Product features may vary from the picture above.
L I M I T E D E D I T I O N M O T O R C Y C L E
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 74298
Tools needed for assembly: Phillips Screwdriver, Hammer and Safety Scissors (not included).
Use only with two Power Wheels
®
6 Volt Batteries with A-Style Connectors and Built-in Thermal Fuses,
and a Power Wheels
®
12 Volt Charger (all included).
Requires three size "AA" (LR6) alkaline batteries (not included) in Sound Box.
Advertisement
Table of Contents
Related Manuals for Power Wheels 74298
Summary of Contents for Power Wheels 74298
- Page 1 L I M I T E D E D I T I O N M O T O R C Y C L E Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74298 Tools needed for assembly: Phillips Screwdriver, Hammer and Safety Scissors (not included). Use only with two Power Wheels ®...
-
Page 2: Table Of Contents
Important Information ..............2 Warnings . -
Page 3: Warnings
• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the batteries, or help in assembly of the vehicle. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts Exhaust Pipe Set Left - Inner Half Right - Inner Half Right - Outer Half Left - Outer Half Front Fork Headlight - Rear Half Headlight - Front Half Seat Saddlebag - 2 Gas Tank Soundbox Fork Cover Battery Retainer...
- Page 6 Parts (Outer (Inner Half) Half) Right Left Shock Set - 2 Handlebar Set 6 Volt Battery - 2 Hex Bushing - 4 Round Bushing - 2 Axle Bushing - 2 Handgrips - 2 12-Volt Charger Not Shown: Label Sheet - 2 Bubble Cap Emblem #8 x "...
-
Page 7: Parts Diagram
Vehicle Frame Vehicle Body Seat Wheel - 2 Gas Tank Left Footboard Exhaust - Inner Half - 2 Exhaust - Outer Half - 2 (Left Shown) 6 Volt Battery - 2 Axle Bushing - 2 Hex Bushing - 4 Wheel Axle - 2 Parts Diagram Saddlebag - 2 Steering Bushing - 2... -
Page 8: Battery Charging
WARNING • The batteries must be handled by adults only. The batteries are heavy and contain sulfuric acid (electrolyte). Dropping the batteries could result in serious injury. • Never allow children to charge the batteries. Battery charging must be done by adults only. - Page 9 Battery Connector Slots Ribs Battery Connector • Align the ribs on the top of one of the battery connectors with the slots on the bottom of the other battery connector. • Stack the two battery connectors and press to join. Note: Make sure that the two connectors on the charger are also stacked and joined.
-
Page 10: Assembly
Rectangular Opening Square Opening High Speed Hook-Up • Pull firmly to separate the two black motor harness connectors near the rear of the vehicle frame. • Position the vehicle body on top of the vehicle frame. • Fit each motor harness connector up through the rectangular opening in the vehicle body, one at a time. - Page 11 Right Footboard • The right footboard was inserted in the vehicle frame and secured by one screw at the factory. • Insert a screw into the open hole in the right footboard. • Tighten the screw with a Phillips screwdriver. Do not over-tighten.
- Page 12 Right Exhaust Pipe • With the screw holes aligned, insert six screws to join the two halves of the right exhaust pipe. • Tighten the screws using a Phillips screwdriver. Do not over-tighten. • Repeat steps 6 through 9 to assemble the left exhaust pipe (L) to the left side of the vehicle.
-
Page 13: Rear View
Axle Bushing Groove Rear Fork Wheel (with Hex Busings) Rear View • Position the vehicle so that the back is facing you. • While holding the hex bushings in place, position the wheel between the rear fork arms of the vehicle frame. •... - Page 14 Headlight Assembly - Rear Half DO NOT INSERT SCREW HERE Headlight Assembly - Front Half • Fit the two halves of the headlight assembly together. • Insert three screws into the rear of the headlight “housing”, as shown (18a). • Turn the headlight assembly upright so the headlight “lens” faces you.
- Page 15 Front Fork • Slide the fork axle up into the bottom of the front fork, through the neck and steering stop, and out the top of the front fork. • Fit a .354 (small diameter) retainer on the end of the fork axle.
- Page 16 Arrow Handlebar Tabs • Position the vehicle upside down. • Note the arrow on the underside of the front fender. • Position the front fender so that the arrow points towards the front of the vehicle. Slide the fender onto the ends of the handlebars.
- Page 17 • Fit a round bushing, plate side first, onto the axle. Helpful Hint: You may need to push the shock outward slightly to fit the round bushing. • Continue to slide the axle through the shock. • Fit a .437 (large diameter) retainer on the end of the axle. •...
- Page 18 Gas Tank Tabs Vehicle Body • Balance the sound box on the vehicle body. (The speaker should face down.) • Fit the tabs at the bottom of the gas tank under the front end of the vehicle body. • Lower the gas tank on the vehicle frame, making sure that the two small square openings in the gas tank fit over the buttons on the sound box.
-
Page 19: Label Decoration
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... -
Page 20: Right Side
® ® ® LIMITED EDITION Chrome Bubble Cap Emblem* ® ® *Bubble cap emblem found in bag with Owner’s Manual. Label Decoration Chrome Right Side Chrome Left Side ® LIMITED EDITION Chrome ® ® ®... -
Page 21: Battery Installation
Important Note: Use only Power Wheels with A-style connectors and built-in thermal fuses. Power Wheels ® 6 volt batteries with external thermal fuses will not fit in the battery compartment of this vehicle. Use of any other batteries or fuses will damage your vehicle. -
Page 22: Battery Care And Disposal
Battery Care and Disposal Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. -
Page 23: Rules For Safe Driving
WARNING • Adult supervision is required. Children do not have the judgement necessary to avoid many accidents. Be sure that children operating this vehicle can do so safely and that they are supervised at all times. • Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or other bodies of water. -
Page 24: How To Operate Your Vehicle
As assembled, your vehicle is ready to roll in low speed (2 mph, maximum). When your child is ready to drive the vehicle in high speed (5 mph, maximum), follow the instructions to on page 25 connect the high speed hook-up. Beginner Use - Low Speed Drive •... -
Page 25: M Statement Of Limited Warranty
How to Operate Your Vehicle Advanced Use - High Speed Drive Connecting the High Speed Hook-up High Speed Hook-up Connectors • Remove the vehicle seat to access the high speed hook-up. • Plug the two high speed hook-up connectors together. Make sure the two connectors are completely joined. -
Page 26: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 5 PM (EST) Monday through Friday. Or, contact your local Power Wheels the Authorized Service Center list beginning on page 29. - Page 27 Problems and Solutions Guide Problem Vehicle was running but Tripped thermal fuse suddenly stopped (cont.) Short run time (Less than Undercharged batteries 1 - 3 hours per charge) Overcharged batteries Batteries are old and will not accept full charge Tripped thermal fuse Vehicle runs sluggishly Undercharged batteries Possible Cause...
- Page 28 Problems and Solutions Guide Problem Problem Vehicle runs sluggishly (cont.) Batteries need charging Batteries are old and will not accept accept full charge Vehicle is overloaded Driving conditions are too stressful Vehicle runs in low speed but High speed hook-up does not run in high speed not connected (Note: The vehicle is designed...
-
Page 29: Authorized Service Centers
Authorized Service Centers We are continually expanding our Authorized Service Center Network. Please check this listing for the Authorized Service Center nearest you. If there is not one in your area, please call Power Wheels ® Consumer Affairs at 1-800-348-0751. ALABAMA BIRMINGHAM - Frigid Appliance Center, 1861 Centerpoint Rd., 35215, (205) 853-3952... - Page 30 Authorized Service Centers IOWA BETTENDORF - K & K True Value Hardware, 1818 Grant Street, 52722, (319) 359-4473 CEDAR RAPIDS - Stalker Electric Inc., 110 3rd Ave. SW, 52404, (319) 364-5646 COUNCIL BLUFFS - Millard Television Inc., 1840 Madison Avenue, 51501, (712) 322-9552 DES MOINES - Quality Appliance Repair Center, 1417 Walnut Street, 50309, (515) 288-0108 DUBUQUE - Shavers Plus, 1824 Central Avenue, 52001,...
- Page 31 JACKSONVILLE - Discount Sales & Service, 468-B Western Blvd., 28546, (910) 455-6700 NORTH WILKESBORO - Appalachian Serv Center, 609 Elkin Hwy 268 East, 28659, (336) 667-5103 RALEIGH - Authorized Appliance Service Center, 800 North Person Street, 27604, (919) 834-3476 STATESVILLE - First Flight Bicycles, 216 S. Center St., 28677, (704) 878-9683 WILMINGTON - American Tool &...
- Page 32 Harley-Davidson ® . All Rights Reserved. Manufactured by Fisher-Price under license from Harley-Davidson Motor Company. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©1999 Mattel, Inc. All Rights Reserved. Fisher-Price, Power Wheels and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc.
