Video & Audio - Access - Sitecom LN-406 Manual

Rate
Access Code
Video Adjustments
Power Line
Frequency
White Balance
Brightness
Sharpness
Options
Microphone
Speaker
Time Stamp
Text Display
Video & Audio - Access
This screen is displayed when the Video Access option on the Video & Audio menu is
clicked.
User Access
Enable
Security
Checking
Enter the code for accessing the live video from camera through cell
phone connection.
Select the power line frequency (50Hz or 60Hz) used in your region,
to improve the picture quality under florescent lighting.
Select the desired option to match the current environment and
lighting.
If necessary, you can adjust the brightness to obtain a better image.
For example, if the camera is facing a bright light, the image may be
too dark. In this case, you can increase the brightness.
Select the desired option for the sharpness. You can select a
Sharpness value between -3 and 3.
Enable audio by checking this checkbox. Using Audio will increase the
bandwidth requirements slightly.
Enable speaker sound by checking this checkbox.
If enabled, the current time will be displayed on the Video image.
Enable this setting if you want text to be displayed on the Video
image, and enter the desired text - up to 20 characters. This feature
is often used to identify each camera when multiple cameras are
installed.
If disabled - No login required, users do not have to provide a
username and password when they connect to the camera to
view video.
If enabled - Require login, users will be prompted for a username
and password when they connect to the camera to view video.
