- Page 1 BVP 8759 User's Manual...
- Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Leadtek Research Inc. Leadtek makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or fitness for any particular purpose. The information in this document is subject to change without notice.
-
Page 3: Table Of Contents
When the IP is shared with other devices (without a DHCP server connected) ............... 14 ADSL/Constant ADSL/Multiple, Public, & Fixed IP ... 15 When BVP 8759 uses one of the IPs (with a DHCP server connected) .................. 15 When BVP 8759 uses one of the IPs (without a DHCP server connected) ............... - Page 4 Table of Contents ADSL/Timing ADSL ............ 19 When the ADSL is used exclusively by BVP 8759 ..... 19 When the ADSL is shared with other devices (with a DHCP server connected) ............... 20 When the ADSL is shared with other devices (without a DHCP server connected) ............
- Page 5 Table of Contents Using OSD Menus ..........37 Password Checking ............37 Configuration ..............38 System Setup ..............38 Network Setup ..............38 Server Setup ..............39 Terminal Setup ..............40 NTP Setup ................ 41 Service Setup ..............42 Call Service Setup ............42 Auto Answer Setup ............
-
Page 6: Getting Started
Getting Started Overview The BVP 8759 is designed to avoid complicated installation. And with the buttons on the remote control, you are able to access the user-friendly on screen display menu (OSD), easily control the functions and make adjustments. BVP 8759 has a built-in high quality CCD camera. -
Page 7: What's In The Package
Please unpack the product package with caution; inspect the items closely. If you find any damaged item, please contact your local distributor immediately. Also, please keep the box and packing material for future use in the event of future shipments. BVP 8759 User's Manual... -
Page 8: Getting To Know Your Bvp 8759
Getting to Know Your BVP 8759 Front view CCD Camera: Power Indicator: The input source of The LED lights green local video image. This when the unit is is a mini built-in CCD powered on. camera. Message Indicator: The LED lights red when a message comes. -
Page 9: Rear View
TV and VCR Ethernet connector Power Switch Microphone USB Connectors Phone Connector For turning Connect to other Connect to on/off the power Connect to an USB devices a telephone external microphone (optional). Connect to an external PTZ camera BVP 8759 User's Manual... -
Page 10: Using Remote Control
Using remote control PQRS WXYZ 1. Camera 12. Soft key 1 (reserved) 2. Number keys 13. On-hook / Off-hook 3. PTZ Camera zoom in 14. PTZ Camera zoom out 4. Navigation key 15. Navigation key 5. Navigation key 16. Ok 6. -
Page 11: Hot Keys
To toggle mirror video on/off. During a video call, this button is used to mute the audio so that Camera: you will not be heard by the To switch between STB and other party on the phone. external PTZ camera. BVP 8759 User's Manual... -
Page 12: Numeric Keypad
Using remote control (cont.'d) Numeric Keypad Inputting numbers Pressing any key on the numeric keypad can input the correspondent number. PQRS WXYZ For example, pressing will generate the number " 8 ". Inputting letters Numeric Keypad Every button on the numeric keypad has characters printed on it, in addition to the numbers. -
Page 13: Installation
Installing the unit Step 1 Pick a good spot Stability Place your BVP 8759 on top of a counter, desk, or table with the CCD camera opening in front. Or you can install BVP 8759 on the wall by fixing the included mounting plate to the wall with screws and sliding the slot on the back of BVP 8759 onto the mounting plate. - Page 14 Step 3 Plug in for power Connect the power cord between the wall outlet and the power adapter. Plug the free end of the power adapter into the power connector (DC IN) on BVP 8759. Connect the power adapter. Connect the power cord and plug in.
- Page 15 Installing the unit (cont'd) External Microphone (Optional) Video/Audio Video/Audio Output Input (Optional) Television CCD Camera Television BVP 8759 User's Manual...
-
Page 16: System Setup
System Setup The System Setup section gives instructions on how to set up your BVP 8759 system under some mostly used interconnection types. There is a condition bar on each page (as shown in the figure), indicating what type of connection the setup guide on that page is for. -
Page 17: Adsl/Constant Adsl/Single, Public, & Fixed Ip
System Setup (Cont'd) Connection ADSL Type Constant ADSL Single, Public, & Fixed When the IP is used exclusively by BVP 8759 Internet BVP 8759 ATU-R BVP 8759 System Setup System Setup Network Setup Configuration Service Setup Server Setup Password Bandwidth Setup... -
Page 18: When The Ip Is Shared With Other Devices (With A Dhcp Server Connected)
TCP port must be able to 1720-1730 and 7000-7009 and UDP port 8050-8058. support dynamic- Or you can put BVP 8759 into DMZ if your router fixed IP allocation. supports this function. BVP 8759 System Setup... -
Page 19: When The Ip Is Shared With Other Devices (Without A Dhcp Server Connected)
This router has to be able to provide the NAT service and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup... -
Page 20: Adsl/Constant Adsl/Multiple, Public, & Fixed Ip
System Setup (Cont'd) Connection ADSL Type Constant ADSL Multiple, Public, & Fixed When BVP 8759 uses one of the IPs (with a DHCP server connected) Internet ATU-R General PC 1, 2, ...n BVP 8759 DHCP Server BVP 8759 System Setup... -
Page 21: When Bvp 8759 Uses One Of The Ips (Without A Dhcp Server Connected)
System Setup (Cont'd) Connection ADSL Type Constant ADSL Multiple, Public, & Fixed When BVP 8759 uses one of the IPs (without a DHCP server connected) Internet ATU-R General PC 1, 2, ...n BVP 8759 BVP 8759 System Setup System Setup... -
Page 22: When One Of The Ips Is Shared With Other Devices (With A Dhcp Server Connected)
TCP port must be able to 1720-1730 and 7000-7009 and UDP port 8050-8058. support dynamic- Or you can put BVP 8759 into DMZ if your router fixed IP allocation. supports this function. BVP 8759 System Setup... -
Page 23: When One Of The Ips Is Shared With Other Devices (Without A Dhcp Server Connected)
This router has to be able to provide the NAT service and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup... -
Page 24: Adsl/Timing Adsl
System Setup (Cont'd) Connection ADSL Type Timing ADSL Single, Public, & Dynamic When the ADSL is used exclusively by BVP 8759 Internet BVP 8759 ATU-R BVP 8759 System Setup System Setup Network Setup Configuration Server Setup Service Setup Password Bandwidth Setup... -
Page 25: When The Adsl Is Shared With Other Devices (With A Dhcp Server Connected)
TCP port must be able to 1720-1730 and 7000-7009 and UDP port 8050-8058. support dynamic- Or you can put BVP 8759 into DMZ if your router fixed IP allocation. supports this function. BVP 8759 System Setup... -
Page 26: When The Adsl Is Shared With Other Devices (Without A Dhcp Server Connected)
This router has to be able to provide the NAT service and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup... -
Page 27: Cable
System Setup (Cont'd) Connection Cable Type Single, Public, & Dynamic When the IP is used exclusively by BVP 8770 Internet BVP 8759 Cable modem BVP 8759 System Setup System Setup Network Setup Configuration Server Setup Service Setup Password Bandwidth Setup Terminal Setup... -
Page 28: When The Ip Is Shared With Other Devices (With A Dhcp Server Connected)
: TCP port 1720- must be able to 1730 and 7000-7009 and UDP port 8050-8058. Or you support dynamic- can put BVP 8759 into DMZ if your router supports this fixed IP allocation. function. BVP 8759 System Setup... -
Page 29: When The Ip Is Shared With Other Devices (Without A Dhcp Server Connected)
This router has to be able to provide the NAT service and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup... -
Page 30: Lan/No Firewall Or Nat
Connection Type Firewall Packet Filter With a DHCP server connected Internet Router General PC 1, 2, ...n BVP 8759 DHCP Server BVP 8759 System Setup System Setup Network Setup Configuration Server Setup Service Setup Password Bandwidth Setup Terminal Setup Phonebook... -
Page 31: Without A Dhcp Server Connected
System Setup (Cont'd) Connection Type Firewall Packet Filter Without a DHCP server connected Internet Router General PC 1, 2, ...n BVP 8759 BVP 8759 System Setup System Setup Network Setup Configuration Service Setup Server Setup Password Bandwidth Setup Terminal Setup Phonebook... -
Page 32: Lan/Nat
TCP port must be able to 1720-1730 and 7000-7009 and UDP port 8050-8058. support dynamic- Or you can put BVP 8759 into DMZ if your router fixed IP allocation. supports this function. BVP 8759 System Setup... -
Page 33: Without A Dhcp Server Connected
This router has to be able to provide the NAT service and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050- 8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup... -
Page 34: Lan/Firewall With Packet Filter
General PC 1, 2, ...n BVP 8759 DHCP Server Firewall This firewall must be able to enable packets I/O for TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058 (for BVP 8759 exclusively). BVP 8759 System Setup System Setup Network Setup Configuration Service Setup... -
Page 35: Without A Dhcp Server Connected
General PC 1, 2, ...n BVP 8759 Firewall This firewall must be able to enable packets I/O for TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058 (for BVP 8759 exclusively). BVP 8759 System Setup System Setup Network Setup Configuration... -
Page 36: Lan/Firewall With Nat & Packet Filter
It must also be able to provide the NAT service, and the following static dynamic-fixed routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port IP allocation. 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. BVP 8759 System Setup System Setup... -
Page 37: Without A Dhcp Server Connected
It must also be able to provide the NAT service, and the following static routes should be set: TCP port 1720-1730 and 7000-7009 and UDP port 8050-8058. Or you can put BVP 8759 into DMZ if your router supports this function. -
Page 38: Making A Call
BVP 8759. might shine into the camera lens. 0.5 m Make sure of the most appropriate Do not point the BVP 8759 at a lighting source, preferably from mirror or bright light. the front with the beam on your face. -
Page 39: Making A Video Call
Dialing (local view) button. Step 5 If there is difficulty in making connection, please make sure that the BVP 8759 has been properly installed. Please also check if the network settings are correctly configured. BVP 8759 User's Manual... -
Page 40: Icon Explanations
Icon explanations When BVP 8759 is powered on, a bootup screen will be displayed, as the figure shown below. There are icons around the screen indicating various statuses of the unit, as explained below. SIP Registration Fail LAN Disconnected SIP Registration OK... - Page 41 The antenna icon on the lower right corner indicates the connection status. The sun icon means the Ethernet cable is connected to the unit. If the sun icon disappears, it means the Ethernet cable is not connected. BVP 8759 User's Manual...
-
Page 42: Using Osd Menus
Using OSD Menus Password Checking : Item selection Configuration Password Phonebook You can enter a combination Please input password: of up to 64 letters (upper case or lower case) and numbers as the password. : backspace System Setup Service Setup Bandwidth Setup Remote Update Note:... -
Page 43: System Setup
There will be a number on the bottom left corner of the screen, indicating the current input mode. Press button to cycle through (numbers), (upper case letters), and (lower case letters) for your desired input mode. BVP 8759 User's Manual... -
Page 44: Server Setup
Using OSD menus Configuration System Setup Server Setup SIP Server: ********* Port: **** Domain: ********* Re-Reg.(1~24h): 1 DNS: 172.16.0.2 NTP Server: 204.152.184.72 Update Server: 0.0.0.0 SIP Server: SIP Server: Please contact your SIP service provider to get the IP of the SIP server. -
Page 45: Terminal Setup
Configuration System Setup Terminal Setup CallerID: **** Phone No.: Bjiot3 Login Name ( ) Login Password ( ) Phone No.: Consult your SIP Service Provider for Phone No. Login Name/Login Password: Consult your SIP Service Provider. BVP 8759 User's Manual... -
Page 46: Ntp Setup
Using OSD menus Configuration System Setup NTP Setup Timer Zone: GMT 00:00 Daylight savings: OFF Time Zone: Please set the time zone according to the place you are using the phone. If there is daylight saving in your area, please set Daylight saving to ON. -
Page 47: Service Setup
When you are in a call and another call comes in, you will hear a reminding tone. Press to answer the call and switch between both. Audio Priority: There are four options: G.711UA,G.729 / G.711AU,G.729 / G.729,G.711UA / G.729,G.711AU. We recommend the default setting: G.711UA,G.729 BVP 8759 User's Manual... - Page 48 Using OSD menus Configuration Service Setup Call Service Setup Video: BVP 8759 can be used to make a video call. BVP 8759 can only be used to make a voice call. OFF:...
-
Page 49: Auto Answer Setup
Ringer: Auto Answer (ON/OFF): ON: BVP 8759 will automatically pick up the phone. If you set Auto Answer to ON but would like to retain security, please set a Password. The other party has to enter the password to establish the connection. -
Page 50: Advanced Setup
Taiwan/HK/China: Please set according to where you are using BVP 8759. Auto Provision (ON/OFF): When BVP 8759 is turned on and connected to the network, your SIP service provider will check the information of your BVP 8759, including user profile and firmware versions, and will update the firmware to the latest version. -
Page 51: Option
ON: In a video call, you can monitor the bandwidth of incoming and outgoing video. Language: English/Traditional Chinese/Simplified Chinese: Choose the language for the OSD Menu. Media Detection (ON/OFF): If you plan to keep BVP 8759 connected for a long period of time, please set to OFF. BVP 8759 User's Manual... -
Page 52: Bandwidth Setup
Using OSD menus Configuration Bandwidth Setup Bandwidth Setup Video Bandwidth: 1. 40 Kbps 2. 64 Kbps 3. 90 Kbps 4. 128 Kbps 5. 192 Kbps 6. 256 Kbps 7. 384 Kbps 8. 512 Kbps Please set the bandwidth according to the bandwidth your ISP provides. Note: Do not set the bandwidth to higher than what your ISP provides to avoid the instability of video quality. -
Page 53: Remote Update
Network software Update proceeding. Please wait. Note: If BVP 8759 has the same software version as the Update Server, the software will not be updated, and BVP 8759 will return to the standby screen. After the update is completed, BVP 8759 will automatically reboot. -
Page 54: Password
Using OSD menus Password : Item selection Old Password: Configuration New Password: Password Phonebook New Password Confirm: There will be a : move cursor number on the bottom left corner : backspace of the screen, indicating the current input mode. Change Password? Press button... -
Page 55: Phonebook
Press button to cycle through (numbers), (upper case letters), and Add This Record? (lower case letters) for your desired input mode. Yes <OK> No <CLEAR> Record Saved BVP 8759 User's Manual... -
Page 56: Search
Using OSD menus Phonebook Search Search for a number : Item selection Search In Box Out Box Speed Dial press **** to clear phonebook : move cursor : backspace There will be a number on the Searching by Name: bottom left corner of the screen, indicating the current input mode. -
Page 57: Phonebook Search
(upper case letters), and (lower case letters) for your desired input mode. If you can not dial out with BVP 8759, press the button to return to local Record updated view, and try to dial again. BVP 8759 User's Manual... - Page 58 Using OSD menus Phonebook Search Search for a number (cont'd) Delete the phonebook record Add the record to Speed Dial : Item selection : Item selection Dial Dial Edit Edit Delete Delete Add to Speed Dial Add to Speed Dial 0.
-
Page 59: In Box
Select a desired item and then press to dial out. Phone No. Domain Dialing... If you can not dial out with BVP 8759, please press the button to return to local view, and try to dial again. BVP 8759 User's Manual... -
Page 60: Out Box
Using OSD menus Phonebook Out Box OutBox contains the numbers of the 30 last dialed calls. : Item selection : Item selection Search Configuration In Box Password Out Box Phonebook Speed Dial press **** to clear phonebook Placed call: 2 of 2 Received call: 1 of 8 Phone:bjiot2 Phone:bjiot2... -
Page 61: Copyright Information
In local view screen, pressing "0000" will bring out a status screen with some information displayed, including the company name, copyright statement, and software version, including main s/w and LAN s/w. Copyright (c) 2001-2004 Leadtek Research Inc. 0000 All rights reserved. Local view VFAST 8759_LR Any key BVP 8759 User's Manual... -
Page 62: Restore Factory Settings
Using OSD menus Restore Factory Settings In local view screen, pressing "********" (eight asterisks) will bring out a dialog window, asking if you want to restore all settings to factory default (see below). Press to begin the process. Press to cancel. Restore all settings ******** to factory default? -
Page 63: Osd Menu Tree
OSD Menu Tree System Setup Configuration Network Setup Server Setup Terminal Setup NTP Setup Service Setup Call Service Setup Bandwidth Setup Auto Answer Setup Password Remote Update Advanced Setup Option Phonebook Search InBox OutBox Speed Dial BVP 8759 User's Manual... -
Page 64: Trouble Shooting
Trouble Shooting Your BVP 8759 is reliable and easy to use. If you encounter any problem while using this product, please refer to the table below for possible solutions. Power Indicator OFF Video of local view is dark Plug power adapter in the unit. -
Page 65: Tech Support
In the event of not finding the solution to your problem, please contact your local distributor. You may also contact our technical support staff; E-mail to <service@leadtek.com.tw> with the following information: Product name: It will be easier for our staff to answer your question if you know the name of the product. -
Page 66: Limited Warranty
Limited Warranty Leadtek warrants to the original purchaser of this product that it shall be free of defects resulting from workmanship or components for a period of one (1) year from the date of sale. Defects covered by this Limited Warranty shall be corrected either by repair or, at Leadtek's discretion by replacement. -
Page 67: Fcc Statement
Consult the dealer or an experienced radio/TV technician for help. Shielded interface cables must be used in order to comply with emission limits. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. BVP 8759 User's Manual...
