Model ST6000 User Guide
TUNER

Advertisement

Table of Contents
loading

Related Manuals for Marantz ST6000

Summary of Contents for Marantz ST6000

  • Page 1 Model ST6000 User Guide TUNER...
  • Page 2 NEDERLANDS täcks av garantin. Ditt kvitto eller faktura är ett giltigt inköpsbevis. GARANTIE DANSK Neem contact op met de Marantz distributeurs in uw buurt voor informatie over de garantie. GARANTI BEWAAR UW REçu ALS AANK OOPBEWIJS. Bed din Marantz-forhandler om oplysninger om garantien.
  • Page 3 SI DICHIARA CHE L’APPARECCHIO SINTONIZZATORE ST-59 RISPONDE ALLE PRESCRIZIONI DELL’ART. 2 COMMA 1 DEL D.M. 28 AGOSTO 1995. N . 548. FATTO A EINDHOVEN, IL 1/1/1996. MARANTZ EUROPE B.V. 5600 EINDHOVEN THE NETHERLANDS “Este aparato lleva elementos antiparasitarios necesarios para cumplir con los limites que se estableren en el Anexo V del Reglamento sobre Pertubaciones Radioelectricas e Interferencias aprobado en el Real Decreto 148/1989.
  • Page 4 FOREWORD INTRODUCTION Be sure to read this section before any connection to the mains supply. Thank you for selecting the Marantz ST6000 FM/AM Stereo Tuner for your system. Please read these operating instructions carefully. We recommend that WARNINGS you read the entire user guide before you attempt to connect or operate the Tuner.
  • Page 5 LOCATION AND FUNCTION OF PARTS AND CONTROLS FRONT PANEL FEATURES (SEE APPEARANCE DRAWING) q q q q q ! 5 ! 5 ! 5 ! 5 ! 5 POWER ON /STANDBY button RDS button This button is used to power on or power standby. When the FM RDS broadcasting is displayed, and it retrieves, this button is operated.
  • Page 6 OPERATIONS 3. FINE, MANUAL TUNING This function used for selection the manual tuning of the fine tuning 1. MEMORY PRESETTING mode. Fine tuning mode is available only in the FM mode. a. Manual operation Press the TUNING MODE button. For example: presetting FM 90.1 M Hz, to Preset number. 10 Every time you press this button, the following will be displayed Select the FM by using the BAND button.
  • Page 7 Daily timer 6. FILING (STATION NAME, ETC. ) Example: presetting ON time: 7:15 OFF time: 9:30 For example: FM 98.8 MHz Preset CH-10 Station name BBC1 Press the TIMER SET button. Select the preset number 10 in the preset mode. DAILY PRESET Preset the ON time by the TUNING 5...
  • Page 8 7. RDS (RADIO DATA SYSTEM) 8. RDS DISPLAY What is RDS? Select the FM band. RDS can be received only in FM. RDS provides such indication as station names, local times, and the 5 button. Select the RDS broadcasting by using the TUNING types of program, the radio text ,etc.

  • Page 9: Troubleshooting Guide

    The memory funcitons are backed up for up to about one week. SURFACES The exterior finish of your ST6000 will last indefinitely with proper care and cleaning. Never use scouring pads, steel wool, scouring powders or harsh chemical agents (e.g., lye solution), alxohol, thinners, benzine, insecticide or other volatile substances as these will mar the finish of the equipment.

  • Page 10: Specifications

    SPECIFICATIONS FM section Frequency range ......................... 87.5 MHz to 108.0 MHz 50 kHz steps: Manual mode (10 kHz steps: Fine mode) Sensitivity (S/N: 30 dB) ............................1.2 V Total harmonic distortion (1 kHz) Mono ................................0.08 % Stereo ................................0.15 % Signal to Noise ratio Mono: ................................

  • Page 11: Before Use

    FIGURES BEFORE USE CAUTION:Do not plug the power cord of any component into AC outlets and do not turn their POWER switches on until connections have been performed. Roof-top FM Antenna(75 ohms) Matching Transformer (optional) Lead-type FM Antenna(75 (provided) AM(MW)Outdoor Antenna 5 to 12m AM(MW)Indoor Loop Antenna (provided)

  • Page 12: Controls And Functions

    CONTROLS AND FUNCTIONS T U N E R S T 6 0 0 0 DOWN PRESET ON/OFF TIMER SET TIMER DAILY ONCE TUNED STEREO PT TP TA AUTO MEMO PRESET STANDBY WIDE NARROW ST.NAME TUNING POWER ON/STAMDBY ANTETTA IF BAND TIME ADJ.
  • Page 13 P.O. Box 685, Bell Village, Port Louis, Mauritius NETHERLANDS Marantz Trading A division of Marantz Europe B.V., Building SFF-2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands NEW ZEALAND Scan audio Pty. Ltd. 4 Station Street, Thornleigh NSW 2120, Australia...
