Problems
Is the power cable con-
System will not nected to the rear?
power ON Have you pushed the ON
No image on Is there power to the sys-
the screen
Turn off the power switch
and plug the DMP back in.
Turn on the power wait for
the DMP to initialise.
The DMP was Remove the paper tray an
unplugged dur- open the paper jam doors;
ing printing remove any paper from
inside the DMP. Under cer-
tain circumstances the ther-
mal print head may require
cleaning (see below)
The paper Is the photo paper loaded
ejected with no glossy surface up?
image printed Is the correct paper used?
The photo
Clean the thermal print
printed with
a hairline
scratch
To reset the Auto focus
press and hold the Auto
focus (1a) for 3 seconds.
Drive the Zoom to the Wide
Auto focus position using the Zoom-W
does not work button (1b). Press and hold
the Zoom-W button (1b)
once it has reached the
Wide position for 1 second.
Then press Auto Focus
Note: If an electro-static discharge event
locks the DMP, turn the DMP off and on to
restore it's normal function.
Solution
switch?
tem?
head.
Or
(1a).

5.2 Clearing a Paper jam

a Switch off the DMP and unplug the power
lead
b Pull the paper tray out the front of the
DMP
c Slide the tray top cover off as shown (18).
If the paper is not accessible proceed to
(d), otherwise proceed to (e).
d Turn the DMP upside down and remove
the bottom covers as shown (20).
e Remove the jammed paper.
f Replace the covers and turn the DMP the
correct way up.

5.3 Cleaning the Thermal print head

The print head of the DMP should be cleaned
at least once a year to avoid any excessive
builds up of dirt/debris, or if lines appear on
the print. To clean the print head:
a Ensure the DMP is switched off and unplug
the power lead. Wait for 5 minutes.
b Remove the ribbon cassette from the DMP.
c Turn the DMP upside down and remove
the bottom cover as shown in "Clearing a
Paper Jam" (21).
d Use cotton sticks with an alcohol-based
solvent to clean the brown heating line of
the thermal print head making strokes from
right to left (22).
Note: The cotton sticks should be applied
gently to avoid damaging the print head.
e Replace the cover and turn the DMP the
correct way up.

5.4 Cleaning the feed roller

Handling of the feed roller should be
avoided at all times. Contamination on the
feed roller leaves "tread" marks on finished
prints. If you see "tread" mark patterns on
your prints you should follow the proce-
dure laid out below:
a Ensure the DMP is switched off and unplug
the power lead. Wait for 5 minutes.
