Front View; Left Side; Right Side - Medion Notebook Manual

Front View

9 - Display catch ........................................... (
10 - Microphone connector ................................ (
11 - Audio In connector ..................................... (
12 - Audio Out / S/PDIF connector ..................... (

Left Side

13
13 - External monitor port VGA
14 - Modem port (RJ-11) (optional) ..................... (
15 - LAN port (RJ-45) ........................................ (
16 - PCI Express port ........................................ (

Right Side

17 - Optical Drive
18 - USB Port .................................................. (
9
10 11 12
........................ (
........................................... (
Views of the Notebook
14 15 16
17
p. 32)
p. 46)
p. 46)
p. 46)
p. 34)
p. 48)
p. 48)
p. 55)
18
p. 41)
p. 56)
15
