2.1.5 Rear Panel

The rear panel of the router has one Reset button at the left. At the right area are the
Internet and LAN ports and a power connector. Figure 2-3, Figure 2-4, and Figure 2-5
shows rear panels of these routers. Table 2-4 explains the function of the port.
Figure 2-3 Rear panel of the Wireless Access Point Router
PCMCIA Slot
Figure 2-4 Rear panel of the Wireless Access Point Router with
Figure 2-5 Front panel of Wireless Access Point Router
Port
Reset
LAN port
Internet port
PCMCIA slot
DC Input Port
with One Optional PCMCIA Card
Reset Button Internet & LAN Ports
Fixed Antenna and one Reverse SMA Antenna
with Built-in PCMCIA and One Antenna
Table 2-4 All Port Functionality
Pressing the Reset button for more than 3 seconds to
restore to the factory default setting.
This is where you connect to the PC.
This is where you connect to the Cable/DSL modem.
This is where you connect to the PCMCIA adapter.
To connect the adapter to receive power.
Wireless Acccess Point Router
Uplink/Normal Switch
Function
9
DC Input Port
