These buttons / keys have several functions.
All functions of the respective buttons / keys outlined in the following chart below.
Your display Button / Key
indicates following to be pushed pushing the
information
TRP-AVS-RID-STP- MODE 1
MAX
TCNT-CLK- ODO MODE 1
TRP-RID-AVS MODE 1
TRP MODE 1
CLK MODE 1
ODO MODE 1
RID-AVS-STP-MAX MODE 1
TCNT MODE 1
TCNT-CLK- ODO MODE 2
TRP-RID-AVS-MAX MODE 2
TRP-RID-AVS-MAX MODE 2
TCNT MODE 2
STP MODE 2
STP MODE 2
Length of What is going on?
button / key
brief (0.1 sec) next information from MODE 1 is indicated.
brief (0.1 sec) computer changes display information from MODE 2 data to
TRP-data of MODE 1
normal (1.5 sec.) TRP-RID-AVS are automatically rotated, one at a time displayed
for 1.5 sec.
long (5 sec) enter set-up mode for wheelsizes.
long (5 sec) enter set-up mode for clock.
long (5 sec) enter set-up mode for odometer.
long (5 sec) switching from wheelsize 1 to wheelsize 2 and vice-versa
long (5 sec.) Set-up mode for TCNT (second trip counter) is called into display
brief (0.1 sec) next information from MODE 2 is indicated.
brief (0.1 sec) computer changes display information from MODE 1 data to
MODE 2 data. TCNT always being the first information indicated.
long (5 sec) TRP-AVS-RID-MAX information reset to zero.
long (5 sec.) Second trip counter TCNT is being reset to zero
long (5 sec) stop watch STP reset to zero
brief (0.1 sec.) either start or stop run of stop watch
