2. Mounting the speed transmitter
Model VDO CYTEC C 10 WL works by
radio transmission of speed impulses from
the sender on the fork, to the receiver
incorporated into the computer head
mounted on the handlebar. Please be sure
to get the sender aimed at the receiver
(computer head) with as much precision
as possible. The sender should be
mounted on the same side of the fork as
the holder is on the handlebar.
Watch out: Do not tighten the cable ties
yet! Accurately position the spoke magnet
and the sender first, then tighten the cable
ties. The distance between transmitter
(sender) and computer head must not
exceed 24 inches (60 cm). Sender range
is technically limited in accordance with
German telecommunication law.
3. Mounting the spoke magnet
Distance between magnet and
sender should be approx. 1-5 mm.
