11265 Battery Charger UK.fm Seite 2 Montag, 7. Mai 2007 12:32 12 DESCRIPTION OF PARTS Charger Fixing holes Network cable with plug Plus pole terminal (red), with connection cable Minus pole terminal (black), with connection cable Button MODE LED “Mode 1”...
11265 Battery Charger UK.fm Seite 4 Montag, 7. Mai 2007 12:32 12 SAFETY INSTRUCTIONS Read these operating instructions carefully before using the appliance for the first time. Note the warnings on the appliance and in the operating instructions. Always keep the operating instructions close to hand. If you sell the appliance or give it away, please ensure that you also pass on these instructions.
11265 Battery Charger UK.fm Seite 5 Montag, 7. Mai 2007 12:32 12 FAULTS • If damage occurs to the mains cable, charger or connection cable, immediately pull the mains plug from the socket. • Never try to open and/or repair the appliance yourself.
11265 Battery Charger UK.fm Seite 6 Montag, 7. Mai 2007 12:32 12 PROTECT YOURSELF FROM AN ELECTRICAL SHOCK! • Only use the charger for 6 V or 12 V rechargeable lead batteries (batteries) with an electrolyte solution or gel! • For a battery that is firmly fixed in the vehicle ensure that the vehicle is out of use and is at a protected standstill! Switch the ignition off and put the vehicle into park, e.
11265 Battery Charger UK.fm Seite 7 Montag, 7. Mai 2007 12:32 12 HANDLING RECHARGEABLE BATTERIES • Do not use the charging and maintenance process on batteries that can not be recharged. • Do not use frozen rechargeable batteries! • Do not use damaged or corroded rechargeable batteries.
Page 7
11265 Battery Charger UK.fm Seite 8 Montag, 7. Mai 2007 12:32 12 • Remove the leaking battery liquid with a dry, absorbent cloth and avoid contact with skin by, for example using protective gloves that withstand acid. • At all times observe the plus (+) and minus ( ) signs on the cells, batteries and appliances.
11265 Battery Charger UK.fm Seite 9 Montag, 7. Mai 2007 12:32 12 ABOUT THIS APPLIANCE PROPER USE This appliance is a primary side switched charging appliance with pulse maintenance charging. It is suitable for charging and maintaining the charge of the following rechargeable 6 V or 12 V lead batteries with an electrolyte solution or gel: •...
11265 Battery Charger UK.fm Seite 10 Montag, 7. Mai 2007 12:32 12 SCOPE OF DELIVERY UNPACKING THE APPLIANCE • Remove all packing materials. WARNING. Do not let children or babies play with the plastic wrapping. There is a risk of suffocation.
11265 Battery Charger UK.fm Seite 11 Montag, 7. Mai 2007 12:32 12 OPERATION LED DISPLAYS The following LEDS may light up during operation: Mode STANDBY mode Mode 1: Charging process 6 V battery Mode 2: Charging process Motor cycle battery...
11265 Battery Charger UK.fm Seite 12 Montag, 7. Mai 2007 12:32 12 CONNECT CHARGER TO BATTERY WARNING. Before assembly and maintenance work and before cleaning the appliance always detach it from the mains power supply! NOTE: Before disconnecting a car or motor bike battery first get advice from the vehicle’s instruction manual on the...
11265 Battery Charger UK.fm Seite 13 Montag, 7. Mai 2007 12:32 12 SELECT CHARGING MODE Select a charging mode depending on the battery type and environmental temperature. You can also recharge a completely discharged battery (“regeneration”). The charger’s electronics do not start the charging process directly after connecting the battery but rather only after a charging mode has been selected.
Page 13
11265 Battery Charger UK.fm Seite 14 Montag, 7. Mai 2007 12:32 12 the complete charging process until the battery is charged to around 7.3 V. • When the battery is fully charged the LED goes out and LED lights up. Maintenance charging takes place in this status.
Page 14
11265 Battery Charger UK.fm Seite 15 Montag, 7. Mai 2007 12:32 12 the complete charging process until the battery is charged to around 14.4 V. • When the battery is fully charged the LED goes out and LED lights up. Maintenance charging takes place in this status.
11265 Battery Charger UK.fm Seite 16 Montag, 7. Mai 2007 12:32 12 for a regular charging mode. The appliance then switches automatically to an appropriate charging mode and continues the charging. APPLIANCE PROTECTION FUNCTION The appliance is protected against improper use. If there is a...
11265 Battery Charger UK.fm Seite 17 Montag, 7. Mai 2007 12:32 12 • Detach the plus pole terminal (red) from the battery’s plus pole. • Reconnect the vehicle’s plus pole connection cable to the battery’s plus pole. • Reconnect the vehicle’s minus pole connection cable to the battery’s minus pole.
11265 Battery Charger UK.fm Seite 18 Montag, 7. Mai 2007 12:32 12 CLEANING AND CARE • Before cleaning, remove the plug from the mains socket. Use a dry, soft cloth to clean the appliance. Avoid the use of chemical solutions and cleaning products because these may damage the appliance surface and/or markings.
11265 Battery Charger UK.fm Seite 19 Montag, 7. Mai 2007 12:32 12 TECHNICAL DATA Input: 220 240 V ~ 50/60 Hz; 60 W Output for batteries with measurement voltages: 6 V or 12 V Charging power approx. 0.8 A/3.8 A (12 V) approx.
11265 Battery Charger UK.fm Seite 20 Montag, 7. Mai 2007 12:32 12 DISPOSAL Appliance At the end of its life, the battery charger should not be disposed of in household rubbish. Seek the advice of your local authority on correct, environmentally friendly disposal.
