Seiko W524 Instructions Manual

Seiko W524 Instructions Manual

Digital quartz watch
Hide thumbs

Advertisement

Quick Links

Cal. W524
INSTRUCTIONS
BEDIENUNGSANLEITUNG
INSTRUCTIONS
ISTRUZIONI
INSTRUCCIONES
INSTRUÇÕES
(P.
3)
(S. 18)
(P. 33)
(P. 48)
(P. 63)
(P. 78)
(93
)

Advertisement

loading
Need help?

Need help?

Do you have a question about the W524 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seiko W524

Summary of Contents for Seiko W524

  • Page 1 Cal. W524 INSTRUCTIONS BEDIENUNGSANLEITUNG (S. 18) INSTRUCTIONS (P. 33) ISTRUZIONI (P. 48) INSTRUCCIONES (P. 63) INSTRUÇÕES (P. 78)
  • Page 2 You are now the proud owner of a SEIKO Digital Quartz Watch Cal. W524. For best results, please read the instructions in this booklet carefully before using your SEIKO Digital Quartz Watch. Please keep this manual handy for ready reference.

  • Page 3: Table Of Contents

    CONTENTS Page MODE CHANGE ...................... TIME/CALENDAR MODE ..................ALARM MODE ......................ILLUMINATING LIGHT ..................... NOTES ON USING THE WATCH ................BATTERY CHANGE ....................TO PRESERVE THE QUALITY OF YOUR WATCH ........... SPECIFICATIONS .....................
  • Page 4 CAL. W524 TIME/CALENDAR The watch indicates the hour with the hour indicator bars and the minutes and seconds in numerals. Month, date and day of the week are displayed in the CALENDAR display. The month is also indicated by the month indicator bars.

  • Page 5: Mode Change

    MODE CHANGE With each press, the mode changes between TIME/CALENDAR and ALARM alternately. TIME display ALARM display Hour indicator bars indicator indicator TIME/CALENDAR mode ALARM mode (TIME display)

  • Page 6: Time/Calendar Mode

    TIME/CALENDAR MODE Hour/month indication: The number of lighted bars indicates the hour/month. The calendar automatically adjusts for odd and even months except February of leap years. SHOWING THE CALENDAR DISPLAY Press and hold in TIME/CALENDAR mode. * While the button is kept pressed, the CALENDAR display is shown instead of the TIME display. TIME display CALENDAR display Hour indicator bars...
  • Page 7 TIME/CALENDAR SETTING Press for 2 to 3 seconds in TIME/CALEN- DAR mode. Press to select the digits/bars to be ad- justed. Seconds Minutes Hour Date Month Press to set the flashing digits. Press to return to TIME display.

  • Page 8: Alarm Mode

    ALARM MODE The alarm can be set to ring on a 24-hour basis. ALARM TIME SETTING ALARM display Press to show ALARM mode. Hour indicator bars indicator Press for 2 to 3 seconds. Press to select the digits/bars to be ad- justed.

  • Page 9: Illuminating Light

    ALARM ENGAGEMENT/DISENGAGEMENT With each press in ALARM mode, the alarm is alternately engaged and disen- gaged. * When the alarm is engaged, the alarm engage- ment indicator is displayed. * At the designated time, the alarm rings for 20 seconds. To stop it manually, press any of the buttons in any mode.

  • Page 10: Notes On Using The Watch

    NOTES ON USING THE WATCH TIME/CALENDAR MODE [TIME/CALENDAR SETTING] The TIME or CALENDAR display is shown according to the digits/bars selected. While the second digits are flashing, press button D in accordance with a time signal. The seconds are reset to “00”. When the seconds read any number from “30” to “59” and button D is pressed, one minute is added and the seconds are reset to “00”.
  • Page 11 When the illuminating light becomes dim, replace the battery with a new one. If the illuminating light remains dim after the battery is replaced, have the electroluminescent panel replaced with a new one by the retailer from whom the watch was purchased, or an AUTHORIZED SEIKO DEALER. It will be replaced at cost.

  • Page 12: Battery Change

    For battery replacement, we recommend that you contact an AUTHORIZED SEIKO DEALER and request SEIKO CR2025 battery. * The battery life may be less than 3 years if the alarm is used for more than 10 seconds a day and/or the illuminating light more than once a day.

  • Page 13: To Preserve The Quality Of Your Watch

    TO PRESERVE THE QUALITY OF YOUR WATCH WATER RESISTANCE Condition Scuba of use Accidental Taking a bath Swimming, and shallow contact with diving** yachting and Indication on diving water such taking a case back saturation as rain and shower Degree diving splashes of water...
  • Page 14 • Do not operate the buttons when ** We recommend that you wear a the watch is wet or in water. SEIKO Diver’s Watch for scuba If used in sea water, rinse the bar WR diving. watch in fresh water and dry it completely.
  • Page 15 2 2 - 3 to 3 years. Have your watch Years checked by an AUTHORIZED SEIKO DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and CHEMICALS crystal seal remain intact. Be careful not to expose the...
  • Page 16 TV becoming difficult to read. Please contact screens which emit strong static electricity. your AUTHORIZED SEIKO DEALER or SERVICE CENTER if you wish to have a new panel fitted (guaranteed one year).

  • Page 17: Specifications

    Alarm engagement indicator Display medium ........Nematic Liquid Crystal, FEM (Field Effect Mode) Battery ............SEIKO CR2025, 1 piece IC (Integrated Circuit) ........ C-MOS-LSI, 1 piece * The specifications are subject to change without prior notice for product improvement.
