Seiko W073 Manual

DIGITAL STOPWATCH

CAL. W073
You are now the proud owner of a SEIKO Digital Stopwatch Cal. W073.
For best results, please read the instructions in this booklet carefully
before using your SEIKO Digital Stopwatch.
Please keep this manual handy for ready reference.

WARNING

NOTES ON THE BATTERY

Do not remove the battery from the stopwatch.
If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
Never short-circuit, heat or otherwise tamper with the battery, and
never expose it to fire. The battery may burst, become very hot or
catch fire.
The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.

NOTES ON THE STRAP

The stopwatch has a strap for wearing the stopwatch around your
neck. Take good care lest it should be caught by something near you
or wind around your neck.
Please also note that the strap may damage your clothes, or injure
your hands, neck or other parts of your body.

TO PRESERVE THE QUALITY OF YOUR STOPWATCH

WATER RESISTANCE (3 bar)
Your stopwatch is designed and manufactured to withstand up to 3 bar, such as
accidental contact with splashes of water or rain, but it is not designed for swimming
or diving. Do not operate the buttons when the stopwatch is wet or in water.
TEMPERATURES
+50°C
If the stopwatch is left in direct sunlight for a long time, the display may become
black, but this condition will be corrected when the stopwatch returns to normal
– 5°C
temperature.
Do not leave your stopwatch in very low temperatures below –5°C (+23°F) for a
long time since the cold may cause:
a. a slight time loss or gain.
b. the change of digits to become slow.
c. the display light to dim.
However, the above conditions will be corrected when the stopwatch returns to
normal temperature.
SHOCKS
Do not subject it to violent shocks.
MAGNETISM
Your stopwatch will not be affected by magnetism.
N S
CHEMICALS
Be careful not to expose the stopwatch to solvents, mercury, cosmetic spray,
detergents, adhesives or paints. Otherwise, the case, etc. may become discolored,
deteriorated or damaged.
PERIODIC CHECK
It is recommended that the stopwatch be checked once every 2 to 3 years. Have
2 - 3
Years
your stopwatch checked by an AUTHORIZED SEIKO DEALER or SERVICE
CENTER to ensure that the case, buttons, gasket and crystal seal remain intact.
PRECAUTION REGARDING CASE BACK PROTECTIVE FILM
If your stopwatch has a protective film and/or a sticker on the case back, be sure
to peel them off before using your stopwatch.
STATIC ELECTRICITY
The IC (Integrated Circuit) used in your stopwatch will be affected by static
electricity which may disturb the display. Keep your stopwatch away from close
contact with objects such as TV screens which emit strong static electricity.
LIQUID CRYSTAL PANEL
The normal life expectancy for a liquid crystal panel is approximately 5 years.
After that it may decrease in contrast, becoming difficult to read. Please contact
5 Years
your AUTHORIZED SEIKO DEALER or SERVICE CENTER if you wish to have a
new panel fitted (guaranteed one year).

FEATURES

FEATURES
Stopwatch
Measures up to 100 hours in 1/100 seconds for the first hour and in seconds
thereafter.
Lap time and split time measurements are available.
MEMORY RECALL
Up to 10 newest lap times and split times can be stored in memory. They can
be recalled either during or after the measurement.
TIME/CALENDAR
Month, day, date, hour, minutes and seconds are displayed. The calendar
automatically adjusts for odd and even months including February of leap years
from January 1, 2003 up to December 31, 2052.
Changeover between 12- and 24-hour indications
Alarm
Can be set to ring once daily at a designated time.

MODE CHANGE

MODE CHANGE
Day
AM/PM mark
Button operation
confirmation
sound mark
B
With each press, the mode changes in the following order.
TIME/
CALENDAR
mode
When the button operation confirmation sound is switched on, a beep sounds with
each press of button B. As a reference aid, the tone is different when the TIME/
CALENDAR mode appears.
If " " is displayed in the TIME/CALENDAR, MEMORY RECALL or ALARM mode,
the measurement is in progress in the STOPWATCH mode.
- 1 -
[ TIME/CALENDAR mode ]
Month Date
B
C
A
Alarm mark
Hour Minutes Seconds
STOPWATCH MEMORY
mode RECALL
mode
ALARM
mode
