- Page 1 Model No. TH-65PB1E Operating Instructions Electronic Pen Operations Interactive Plasma Display Please read these instructions before operating your set English and retain them for future reference.
- Page 2 Introduction Abbreviations ® ® ® Windows refers to the Microsoft Windows operating system. ® ® ® Windows XP refers to the Microsoft Windows XP operating system. ® ® ® Windows Vista refers to the Microsoft Windows Vista operating system. ® ®...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Safety Precautions..................4 Requests regarding handling..............6 Accessories Supplied................7 Names and Uses of the Parts..............8 Preparation ....................10 Operation ....................13 About software ..................15 Additional Information................16 Specifications ..................18... -
Page 4: Safety Precautions
Safety Precautions For Your Safety WARNING Operating Safeguards Electronic Pen Do not alter the unit or modify any parts. Alteration or Do not use near medical equipment. modification can cause fire or electric shock. (Do not bring into a surgery room, intensive care unit, critical care unit, etc.) Electromagnetic waves generated by this device can Choking Hazard... -
Page 5: Other Information
Precautions Other Information Usage Note Any changes or modifications not expressly approved by the party responsible for compliance could void the Operating the electronic pen and the electronic user’s authority to operate this device. pen adapter near electrical appliances may cause interference. -
Page 6: Requests Regarding Handling
Requests regarding handling • Do not push down hard on the Pen tip. • If there is surface contamination of the electronic pen, wipe it off with a soft cloth. For heavy contamination, wipe it off with a soft cloth dampened with a mild soap solution after squeezing water out of the cloth, and then dry the surface with a soft, dry cloth. -
Page 7: Accessories Supplied
Accessories Supplied Usage Check that all of the following items are included with your Interactive Plasma Display. In the event that an item is missing, please contact your dealer. List of Accessories (Electronic Pen set) Rechargeable AAA Ni-MH Recharger Cable (2m) Electronic Pen Adapter Battery* N5EDZ0000006... -
Page 8: Names And Uses Of The Parts
Names and Uses of the Parts 1 Light receiving window 2 Pen tip In the electronic pen mode, you can draw by touching the screen with it. In the mouse mode, touching with it functions as a “left button of mouse”. Touching and holding with it in the mouse mode functions as a “right-click of mouse”. -
Page 9: Power Indicator
; Power indicator Lights green when the power of the electronic pen is “on”. Blinks green when the battery of the electronic pen is low. Lights red during charging and turns off when charging is completed. Blinks red when no rechargeable battery is in during charging or when an incompatible battery is used. Power indicator Operation state Power “off”... -
Page 10: Preparation
Preparation Inserting (Replacing) Batteries Unlock the battery cover ( 1 ), Insert (replace) the battery, and then and open the cover ( 2 ). reattach the cover and lock it. • • Make sure to use a rechargeable AAA Ni-MH When replacing the cover, follow the procedure in battery or a AAA alkaline battery (LR03), and reverse. - Page 11 Charging After purchase, charge the electronic pen before use. • Charging is not necessary for an AAA alkaline battery. Connect the recharger port of the electronic pen to the USB port of the computer with the included recharger cable. • The power indicator lights red and charging starts.
- Page 12 Restart your computer if you are prompted to do • The group [elite Panaboard] will be created in the [Panasonic] group in the program menu. • The following items will appear in the [elite Panaboard] group (A function that you deselected on the “Select Features”...
-
Page 13: Operation
Operation After finishing preparation of the electronic pen and installation of the software, make settings and connections according to the following procedure. 1. Connect a computer to the Interactive Plasma Display For connection of a computer and the Interactive Plasma Display, see Display Operations of the operating instructions. - Page 14 • You can also start up elite Panaboard software in either of the following procedures. a. From the Start menu of Windows, point to [All Programs] → [Panasonic] → [elite Panaboard] and click [elite Panaboard software]. b. Click the desktop icon of to start up.
-
Page 15: About Software
Turn on your computer and start Windows. On the Start menu, point to [All Programs] → Open “Software Help” from the Start menu. ([Start] → [All Programs] → [Panasonic] → [Panasonic] → [elite Panaboard] → [Interactive [elite Panaboard] → [Interactive Plasma Plasma Display], and click [Download the latest Display] →... -
Page 16: Additional Information
Additional Information Replacing the pen tip of the Electronic Pen As the pen tip of the electronic pen becomes worn, the pen tip will no longer slide easily across the screen. Continuing to use the electronic pen in this condition may make the screen dirty and cause malfunction. Replace the pen tip with a new one as soon as possible. - Page 17 Troubleshooting When experiencing problems, please refer to the table below for possible solutions. If the problem persists, contact your dealer. Symptom Possible cause and solution See page No rechargeable battery is in during charging or a battery The power indicator 9, 10 incompatible with this electronic pen is charged blinks red...
-
Page 18: Specifications
Specifications Type Electronic pen Transmission system 2.4 GHz radio transmission Power source Rechargeable AAA Ni-MH battery × 1 or AAA alkaline battery (LR03) × 1 External dimensions (L × H) 198.5 mm × 22.1 mm Weight Approx. 40 g (including the included rechargeable battery) Operation time Approx. - Page 19 Interactive Plasma Display Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this display is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC, Directive 2004/108/EC, Directive 2006/95/EC and Council recommendation 1999/519/EC.” If you want to get a copy of the original DoC of this display, please visit the following website: http://www.doc.panasonic.de...
