service (service/Internet application) port number from the Internet that will
be re-directed to the above Private IP address host in your LAN
Comment The description of this setting.
Add Virtual Server Fill in the "Private IP", "Private Port", "Type", "Public
Port" and "Comment" of the setting to be added and then click "Add". Then
this Virtual Server setting will be added into the "Current Virtual Server Table"
below.
Remove Virtual Server If you want to remove Virtual Server settings from
the "Current Virtual Server Table", select the Virtual Server settings you want
to remove in the table and then click "Delete Selected". If you want to
remove all Virtual Server settings from the table, just click the "Delete All"
button. Click "Reset" will clear your current selections.
Click <Apply> at the bottom of the screen to save the above configurations.
43
