Summary of Contents for Vosonic X's-DRIVE PRO VP300
- Page 1 ( VP300 ) OPERATION INSTRUCTIONS...
- Page 2 FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Index 1. Introduction ..............1 Features ................1 Accessories ..............1 Specifications ..............2 2. Overview of Panels & keys ........3 3. Using the X's-drive Pro ..........5 3-1 Starting up ..............5 -Charge Batteries ............5 -Power On /Off ............5 -Driver Installation ............. -
Page 4: Introduction
• Convenient charged by a generic AC/DC adapter. • USB 2.0 connection • MP3s playback • Firmware Upgradeable Accessories: • User Manual • Setup CD-Rom • USB Cable • Carrying Case • High Quality Earphone (3.50mm) • AC/DC adapter 100 ~ 240V auto switched X's-Drive Pro VP300... -
Page 5: Specifications
Accessories User Manual/Setup CD-Rom/USB Cable/ High Quality Earphone/Carrying Case Operating Temperature 0°C~70°C Storage Temperature -40°C~70°C Humidity 90% RH Weight 329g (including HDD and battery pack) Dimension ( L x W x H ) 136x 86 x 37mm X's-Drive Pro VP300... -
Page 6: Overview Of Panels & Keys
Power ON /OFF Long press to power on/off Delete Deletes data from Copy self-contained H.D.D Copies data from memory card(s) to Self-contained H.D.D Down Scroll upward Scroll Downward Volume down Volume up Play / Pause STOP / ESC X's-Drive Pro VP300... - Page 7 DC In : Reset Insert AC adapter jack USB port: Earphone Jack Insert USB cord mini jack Memory Stick / Memory Stick Pro, MMC/SD card slot SmartMedia card slot Compach Flash TypeI/II, IBM Microdrive slot X's-Drive Pro VP300...
-
Page 8: Using The X's-Drive Pro
Browse your CD-ROM drive and run "setup.exe "to begin driver installation. Press "Next" and follow the installation instructions. Restart your computer after installation is complete Under Windows 98, Windows 2000 Professional, the 4 removable disk drives look like drives F,G,H and I in the following figure. X's-Drive Pro VP300... -
Page 9: Multi-Language File Name Supporting
NOTE: Windows 2 K / XP don't support partition table for the new 40G above Hard Dirve,so that the Hard Drive must be Fdisk under Windows 98 DOS first. then use the "Application Program" to format Hard Disk. X's-Drive Pro VP300... -
Page 10: Downloading Or Editing The Files On Pc
• Double Click the " My computer" icon , the operating system will display 4 "Removeable Disks " icons identifying the media types correspondingly. • You can then read ,write,copy ,delete and remove data on the PC. X's-Drive Pro VP300... -
Page 11: Data Transfer
• Use the UP and down buttons to find the file you want to copy. • Press "COPY" button, Single File Copy function can be performed. • If the arrow has stop flashing, it indicates the file is successfully copied X's-Drive Pro VP300... -
Page 12: Single File Copy
1. Disconnect unit from the computer 2. Remove memory card(s) from the card slot Otherwise, there may be a chance of lost or corrupt data. Note: Keep it plugged into the AC adapter/charge while connected to your computer. X's-Drive Pro VP300... -
Page 13: Delete File
" button to pause a song and then again to restart the song. 5) Use the "Copy" button to play all tracks in the current directory then again to play a single track. 6) Hold the power button for 2 seconds to select the EQ mode. X's-Drive Pro VP300... -
Page 14: Auto Power Off Function
1) When the device error message pop on screen, there may be a chance of corrupt data or the memory card is damaged, you can change another memory card or the main unit will be automatically switched off after 45 second. X's-Drive Pro VP300... -
Page 15: Care For The Hard Drive And The Unit
7) To reduce the risk of electronic shock, do not remove cover (or back ) 8) To reduce the risk of fire or shock hazard, do not expose this equipment to rain, any liquid or moisture. 9) Keep it plugged into the AC adapter/charge while connected to your computer. X's-Drive Pro VP300... -
Page 16: Troubleshooting
Under Windows 98, the The X's-drive Pro has The driver must be installed New hardware install been connected before before connecting the X's-drive wizard does not find a installing the driver Pro. suitable driver in the CDROM X's-Drive Pro VP300... - Page 17 When I insert the CDROM The automatic execution Run from the Explorer the into the CDROM drive of Autorun files from Autorun.exe file located in the under Windows, nothing CDROM is not enabled in CD-ROM's root directory happens the system. X's-Drive Pro VP300...
- Page 18 = 70 2, appears associed with the ASC = 3a, ASCQ = 0 are following devices: shown by the dmesg /dev/sda, /dev/sdb and command /dev/sdc are the card slots /dev/sdd is the internal harddisk. X's-Drive Pro VP300...
- Page 19 The FAT-32 file system allows for larger than 4 GB, although limitation files up to 4 GB in length. Split my X's-Drive Pro has more the back-up into blocks smaller than that free space than 4 GB X's-Drive Pro VP300...
-
Page 20: Frequently Asked Questions
Should the disk be previously partitioned, every partition can be reformated, but the number or size of the partitions cannot be changed. • Under Linux several partitions can be created by fdisk X's-Drive Pro VP300... - Page 21 What is wrong? What is the purpose of In case that the X's-Drive II hangs, you can reset it via the Reset button on the this button-note that the data on the Hard disk will not X's-Drive? be affected. X's-Drive Pro VP300...
- Page 22 How to work with the X's- USB disks are supported under Linux from kernel 2.4.x. Drive under Linux? Are USB drivers are included in kernel 2.4.18 or later, and drivers needed? there are USB packages available to install under earlier 2.4.x versions. X's-Drive Pro VP300...
- Page 23 Hard Disk Assembly Chart Step 1: Remove the screw Step 2 : Insert the new HDD into the case and place screws 1-4, then connect the HDD connector cable. ➀ ➂ ➃ ➁ X's-Drive Pro VP300...
- Page 24 Thank you for choosing this product. If you experience problems with X's-drive And cannot find answer in the previous troubleshooting sections, please contact your dealer. Or check the updated firmware at www.xs-drive.com, www.vosonic.com...
