- Page 1 X-Treme Electric Scooters Model: X-360 Product Handbook (photos may vary) PLEASE BE SAFE WHEN RIDING ALWAYS WEAR A HELMET AND OBEY ALL LAWS! Page1...
-
Page 2: Important Information
Failure to follow these INSTRUCTIONS will VOID YOUR WARRANTY! This PRODUCT IS NOT INTENDED FOR EXTREME or OFF-ROAD Use! Please take care of your X-360! DO NOT JUMP or ABUSE THIS PRODUCT! DO NOT RIDE IN WET/ICY CONDITIONS! Failure to follow these instructions will... - Page 3 IMPORTANT PLEASE READ THIS BEFORE USING THIS PRODUCT READ THIS FIRST! WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways. Serious injury can result from the unsafe operations of this product. Operator can minimize these risks by using certain safety equipment such as: safety helmet, goggles, gloves, elbow and kneepads and appropriate footwear.
-
Page 4: Quick Reference
Brakes are designed to control speed as well as stop the scooter. Practice braking for proper slowing down and smooth stops. • Maintain your X-Treme X-360 as recommended in this Product Handbook. • Use only quality replacement parts as recommended by the manufacturer. -
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION…………………………………….…2-3 QUICK REFERENCE…………………………………………………4 TABLE OF CONTENTS……………………………….……………...5 GETTING TO KNOW YOUR X-TREME X-360………..…………..6 PACKING CONTENTS……………………………………………….7 GETTING STARTED………………..……………………………..…7 ASSEMBLY………………………………………………………..7 CHARGING………………………………………………………..8 RIDING……………………………………………………………..8 STOPPING/BRAKING……………………………………………9 BRAKING SYSTEM………….…………………………………..9 TIRES………………………………..…………………..………..10 MAINTENANCE………………………………………………………10 RECOMMENDED TOOLS……………………………………...10 ADJUSTING THE CHAIN……..…………………………….….10 MAINTENANCE SCHEDULE……………………………………….11 TROUBLESHOOTING GUIDE…..…………………………………..12 ADDITIONAL INFORMATION………………………………………..13 GENERAL INFORMATION/TECH SUPPORT……………………..14... -
Page 6: Getting To Know Your X-Treme X-360
GETTING TO KNOW YOUR X-TREME X-360 (Photo’s may vary) Page6... -
Page 7: Packing Contents
PACKAGE CONTENTS Your X-Treme X-360 comes with the following items in the box. Please locate all of the following: The X-Treme X-360 Scooter 36V Battery Charger Tool Kit Seat & Seat Post Front Wheel & Axle Trunk with Keys & mounting hardware Trunk Rack &... -
Page 8: Charging
4. Turn the Ignition key to the on position. Gently rotate the THROTTLE GRIP, on the right side of the handlebars. The X-360 will begin to move on its own power. Your scooter has a variable speed hand throttle. You can control the speed of your scooter by the amount of pressure you use when rotating the hand throttle. -
Page 9: Stopping/Braking
BRAKING SYSTEM The X-360 uses a hub brake system on the rear wheel of the scooter activated by a hand brake lever on the left side of the handlebar. Squeezing the hand brake lever with your left hand activates the rear brake. -
Page 10: Tires
TIRES The X-Treme X-360 uses an identical tire on the front and rear wheels, which means that the tires can be rotated. Tire wear will differ based on rider weight, riding conditions and care. Replacement tires can be obtained at your local X-Treme dealer, through motorcycle shops, or from the X-Treme website at www.x-tremescooters.com... -
Page 11: Maintenance Schedule
Fig. 9 MAINTENANCE SCHEDULE Proper care of your X-Treme X-360 will insure optimal performance and longer life span. The following are a few maintenance suggestions that will keep your X-Treme X-360 running in top condition: Daily Maintenance Perform each time you ride your X-360 Clean the exterior of the unit with a soft, damp rag. -
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Motor Does Not Start Batteries not connected Connect batteries Power switch is off Turn on power/key Batteries are drained Charge batteries Electrical Fault Check all fuses Master power/kill Turn on master power Rear wheel does not Brake too tight Adjust brakes Motor Trouble... -
Page 13: Additional Information
If you have questions about our warranty, please contact your dealer. X-Treme Electric Scooters Manufacturers & Wholesale Distributors is not responsible for the proper or improper use of merchandise sold. We care about our customers and urge you to exercise caution and take necessary safety measures to protect yourself while engaging in cycling. -
Page 14: General Information/Tech Support
For General Information or Parts Visit http://www.x-tremescooters.com/ For Technical Support or Assistance Visit http://www.x-tremescooters.com/support/ Page14...
