Care and Use Manual
Installation Instructions
Installer:
Owner:
WARNING: If the information in this manual is not followed exactly, a fire or
!
explosion may result causing property damage, personal injury or death.
AVERTISSEMENT: Si l'information dans ce manuel n'est pas suivie
!
exactement, une incendie ou une explosion peut résulter, entrainant des
dégats matériels, des blessures ou la mort.
Thermador Char Glo
Outdoor Barbecues
Models:
CGB30CZLP • CGB36FZLP
CGB48FZLP • CGB48FSZLP
Please leave these instructions with the unit for the owner.
Please retain these instructions for future reference.
for
®
Advertisement
Table of Contents
Related Manuals for Thermador CGB30CZLP
Summary of Contents for Thermador CGB30CZLP
-
Page 1: Installation Instructions
Installation Instructions ® Thermador Char Glo Outdoor Barbecues Models: CGB30CZLP • CGB36FZLP CGB48FZLP • CGB48FSZLP Installer: Please leave these instructions with the unit for the owner. Owner: Please retain these instructions for future reference. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. -
Page 2: Table Of Contents
Contents SECTION 1: Safety Information ..............1 SECTION 2: Gas Requirements ............2 – 3 Natural Gas Requirements ................2 Propane Gas Requirements ................. 2 Gas Consumption ..................2 Propane Hook-up ..................2 Important Gas Supply and Installation Information........ 3 SECTION 3: Electrical Cautions .............. -
Page 3: Section 1: Safety Information
SECTION 1: SAFETY INFORMATION FOR YOUR SAFETY AVERTISSEMENT If you smell gas: S’il y a une odeur de gaz: 1. Shut off gas to the appliance. 1. Coupez l’admission de gaz de l’appariel. 2. Extinguish any open flame. 2. Ènteindre toute flamme nue. 3. -
Page 4: Section 2: Gas Requirements
PROPANE HOOK-UP Tank Gas Regulator Gas Hose Figure 1 LP Gas Tank GAS CONSUMPTION ® The total gas consumption of the Thermador Char Glo barbecues with all burners on "HI" is as follows: CGB30RFZLP = 52,000 BTU/Hr CGB36FZLP = 77,000... -
Page 5: Important Gas Supply And Installation Information
SECTION 2: GAS REQUIREMENTS For Massachusetts Installations: 1. Shut-off valve must be a “T” handle gas cock. 2. Flexible gas connector must not be longer than 36 inches. 3. Not approved for installation in a bedroom or a bathroom unless unit is direct vent. CAUTION: The appliance and its individual shut-off valve must be disconnected from the gas supply before any pressure testing of the system at test pressures in... -
Page 6: Electrical Cautions
In the absence of local codes or ordinances, the supply should be installed in accordance with the National Electric Code ANSI/NFPA No. 70, current issue, or Canadian Electric Code C22.1 Part 1. The Thermador Char Glo ® barbecues use an electronic ignition system that requires a 120 VAC, 15A, 60 Hz power supply. -
Page 7: Section 4: Unpacking, Moving And Placing The Unit
See conversion instructions below. ONVERSION IT BY ODEL Model No. Orifice Description Part Number Quantity Remarks CGB30CZLP 2.06mm (#46) Orifice Hood, Grill Burner 5040000445 To Convert LP To NG 1.40mm (#53) Orifice Hood, Infrared Burner 5040000443 Conversion Sticker 5040000623 CGB36FZLP 2.06mm (#46) Orifice Hood, Grill Burner... - Page 8 SECTION 4: UNPACKING, MOVING AND PLACING THE UNIT (EXAMPLE) 9. On all models, the bypass jet must be turned counterclockwise with a small flat-bladed screwdriver 1 to 1 turns to set proper low flow rate. See Figures 4 and 5. 10.
-
Page 9: Gas And Electrical Hook-Up
SECTION 4: UNPACKING, MOVING AND PLACING THE UNIT and tighten the nuts that retain the burners at A regulator can also be purchased locally the rear of the burner box. Reinstall the cover provided it meets the following on the infrared burner housing. Connect the specifications: unit to the electrical supply. -
Page 10: Section 5: Test And Adjustment
SECTION 5: TEST AND ADJUSTMENT MUST BE DONE BY A QUALIFIED INSTALLER CHECKING FOR LEAKS All points of connection to the gas supply should be manifold. Bubbles will form where a leak exists. checked for leaks anytime you smell gas. It is also C. - Page 11 NOTES...
- Page 12 Thermador reserves the right to change specifications or design without notice. Some models are certified for use in Canada. Thermador is not responsible for products which are transported from the United States for use in Canada. Check with your local Canadian distributor or dealer. Thermador, 5551 McFadden Avenue, Huntington Beach, CA 92649.
