waterway Marking the International Rules.
  • Page 27 Safety information They signify speed zones, restricted areas, danger areas, and general information. Remember, markings may vary by geograph- ic location. Always consult local boating au- thorities before riding your watercraft in unfamiliar waters.

  • Page 28: To Get More Boating Safety Information

    Power Squadron. Watercraft Education and Training The Online Boating Safety Course, available through the watercraft section of the yamaha- motor.com website, is a free, 50 question learning course available to the public. Upon successful completion of 80 percent or better,...

  • Page 29: Enjoy Your Watercraft Responsibly

    Safety information EJU30990 Enjoy your watercraft responsibly You share the areas you enjoy when riding your watercraft with others and with nature. So your enjoyment includes a responsibility to treat these other people, and the lands, wa- ters, and wildlife with respect and courtesy. Whenever and wherever you ride, think of yourself as the guest of those around you.

  • Page 30: Features And Functions

    Features and functions EJU31010 Location of main components Front view 1 Handlebars 2 Rear seat 3 Front seat 4 Footwell 5 Sponsons 6 Gunwale 7 Cooling water pilot outlet 8 Bow eye 9 Hood...
  • Page 31 Features and functions Rear view 1 Fuel tank filler cap 2 Intake grate 3 Speed sensor 4 Stern eyes 5 Stern drain plugs 6 Reverse gate 7 Ride plate 8 Jet thrust nozzle 9 Reboarding step (for FX Cruiser) 10 Electric bilge pilot outlet 11 Cleat 12 Handgrip...
  • Page 32 Features and functions Control system 1 Multifunction information center 2 Beverage holder 3 Rearview mirrors 4 Throttle lever 5 Shift lever 6 Tilt lever 7 Glove compartment 8 Engine stop switch 9 Engine shut-off cord (lanyard) 10 Quick Shift Trim System (QSTS) selector 11 QSTS selector lock lever 12 Watertight compartment 13 Start switch...
  • Page 33 Features and functions Engine compartment 1 Air filter case 2 Water separator 3 Fuel tank 4 Battery 5 Flushing hose connector 6 Electrical box 7 Oil tank 8 Muffler 9 Spark plugs/Spark plug caps/Ignition coils 10 Spark plug lead...

  • Page 34: Operation Of Controls And Other Functions

    Features and functions EJU31020 To install the rear seat: Operation of controls and other Insert the projections on the front of the seat functions into the stays on the deck, and then push the EJU31040 rear of the seat down to lock it in place. Seats To remove the rear seat: Pull the rear seat latch up, and then pull the...

  • Page 35: Hood

    Features and functions To install the front seat: EJU31061 Hood (1) Insert the projections on the front of the To open the hood, push the hood latch down, seat into the stays on the deck, and then and then lift up the hood. push the rear of the seat down to lock it in place.

  • Page 36: Fuel Tank Filler Cap

    Features and functions EJU31090 switch, such as if the operator falls off the wa- Fuel tank filler cap tercraft. To remove the fuel tank filler cap, turn it coun- terclockwise. 1 Clip 2 Engine shut-off cord 1 Fuel tank filler cap 3 Engine shut-off switch EWJ00010 NOTE:...

  • Page 37: Start Switch

    Features and functions EJU31180 When the engine is running, cooling water is Start switch circulated in the engine, and then it is dis- Push the start switch (green button) to start charged from the pilot outlets. the engine. To check for proper operation of the cooling 1 Start switch system, check that water is being discharged NOTE:...

  • Page 38: Steering System

    This model is equipped with the Yamaha En- gine Management System (YEMS) that in- cludes an off-throttle steering (OTS) system.

  • Page 39: Shift Lever

    Features and functions otherwise the handlebars may suddenly Do not touch the reverse gate while the change position, which may lead to an shift lever is being operated, otherwise accident. you could be pinched. To shift into forward: EJU31300 Shift lever (1) Release the throttle lever and let the en- The shift lever is located on the starboard gine speed return to idle.
  • Page 40 Features and functions There are 5 positions: 2 bow-down positions To enhance particular types of performance, (a) and (b), neutral “N”, and 2 bow-up posi- select bow down or bow up. tions (c) and (d). EJU31330 Bow down To change the trim angle: Turn the QSTS selector to (a) or (b) and the (1) Reduce engine speed to 4000 r/min or bow will go down while the watercraft is on...

  • Page 41: Handgrip

    Features and functions ahead acceleration when on plane and top EJU34860 Reboarding step (for FX Cruiser) speed are enhanced. The reboarding step provides a handhold and In some conditions, however, the watercraft footstep for boarding the watercraft. may tend to “porpoise” (hop in the water). If the watercraft is porpoising, select neutral or bow down.

  • Page 42: Stern Eyes

    1 Stern eye CAUTION: EJU31370 Do not run the engine for more than 15 Yamaha Engine Management System seconds without supplying water or over (YEMS) 4000 r/min on land when checking the op- This model is equipped with an integrated,...
  • Page 43 Features and functions EJU34930 “RPM” indicator light comes on when the an- Analog speedometer/tachometer and indi- alog tachometer is selected. cator lights This watercraft is equipped with the following meter and indicator lights. 1 “Speed/RPM” button 2 “SPEED” indicator light 3 “RPM”...
  • Page 44 Features and functions EJU34950 EJU34980 “SPEED” indicator light “WARNING” indicator light The “SPEED” indicator light comes on when The “WARNING” indicator light blinks or the analog speedometer is selected. comes on, together with a warning indicator, when a malfunction has occurred. 1 “SPEED”...
  • Page 45 Features and functions The following operation buttons are on the left operating, or if the display units of the meter side of the multifunction meter. are switched to miles. 1 “Speed/RPM” button 1 “Volt/Hour” button 2 “Volt/Hour” button EJU35041 Digital speedometer The digital speedometer shows the watercraft speed against water.
  • Page 46 18.1 volts, “HI” is displayed on the voltmeter. If “HI” or “LO” is displayed, return to shore and, if necessary, have a 1 Fuel level meter Yamaha dealer check the charging system and the battery. NOTE: EJU35071...
  • Page 47 (See page 51 for engine oil level checking procedures.) If the oil level is low, add enough engine oil to raise it to the proper level. If the oil level is sufficient, have a Yamaha dealer check the watercraft. NOTE: Press any button on the multifunction meter to stop the buzzer.

  • Page 48: Storage Compartments

    If this occurs, reduce the engine speed, return to shore, and have a Yamaha dealer check the engine. NOTE: Press any button on the multifunction meter to stop the buzzer.
  • Page 49 Features and functions To open the front storage compartment, push To close the front storage compartment, push the hood latch down, and then lift up the hood. down on the rear of the hood until it latches securely. 1 Hood latch NOTE: Make sure that the front storage compartment is securely closed before operating the water-...
  • Page 50 Features and functions To open the glove compartment, turn the To open the seat storage compartment, re- glove compartment knob, and then lift up the move the rear seat. (See page 29 for rear seat lid. removal and installation procedures.) 1 Glove compartment knob 1 Seat storage compartment 1 Glove compartment...
  • Page 51 Features and functions EJU35170 Beverage holder NOTE: The beverage holder is located on the star- Make sure that the watertight compartment board (right) side of the watercraft. cap is closed securely before operating the watercraft. 1 Beverage holder NOTE: Do not place beverages in the beverage hold- er when operating the watercraft.

  • Page 52: Operation

    Gasohol containing methanol is not recom- dry rags. Always properly dispose of mended by Yamaha because it can cause gasoline-soaked rags. fuel system damage and engine performance Avoid overfilling the fuel tank. Stop fill- problems.

  • Page 53: Engine Oil

    Operation EJU31890 ly 50 mm (2 in) from the top of the fuel Engine oil tank as indicated in the illustration. Use a combination of the recommended SAE and API engine oil classifications shown in the chart below. ECJ00280 CAUTION: Use only 4-stroke engine oil.

  • Page 54: Pre-Operation Checks

    Operation EJU31980 Pre-operation checks EJU31990 Pre-operation check list Before operating this watercraft, perform the checks in the following check list. See the accom- panying text in this chapter for details on how to perform the checks. EWJ00410 WARNING If any item in the pre-operation check list is not working properly, have it inspected and repaired before operating the watercraft, otherwise an accident could occur.
  • Page 55 Operation NOTE: Pre-operation checks should be made each time the watercraft is used. These checks can be completed in a short time. It is worth the time spent to ensure safety and reliability.

  • Page 56: Pre-Operation Check Points

    Check the hull and deck for cracks and other enter the oil tank filler hole. Debris and damage. If any damage is found, have a water in the engine oil can cause serious Yamaha dealer repair the watercraft. engine damage. EJU32380 Fuel level...
  • Page 57 If the ambient temperature is 20 °C (68 °F) or mum level mark, the oil tank is overfilled. less, warm up the engine for an additional 5 Have a Yamaha dealer remove the ex- minutes. cessive amount of engine oil.
  • Page 58 Operation the water is discharged from the electric bilge could be damaged, allowing water to en- pilot outlet at the stern. ter the engine compartment. Make sure that the stern drain plugs are tightened securely before launching the watercraft. Otherwise, water may flood the engine compartment and cause the watercraft to submerge.
  • Page 59 Operation Check that the battery leads are tightened se- EJU32570 Fire extinguisher curely and that there is no corrosion on the Check that there is a full fire extinguisher on battery terminals. board. 1 Positive (+) battery terminal: Red lead The fire extinguisher container is located in 2 Negative (–) battery terminal: Black lead the seat storage compartment.
  • Page 60 Operation contact a Yamaha dealer or a fire extin- turned, and that there is no free play between guisher dealer to obtain one meeting the the handlebars and the jet thrust nozzle. proper specifications. Fire extinguisher: Classification: Capacity: 2 lb or more...
  • Page 61 Operation Also, make sure that the reverse gate goes up EJU32641 Quick Shift Trim System (QSTS) completely when the shift lever is pushed Operate the QSTS selector lock lever and the down. QSTS selector several times to check that they operate properly. (1) Squeeze the QSTS selector lock lever and check that it returns smoothly to its original position when released.
  • Page 62 If the mechanism does not work properly, have a Yamaha dealer service it. EJU32650 Jet intake Carefully check the jet intake for weeds, de- bris, or anything else that might restrict the in- take of water.
  • Page 63 Operation EJU32670 is running and the watercraft is in the water. Switches (See page 32 for more information.) ECJ00410 CAUTION: Do not run the engine for more than 15 seconds when checking the switches on land without supplying water, otherwise the engine could overheat.

  • Page 64: Operation

    For the 30 minutes of familiar with all of the controls. Consult a operation after that, keep the engine Yamaha dealer about any control or func- speed below 5000 r/min. For the 1 hour of tion that you do not fully understand. Fail-...
  • Page 65 Operation (1) Launch the watercraft in water free from (2) Attach the engine shut-off cord to your left weeds and debris and at least 60 cm (2 ft) wrist, and then attach the clip to the en- deep. gine shut-off switch. 1 Clip EWJ00570 2 Engine shut-off switch...

  • Page 66: Stopping The Engine

    Operation (3) Push the start switch (green button), and EJU32860 Stopping the engine then release it as soon as the engine To stop the engine, release the throttle lever, starts to run. and then push the engine stop switch (red button).

  • Page 67: Operating Your Watercraft

    Operation EJU32900 Check state and local laws before operating Operating your watercraft your watercraft. EJU32951 Operate defensively at safe speeds and keep Getting to know your watercraft a safe distance away from people, objects, Operating your watercraft requires skills ac- and other watercraft.

  • Page 68: Riding With Passengers

    Operation fabrics, like those used in bicycle shorts. A full vided, and keep their feet on the floor of the wetsuit can also protect against hypothermia footwell. Never allow a passenger to ride in (subnormal body temperature) and abra- front of the operator. sions.

  • Page 69: Boarding And Starting In Deep Water

    Operation Practice reboarding in shallow water be- (2) Board the watercraft from the side or the fore riding in deep water. rear. (3) Attach the engine shut-off cord to your left wrist, and then attach the clip to the en- gine shut-off switch.
  • Page 70 Operation EJU35230 start the engine, and then look in all direc- Boarding alone tions before starting off. (1) Swim to the rear of the watercraft and place both hands on the boarding plat- form, pull yourself up, and then grasp the handgrip with one hand.
  • Page 71 Operation (1) Climb on board as noted in the previous NOTE: section, and sit astride the seat. When a passenger is boarding, both the pas- sengers and the operator should try to bal- ance the watercraft. (5) Check that the passengers have their feet on the floor of the footwell and are securely holding on to the person in front of them or to the handgrip provided.

  • Page 72: Capsized Watercraft

    Operation tion, and then move to the seat and sit (6) Gradually increase the speed to balance astride to balance the watercraft. the watercraft. (2) Have a passenger pull him or herself up onto the boarding platform into a kneeling position, then move to the seat and sit astride to balance the watercraft.

  • Page 73: Turning The Watercraft

    Operation ride plate while pushing down on the gun- ECJ00550 CAUTION: wale with your right hand or foot. Do not operate the engine at full throttle for at least 1 minute after the engine has been restarted. Excessive water in the bilge can splash into the engine, which can result in severe damage.
  • Page 74 This model is equipped with the Yamaha En- gine Management System (YEMS) that in- cludes an off-throttle steering (OTS) system. It will activate at planing speeds should you attempt to steer the watercraft after releasing the throttle lever (see condition C above).

  • Page 75: Stopping The Watercraft

    Operation put until you apply throttle again or you reach steer away from a boat or other obstacle trolling speed. that comes into your path. EJU33290 Do not use the reverse function to slow Stopping the watercraft down or stop the watercraft as it could The watercraft is not equipped with a sepa- cause you to lose control, be ejected, or rate braking system.

  • Page 76: Rough Water Operation

    Operation Once the engine is idling, shift into reverse EJU33390 Post-operation care and gradually increase engine speed. Make To keep your watercraft in top shape, always sure that there are no obstacles or people be- take it out of the water after using it and per- hind you before shifting into reverse.

  • Page 77: Transporting

    Before putting the watercraft on the trail- (11) Spray a rust inhibitor, such as Yamaha er or transporting it, be sure to put the Silicone Protectant and Lubricant, on me- shift lever in the forward position, other- tallic parts to minimize corrosion.

  • Page 78: Maintenance And Care

    It is advisable 1 Flushing hose connector cap to have the watercraft serviced by a Yamaha 2 Garden hose adapter dealer prior to storage. However, the following 3 Flushing hose connector procedures can be performed by the owner.

  • Page 79: Lubrication

    EWJ00280 WARNING moval and installation procedures.) GASOLINE AND ITS VAPORS ARE HIGH- (3) Spray a rust inhibitor such as Yamaha LY FLAMMABLE AND EXPLOSIVE! Stor-Rite Engine Fogging Oil into each in- Do not smoke when refueling, and keep take opening for 3 seconds.

  • Page 80: Battery

    1.28 at 20 °C (68 °F) line in your eyes, get immediate medical attention. It is recommended to have a Yamaha dealer If any gasoline spills on your skin or check the specific gravity and charge the bat- clothing, immediately wash the affected tery.

  • Page 81: Maintenance And Adjustments

    EJU33800 See a Yamaha dealer for genuine Yamaha re- Owner’s/operator’s manual and tool placement parts and optional accessories de- signed for your watercraft. It is advisable to always carry the owner’s/op- Remember, failures that are the result of the erator’s manual and tool kit with you whenev-...
  • Page 82 Maintenance and care pairs. The tools provided in the tool kit are suf- ficient for this purpose, except that a torque wrench may also be necessary to tighten nuts and bolts. 1 Tool bag 2 Screwdriver 3 16 mm box wrench 4 10/12 mm box wrench 5 Pliers 6 Open-end wrench...

  • Page 83: Periodic Maintenance Chart

    This “ ” mark indicates maintenance that you may do yourself. This “ ” mark indicates work to be done by a Yamaha dealer. Initial Thereafter every Item...
  • Page 84 Maintenance and care Initial Thereafter every Item Operation hours hours hours hours hours Page months months months months Nuts and bolts Check — Air filter element Check Engine oil Replace Oil filter Replace Valve clearance Check, adjust — * This operation should be performed after every use.

  • Page 85: Checking The Fuel System

    Fuel tank filler cap and seal for damage. year or every 100 hours of operation. Fuel in fuel tank for water and dirt. Have a Yamaha dealer replace the oil fil- Fuel tank for damage, cracks, and leakage. ter if necessary.

  • Page 86: Checking The Air Filter Element

    If oil is leaking or the oil pressure warning indicator comes on when the engine is running, immediately shut the engine off and have a Yamaha dealer check the wa- tercraft. Continuing to operate the engine under such conditions could cause severe engine damage.

  • Page 87: Checking The Jet Thrust Nozzle Angle

    Maximum 5 mm (0.20 in) 1 Stopper 2 Shift arm If the reverse gate does not reach the correct positions, have a Yamaha dealer service it. EJU34360 Checking and adjusting the throttle cable Check that the throttle cable moves back to the set position smoothly and that the throttle lever free play is within specification.

  • Page 88: Cleaning And Adjusting The Spark Plugs

    Do not at- tempt to diagnose any problems yourself. Have a Yamaha dealer service the watercraft. Remove and inspect the spark plugs periodi- cally; heat and deposits will cause the spark 1 Spark plug gap plugs to slowly break down and erode.

  • Page 89: Lubrication Points

    To keep moving parts sliding or rotating smoothly, coat them with water-resistant Steering cable (handlebar end) grease. Recommended water-resistant grease: Yamaha Marine Grease/Yamaha Grease A Throttle cable (throttle body end) Throttle bodies (throttle cable pulley, throt- tle cam, and return spring)

  • Page 90: Checking The Battery

    Maintenance and care QSTS cables (pulley end) Shift cable (reverse gate end) QSTS cables (handlebar end) Intermediate housing Remove the QSTS cable housing. Spray a Fill the intermediate housing with water-re- rust inhibitor into the outer cables. Reinstall sistant grease through the grease nipple the QSTS cable housing.
  • Page 91 Battery life could be shortened. trolyte or charging the battery. It is recommended to have a Yamaha dealer charge the battery. If you charge the battery yourself, carefully read the battery charger in- structions before charging and follow the points below.

  • Page 92: Fuel Injection System

    EJU34490 Fuel injection system The fuel injection system was set at the Yamaha factory. If the fuel injection system needs to be adjusted, have a Yamaha dealer service the watercraft. ECJ00220 CAUTION: Do not attempt to adjust the fuel injection system.

  • Page 93: Specifications

    Specifications EJU34542 Spark plug: Specifications CR9EB Watercraft capacity: Spark plug gap: 0.7–0.8 mm (0.028–0.031 in) Maximum people on board: Battery capacity: 3 person 12 V, 19.0 Ah Maximum load capacity: Charging system: 240 kg (530 lb) Flywheel magneto Dimensions: Drive unit: Length: Propulsion system: 3340 mm (131.5 in)

  • Page 94: Trouble Recovery

    If you have any trouble with your watercraft, use this section to check for the possible cause. If you cannot find the cause, or if the procedure for replacement or repair is not described in this owner’s/operator’s manual, have a Yamaha dealer perform the necessary service. EJU34611...
  • Page 95 Engine runs irregu- Fuel Empty Refill as soon as pos- larly or stalls sible Stale or contaminat- Have serviced by Yamaha dealer Fuel tank Water or dirt present Have serviced by Yamaha dealer Spark plug Fouled or defective Replace Incorrect heat range...

  • Page 96: Emergency Procedures

    Trouble recovery EJU34620 contact with the rotating parts of the jet Emergency procedures pump. EJU34630 Cleaning the jet intake and impeller If weeds or debris get caught in the jet intake or impeller, cavitation can occur, causing jet thrust to decrease even though engine speed rises.

  • Page 97: Jumping The Battery

    (1) Connect the positive (+) jumper cable to If debris is difficult to remove, consult a the positive (+) battery terminals of both Yamaha dealer. batteries. ECJ00670 (2) Connect one end of the negative (–) CAUTION: jumper cable to the negative (–) battery...

  • Page 98: Replacing The Fuses

    Trouble recovery gine. Any wrong connection could dam- (2) Replace the blown fuse with the spare age the electrical system. fuse of the correct amperage by using the fuse puller on the reverse side of the cap. (4) Start the engine, and then disconnect the jumper cables by reversing the steps above.

  • Page 99: Towing The Watercraft

    If the watercraft is submerged or flooded with bars. water, follow the procedure below and consult a Yamaha dealer as soon as possible. Failure ECJ00720 CAUTION: to do so could result in serious engine dam-...
  • Page 100 Trouble recovery (6) Spray a rust inhibitor such as Yamaha Stor-Rite Engine Fogging Oil into each spark plug hole for 5 seconds. (7) Crank the engine for 5 seconds at wide open throttle. Repeat this step several times. (8) Install the spark plugs, and then connect the spark plug caps and fuel injector cou- plers.

  • Page 101: Consumer Information

    Owner’s/Operator’s Manual. The owner of the watercraft shall give notice to an authorized Yamaha dealer of any and all apparent defects within ten [10] days of dis- covery and make the watercraft available at that time for inspection and repairs at the dealer’s place of business.
  • Page 102 If you should move after you have purchased your new watercraft, please advise us of your new address by sending a postcard listing your Yamaha model name, engine number, dealer number [or dealer’s name] as it is shown on your warranty card, your name and new mailing address.

  • Page 103: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha Extended Service.
  • Page 104 Index Enjoy your watercraft responsibly .... 24 Air filter element, checking ....... 81 Analog speedometer/tachometer ..... 38 Filling the fuel tank ........48 Analog speedometer/tachometer and Fire extinguisher........54 indicator lights........38 Flushing the cooling system ..... 73 Approval label of emission control Front storage compartment ......
  • Page 105 ..........34 Water-skiing ..........17 Watertight compartment ......46 Reboarding step (for FX Cruiser) ..... 36 Recommended equipment ....... 14 Yamaha Engine Management Reverse on waterways......70 System (YEMS) ........37 Riding with passengers ......63 YAMAHA EXTENDED SERVICE Rough water operation......
  • Page 108 YAMAHA MOTOR CORPORATION, USA Printed in USA September 2006–1.0 × 1 CR...
