Summary of Contents for Makita BDF442
- Page 1 INSTRUCTION MANUAL Cordless Driver Drill BDF442 BDF452 007698 WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
The tool is intended for drilling and screw driving in wood, We declare under our sole responsibility that this metal and plastic. product is in compliance with the following standards of For Model BDF442 standardized documents; ENG101-1 For European countries only... -
Page 3: General Safety Rules
GEA002-3 reduce personal injuries. Avoid accidental starting. Ensure the switch is GENERAL SAFETY RULES in the off-position before plugging in. Carrying WARNING! Read all instructions. Failure to follow all power tools with your finger on the switch or instructions listed below may result in electric shock, fire plugging in power tools that have the switch on and/or serious injury. -
Page 4: Specific Safety Rules
tool, taking into account the working conditions Keep hands away from rotating parts. and the work to be performed. Use of the power Do not leave the tool running. Operate the tool tool for operations different from those intended only when hand-held. could result in a hazardous situation. -
Page 5: Switch Action
Be careful not to drop or strike battery. Switch action 1. Switch trigger SAVE THESE INSTRUCTIONS. Tips for maintaining maximum battery life Charge the battery cartridge before completely discharged. Always stop tool operation and charge the battery cartridge when you notice less tool power. -
Page 6: Reversing Switch Action
Reversing switch action Adjusting the fastening torque 1. Reversing 1. Adjusting ring switch lever 2. Graduation 3. Pointer 007421 007423 This tool has a reversing switch to change the direction The fastening torque can be adjusted in 17 steps by of rotation. -
Page 7: Screwdriving Operation
Installing bit holder (Optional accessory) Screwdriving operation 1. Bit holder 2. Bit 007700 007702 Fit the bit holder into the protrusion at the tool foot on CAUTION: either right or left side and secure it with a screw. Adjust the adjusting ring to the proper torque level •... -
Page 8: Maintenance
Drilling in metal 1. Rear cover To prevent the bit from slipping when starting a hole, 2. Screws make an indentation with a center-punch and hammer at the point to be drilled. Place the point of the bit in the indentation and start drilling. - Page 9 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Drill bits • Screw bits • Bit holder •...
- Page 12 Makita Corporation Anjo, Aichi, Japan 884679B229...
