1-3/4 HP PLUNGE
ROUTER WITH BRAKE
OPERATING INSTRUCTIONS
Visit our Web site at http://www.harborfreight.com
Copyright © 2000 by Harbor Freight Tools
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions please call 1-800-444-3353
3491 Mission Oaks Blvd., Camarillo, CA 93011
43585
®
. All rights reserved. No portion of this
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chicago Electric 43585
Summary of Contents for Chicago Electric 43585
-
Page 1: Operating Instructions
Visit our Web site at http://www.harborfreight.com Copyright © 2000 by Harbor Freight Tools manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions please call 1-800-444-3353 43585 ®... -
Page 2: Specifications
USE EYE PROTECTION. Wear ANSI-approved safety impact eye goggles. ANSI- approved safety impact goggles are available from Harbor Freight Tools. DRESS SAFELY. Do not wear loose clothing or jewelry as they can become caught in moving parts. Wear a protective hair covering to prevent long hair from becoming caught in the moving parts. - Page 3 REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical replacement parts. Only use accessories intended for use with this product. Approved accessories are available from Harbor Freight Tools. MAINTAIN THIS PRODUCT WITH CARE. Keep this product clean and dry, moving parts lightly lubricated, and router bits sharp for better and safer performance.
-
Page 4: Specific Product Warnings And Precautions
WARNING: Under no circumstance is the Router base ever to be removed from the Router in order to use bits that are too large to use with the base assembly attached. The removal of the Router base and using the Router “Free Hand” can... - Page 5 When unpacking, check to make sure all parts shown on the Par ts List (page 11 and 12) are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
- Page 6 Loosen the Knob (part #46). Adjust the Stopper Pole (part #45) and the Stopper Block (part #32) to obtain the required cutting depth. Then, retighten the Knob. Check to make sure that, even if released with the Lock Lever, the Router stops at the determined depth for repeated cuts. (Figure B) Minute depth adjustments can be made by raising or lowering the Stopper Pole.
- Page 7 Insert the two bars of the Bar Holder Assembly fully into the Base Plate, and securely tighten the two Wing Nuts (part #84). (Figure E) Fine Adjust the desired distance from the Router Bit to the edge of the Straight Guide by turning the Feed Screw (part #70). When the desired distance is deter- mined, securely tighten the Wing Bolt (part #66) located on the Bar Holder Assembly (part #69).
- Page 8 The template should also have openings large enough to admit the Router Bit and the Template Guide. Secure the Template Guide (part #65) to the Base of the Router with the two accessory Machine Screws (part #67). Make sure the projected side of the Tem- plate Guide is facing the bottom surface of the Base of the Router.
- Page 9 After measuring and setting the desired distance from Bit cutting depth to edge of workpiece, carefully follow the edge of the workpiece as shown. (Figure K) 74/75 74/75 SKU 43585 For technical questions, please call 1-800-444-3353. Figure I Figure J...
-
Page 10: Maintenance
The Router Bit rotates clockwise. Therefore, you should adjust for this while cutting. For most materials it is best to move the Router from left to right as you face the workpiece. When cutting outside edges, move the Router counterclockwise. When cutting inside edges, move the Router clockwise. -
Page 11: Parts List
ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACE- MENT PARTS THERETO. SKU 43585 For technical questions, please call 1-800-444-3353. PARTS LIST... -
Page 12: Assembly Diagram
ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. REV 01/05 SKU 43585 For technical questions, please call 1-800-444-3353. Page 12...
