Airfree E60 Instruction Manual
Airfree air puri?ers
Hide thumbs
Also See for E60:
- Instruction manual (84 pages) ,
- Operator's manual (24 pages) ,
- Instruction manual (48 pages)
Related Manuals for Airfree E60
Summary of Contents for Airfree E60
- Page 1 Manual Instruction Manual Airfree E60 Airfree E60 Ai f Ai f...
- Page 2 Copyright 2001-2003 Airfree Produtos Eletrónicos Lda. All Rights Reserved All rights reserved. No part of this publication may be reproduced, photocopied, transmitted, transcribed, stored in a retrieval system, or translated into any lan- guage in any form or by any means without the express prior written consent of...
-
Page 3: Table Of Contents
Index Introduction Applications Airfree and Mould Technical Characteristics Airfree Description Installing and Connecting Safety Instructions How does Airfree work? Maintenance Airfree’s Independent and Effi ciency Tests FAQ - Frequently Asked Questions Warranty... - Page 4 Congratulations for having purchased your Airfree. Airfree air purifi ers are manufactured under license of US Patent 5,874,050, and many other patents pending worldwide. Airfree was designed with most advanced American and German technologies, to drastically destroy indoor airborne micro- organisms and reduce ozone.
-
Page 5: The Invisible Enemies
(some of them already resistant to the most power- ful chemicals and poisons), bacteria, viruses, the fi ne dust mite excrements and skeletons containing powerful allergens and hazardous fungus, and the seasonal pollens. Airfree can safely and silently destroy those allergens... -
Page 6: Applications
Airfree can reduce some odors like “mildew smell” and other organic odors. Kitchens and Pantries The reduction of airborne fungi and spores in areas protected by Airfree helps prevent mildew on food. Video, fi lms, slides, sound and optical equipment... - Page 7 The use of Airfree in guest rooms shows concern on behalf of the hotel to its guests well being. The use of Airfree can contribute to a higher oc- cupancy rate and may provide a good line of defense in case of lawsuits.
- Page 8 Food and Drug Administration, recommends not to use any equipment directly or indirectly generating ozone in Hospitals or where the patients are present. Airfree is proven to reduce ozone levels in 26%, every time air passes through its ceramic core. Viruses, Bacteria, Fungus and Germs...
-
Page 9: Airfree And Mould
3 - Clean mould infected items and surfaces, since they are a con- tinuous source of new spores. It is important to stress that Airfree will not destroy or remove mould from an infected item or surface. Those surfaces must be cleaned manually. -
Page 10: Technical Characteristics
Technical Characteristics Model Capacity 2119 cu.ft (60m³) Inside Temperature 392°F (200°C) Electric Consumption Voltage 220V - 240V Noise Totally Silent Weight 2.4 lbs (1,09 Kg) height: 10.4in (26.5 cm) Dimensions diameter: 8.4in (21.5 cm) -
Page 11: Airfree Description
Airfree Description 1- Top Lid with Air outlets 2- Side Shells 3- On/Off Led 4- Base 5- Air Inlets 6- Power Cord... -
Page 12: Installing And Connecting
fl ow and Airfree effi ciency in reducing microorganisms. Place each Airfree in rooms up to 258 sq. ft. (24m²) for E60. For larger rooms use proportionally additional Airfree units. The use of just one Airfree in rooms larger than recommended will reduce Airfree effi... - Page 13 However it is recommended not to place Airfree nearby them to avoid potential interference in Airfree air fl ow. Do not place Airfree in the corridor to try to reach the whole house. In this case Airfree will only reduce air pollution in the corridor area.
-
Page 14: Safety Instructions
Any attempt to open or tamper Airfree will void this warranty. To clean Airfree, unplug it from the electric outlet and use a dry cloth to wipe off its surface. Do not attempt to open Airfree to clean it inside. -
Page 15: How Does Airfree Work? Maintenance
The heat inside the ceramic core forces sterilised air out to the heat exchanger causing air convection, which generates negative pressure underneath the ceramic core, so contaminated air is “sucked” in at Airfree bottom air inlets in a continuous and silent thus effi cient air fl ow. -
Page 16: Airfree's Independent And Effi Ciency Tests
14 to april 29, 1999 INETI* Closed Environments Lisbon/Portugal november 12 to december 10, 2004 INETI* Lisbon/Portugal Hotel Rooms march 19 to april 30, 2001 Above and other tests can be seen at our web site www.airfree.com * Certifi ed by ISO 17025... -
Page 17: Faq - Frequently Asked Questions
3. What is Airfree’s air cleaning capacity? Airfree E60 was designed for rooms up to 258 sq. ft. (24m²) or 2118 cu. ft. (60m³). 4. Can I install Airfree in my walking closet ? Yes, as long as it has at least 330cu.ft (10m³)*. - Page 18 FAQ - Frequently Asked Questions 9. Is it necessary to keep doors and windows closed? It is preferable. But opening window for 1 or 2 hours a day will not affect Airfree effi ciency. 10. Does Airfree eliminate bacteria and viruses? Yes.
- Page 19 15. How does Airfree destroy dust mites? Mould reduction in the environment causes reduction in the mold dependant dust mite population. Airfree also destroys the harmful toxins and fungus freed by dust mite feces that trigger respiratory allergies. 16. How does Airfree eliminate fungi? As mentioned before, Airfree eliminates airborne microorganisms included fungi and spores.
- Page 20 24. Where do the microorganisms go after they are incinerated? As all living organisms, microrganisms and their products are basically composed by carbon, oxigen and nitrogen. Since Airfree reachs nearly 200ºC, all the compo- nents are supposed to suffer a combustion process, which liberates carbone di- oxide (the same product released by our respiration) and water.
-
Page 21: Warranty
To be eligible for the warranty, please register at www.airfree.com or complete your warranty card at the time of purchase and mail it to the distributor. To obtain warranty service, please send the product sales receipt or proof of Purchase, and a check or money order for €10 payable to the distribu-... - Page 22 Phone Number. ( Purchase Date Store Name: Invoice Number: In order to obtain full warranty terms and conditions as stated above please fi ll in and return Warranty Certifi cate to Authorised Airfree distributor. You may also register your warranty at www.airfree.com...
- Page 24 AIRFREE PRODUCTS Tel.: 351 - 213 156 222 Web: www.airfree.com Mail: info@airfree.com...
