2.1.4 LEDs and Reset Button

The LEDs are explained in the following tables.
LED
WLAN Act
WLAN Link
Power
LED
Link/Act
FULL/COL
100 Orange
LED
Link
Act
Diag
Table 2-1 WAN Status LED Functionality
Color
Green Lights to indicate the router is activated.
Lights to indicate that the Router's wireless functions
Green
have been enabled through the Web-based utility.
Green
Lights to indicate the router has power.
Table 2-2 10/100 Port Status LED Functionality
Color
Lights to indicate a functional network link through the
corresponding port with an attached device.
Green
Blinks to indicate that the router is actively sending or
receiving data over that port.
Lights to indicate that the connection made through
the corresponding port is running in Full Duplex mode.
Green
Blinks periodically to indicate that the connection is
experiencing collisions.
Lights for any port to indicate that the port is operating
at 100 Mbps.
Off to indicate that the port is operating at 10 Mbps
while the network is still operating.
Table 2-3 Internet LED Functionality
Color
Lights to indicate a successful connection between
Green
the Router and your broadband device or network.
Blinks to indicate that the Router is sending or
Green
receiving data over the broadband (Internet) port.
Lights to indicate the Router's self-diagnosis mode is
Red running during boot-up and restart. It will turn off when
completing the diagnosis.
