TX-P42U30B TX-P50U30B Operating Instructions Plasma Television Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only. English...
Page 2
Features DVB-T tuner built-in Receives DVB (Digital Video Broadcasting) digital terrestrial broadcasts. DVB-T2 tuner built-in DVB-T2 is an advanced digital terrestrial system for more efficient transmission. Available DVB-T2 broadcasts will be tuned automatically when you perform DVB Auto Setup. GUIDE Plus+ (p. 18) This TV supports the TV Guide services sent from the GUIDE Plus+ system.
On screen messages ····························································· 74 Notice for DVB functions Glossary····················································································· 76 The compatibility with future services is not guaranteed. Check the latest information on the available services at the Maintenance ··········································································· 77 following website. Licence ······················································································ 77 http://panasonic.jp/support/global/cs/tv/ Index ·························································································· 78 Specifications ·········································································· 79...
Safety Precautions Warning ■ Mains plug and lead To help avoid risk of electrical shock, fire, damage or injury, please follow the warnings below: • This TV is designed to operate on AC 220-240 V, 50 / 60 Hz. • Insert the mains plug fully into the socket outlet.
Page 5
Do not insert foreign objects into the TV through the air vents. • Do not use an unapproved pedestal / mounting equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved wall-hanging brackets.
Accessories may not be placed all together. Take care not to throw them away unintentionally. Optional accessories Please contact your nearest Panasonic dealer to purchase the recommended optional accessories. For additional details, please refer to the manual of the optional accessories.
Page 7
• Do not use any pedestal other than the one provided with this TV. • Do not use the pedestal if it becomes warped or physically damaged. If this occurs, contact your nearest Panasonic dealer immediately. • During setup, make sure that all screws are securely tightened.
Changes the input mode SD Card slot (p. 51) Headphones jack (p. 67) Mains power On / Off switch • Use to switch the mains power. If you turned the TV Off during Standby mode by the remote control last time, the TV will be in Standby mode when you turn the TV On with Mains power On / Off switch.
Basic Connection External equipment and cables shown are not supplied with this TV. Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. When disconnecting the mains lead, be absolutely sure to disconnect the mains plug at the socket outlet first. Example 1 Example 2 Connecting aerial...
Page 11
Example 3 Connecting DVD Recorder / VCR and Satellite receiver TV, DVD Recorder / VCR and Satellite Mains Lead Rear of the TV Make sure that the mains lead is securely fixed. Push until both side tabs click To remove from the TV : AC 220-240 V 50 / 60 Hz tabs...
Auto Setup Search and store TV channels automatically. • These steps are not necessary if the setup has been completed by your local dealer. • Please complete connections (p. 10, 11) and settings (if necessary) of the connected equipment before starting Auto Setup. For details of settings for the connected equipment, read the appropriate manual.
Page 13
■ How to input Owner ID Enter the PIN number (4 digits) • Enter the PIN number twice at first setting. Owner ID Please enter new PIN pqrs wxyz * * * Select the item (NAME / HOUSE NO / POSTCODE) select Owner ID-Data Entry NAME...
Watching TV Turn power on • INPUT SD CARD Press for about 1 second • Mains power On / Off switch should be On. (p. 9) MENU ASPECT DIRECT TV REC Select DVB or Analogue EXIT • Also possible to select the mode pressing the TV button on the side panel of the TV.
Other useful functions Display Information banner Display Information banner • Also appears when changing a channel Example : DVB 1 BBC ONE WALES All DVB Channels Radio 19:50 Also in Select favourites Coronation Street For info press 19:30 - 20:00 Mute Encrypted STTL...
Hold Freeze / unfreeze picture HOLD Display the selectable settings for the current status Check or change the current status instantly • To change OPTION select change [Subtitle Language] [Audio Description] (DVB mode) (DVB mode) Allows you to select the language in which subtitles should Set to [Auto] if the programme has Audio Description service, appear (if available) •...
Aspect Change the aspect ratio (image size) ASPECT Enjoy viewing the image at its optimum size and aspect. Programmes usually contain an “Aspect Control Signal” (Widescreen signal, etc.), and the TV will choose the aspect ratio automatically according to the “Aspect Control Signal” (p. 68). ■...
Using TV Guide TV Guide−Electronic Programme Guide (EPG) provides an on screen listing of the programmes currently broadcast and the forthcoming broadcasts over the next seven days (depending on the broadcasters). • This TV supports the GUIDE Plus+ system. • The Rovi branding partner will supply the rating information in the programme information and the recommended group in the Search list.
■ To search programme types and view a channel list of the searched programmes (DVB mode) (yellow) (Type list) (Search list) select type Prog.Type Search All Types view All Types Search Titles... Movie Movie News News and Fac tual ■ To search programme titles and view a list of the searched programmes (DVB mode) (yellow) •...
Note • This function is not available in Analogue mode. • Timer Programming reminder messages will remain displayed until one of the following occurs: • You press the OK button to view the programme or the EXIT button to cancel the reminder. •...
Viewing Teletext You can enjoy news, weather forecasts and subtitles, etc. (depending on the broadcaster) • The availability of teletext services for a programme is indicated by [TEXT] in the information banner. Information banner (p. 15) 1 BBC ONE Wales 19:50 All DVB Channels Coronation Street...
Analogue teletext Analogue teletext services are the text information provided by the broadcasters. The features may vary depending on the broadcasters. What is FASTEXT (FLOF) mode? In FASTEXT mode, four differently coloured subjects are situated at the bottom of the screen. To access more information about one of these subjects, press the appropriately coloured button.
Page 23
INDEX Subtitles Return to the main index page View a favourite page stored • INDEX STTL Factory setting is “P888” (subtitle service) on the blue button (List mode). View in multi window Watch TV and Teletext in two windows at once TEXT •...
Watching External Inputs Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch through the AV input. • To connect the equipment (p. 10, 11, 66, 67) The Remote Control is capable of operating some functions of selected external equipment. “Operating the equipment with the TV remote control”...
Operating the equipment with the TV remote control The Panasonic equipment connected to the TV can be directly operated with the below buttons of this TV remote control. Standby Set to Standby mode / Turn on Play Playback videocassette / DVD / video content...
How to Use VIERA TOOLS You can access some special features easily by using the VIERA TOOLS function. • For [VIERA Link Control] and [Pause Live TV] functions to operate correctly, ensure the connections and settings are completed. “Summary of Q-Link and VIERA Link features” (p. 58, 59), “Preparations” (p. 61) After connection, turn the equipment on and then switch the TV on.
How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions. Display the menu • INPUT MENU SD CARD Displays the functions that can be set (varies according to the input signal) MENU ASPECT DIRECT TV REC...
Menu list Menu Item Adjustments / Configurations (alternatives) Basic picture mode [Dynamic] / [Normal] / [Cinema] / [True Cinema] / [Game] In each Viewing Mode, [Contrast], [Brightness], [Colour], [Sharpness], [Tint], [Colour Balance], [Vivid Colour], [C.A.T.S.], [P-NR] and [3D-COMB] can be adjusted and stored to suit your particular viewing requirement.
Page 29
Menu Item Adjustments / Configurations (alternatives) Changes the black level in the image for HDMI input mode with DVI input signal manually [Normal] / [Full] • When the DVI input signal from the external equipment, especially from PC, is displayed, DVI Input Setting the black level may not be suitable.
Page 30
Menu Item Adjustments / Configurations (alternatives) SPDIF: A standard audio transfer file format Selects the initial setting for digital audio output signal from DIGITAL AUDIO OUT and HDMI2 (ARC function) terminals [Auto] / [PCM] [Auto] : Dolby Digital Plus and Dolby Digital are output as Dolby Digital Bitstream. SPDIF Selection HE-AAC (48 kHz) multi-channel is output as DTS.
Page 31
Menu Item Adjustments / Configurations (alternatives) VIERA Link Sets to use VIERA Link functions [Off] / [On] (p. 61) Chooses the signal to be transmitted from the TV to Q-Link [TV] / [AV2] / [Monitor] AV1 out [Monitor] : Image displayed on screen •...
Page 32
Menu Item Adjustments / Configurations (alternatives) Selects the preferred language for digital channel subtitles (depending on the broadcaster) [English] / [Welsh] / [Gaelic] / [Irish] Preferred Subtitles To display subtitles (p. 17) provides aids in understanding and enjoyment with DVB subtitles(depending on the broadcaster).
Page 33
Overview (Picture, Sound) How to operate (p. 27) Main Menu Picture Picture Menu Sound Viewing Mode Dynamic Setup Contrast Brightness Colour Sharpness Available in NTSC Tint Colour Balance Warm Not available when [Viewing Mode] is Vivid Colour C.A.T.S. set to [True Cinema] Picture Menu P-NR Available in NTSC / PAL...
Page 34
Overview (Setup) How to operate (p. 27) Timer Programming Wed 27.10.2010 10:46 Main Menu Func tion Channel Name Date Star t End Ext Rec. BBC 2W Wed 27 Oct 20:00 21:30 Picture < T IM ER > ( 90 mi n.) Reminder 14 E4 Wed 27 Oct...
Page 35
TV Guide Settings Menu TV Guide View Normal GUIDE Plus+ Postcode Access GUIDE Plus+ Information Access Link Settings (p. 30) VIERA Link AV1 out Enter Postcode Standby Power Save Postcode Intelligent Auto Standby On (No reminder) A B C D E F G H L M N O P Q R...
Retuning from Setup Menu Automatically retune the channels received in the area. • This function is available if channel tuning is already performed. • Only the selected mode is retuned. • All the previous tuning settings are erased. • If Child Lock PIN number (p. 43) has been set, the PIN number is required. •...
Tuning and Editing Channels (DVB) You can retune channels or make your favourite channel lists, skip unwanted channels, etc. Select DVB INPUT SD CARD MENU ASPECT DIRECT TV REC EXIT Display the menu MENU Select [Setup] OPTION RETURN select Main Menu Picture access Sound...
List favourite DVB channels [Favourites Edit] Create your favourite channel lists from various broadcasters (up to 4: [Favourites]1 to 4). The DVB Favourites lists are available for switching in the Information banner (p. 15) and from [Category] in the TV Guide screen (p.
Page 39
Skip unwanted DVB channels, Edit DVB Channels [Channel List] You can hide unwanted DVB channels. The hidden channels cannot be displayed except in this function. Use this function to skip unwanted channels. Select a channel and [reveal] / [hide] • To reveal all channels All DVB Channels select...
Skip unwanted Analogue channels, Edit Analogue channels [Channel List] You can hide unwanted Analogue channels. The hidden channels cannot be displayed except in this function. Use this function to skip unwanted channels. Select a channel and [reveal] / [hide] • To reveal all channels Analogue Channel List select...
Timer Programming Timer Programming from Menu The Timer Programming menu allows you to choose programmes that you wish to remind watching or record to the external recorder. At the correct time, the TV will tune to the correct channel automatically to record even if the TV is in Standby mode. TV Guide may also be used to set timer programming event (p.
Set timer programming event details [Timer Programming] Start making the settings Select the function ([Ext Rec.] or [Reminder]) select [Reminder] : to remind you to watch the programme [Ext Rec.] : to record the programme to the external recorder When you are watching TV, a reminder message appears When the start time comes, the channel will be switched 2 minutes before the start time.
Child Lock You can lock specific channels / AV input terminals and control who watches them. When the locked channel / input is selected, a message appears; by entering the PIN number, you can watch it. MENU ASPECT DIRECT TV REC Display the menu MENU EXIT...
Input Labels For easier identification and selection of the input mode, you can label each input mode or skip terminals that are not connected to any equipment. • To select the input mode (p. 24) Display the menu INPUT MENU SD CARD MENU ASPECT DIRECT TV REC...
Setup for Internet Connection The ETHERNET terminal is for TV’s software update. You can download a newer version of software through the internet, if it is available. (p. 46) • To update the TV’s software without internet connection “Updating the TV Software” (p. 50) Network connections Connect the TV and the Broadband network equipment (modem, hub or router) by using a LAN cable.
Connect to the network [Network Setup] Select [IP/DNS Settings] and set the items Network Setup select Connection Test IP/DNS Settings Access access Software Update MAC Address ab-cd-ef-gh-ij-kl ■ To set [Acquire IP Address] / [Acquire DNS Address] Select [Acquire IP Address] / [Acquire DNS Address] and set to [Auto] select IP/DNS Settings Acquire IP Address...
Shipping Condition Resets the TV to its original condition with no channels tuned in. All settings other than [Owner ID] are reset (channels, picture, sound settings, etc.). • To retune TV channels only, e.g. after moving house “Retuning from Setup Menu” (p. 36) Display the menu INPUT MENU...
Owner ID Entry of the PIN number and personal information (your name, address and postcode). In the unfortunate event of theft, the Owner ID will help the Police to determine the owner. Display the menu MENU ASPECT DIRECT TV REC MENU EXIT Select [Setup]...
Using Common Interface The Common Interface Module menu provides access to software contained on Common Interface (CI) Modules. This TV works only for Pay TV modules complying with CI standard. • This function is not available for BskyB’s Sky channels. •...
Updating the TV Software From time to time, a new version of software may become available for download to enhance the performance or operations of the TV. In DVB mode, a notification banner will appear when one of the BBC channels is turned to if a new available software is found. •...
Using Media Player Media Player allows you to enjoy photo, video or music recorded on an SD Card. VIERA IMAGE VIEWER is the function of the easy viewing for photos or videos recorded on an SD Card on the TV screen by simply inserting into the SD Card slot.
Photo mode Photo mode will read all “.jpg” extension files in the SD Card. The thumbnail of all the photos in the SD Card will be displayed. INPUT SD CARD Example : Thumbnail - [All photos] MENU ASPECT DIRECT TV REC All photos Media Player Photo...
[Single view] - Photos are displayed one at a time. Select the file from the thumbnail of photos to be viewed select access Example : • • To display / hide the operation To operate Single view Single view guide To the previous photo Slideshow •...
Menu Item Adjustments / Configurations (alternatives) Selects whether enlarged or normal viewing on Single view and Slideshow [Original] / [Zoom] • This function is not available when [Frame] is set to [Collage]. Aspect • This function is not available when [Transition Effect] is set to [Motion]. •...
Video mode • Supported file formats (p. 69) The thumbnail of video titles in the SD Card will be displayed. INPUT SD CARD Example : Thumbnail - [Title view] MENU ASPECT DIRECT TV REC The preview will start when the title is Title view Media Player Video...
Video Setup Setup the settings for Video mode. Display the option menu Select [Video Setup] Select the items and set in the thumbnail view OPTION Video Setup Menu Option Menu Video Preview Video Setup Repeat select access Menu Item Adjustments / Configurations (alternatives) Sets to start the preview of the title or scene in the thumbnail view [Off] / [On] •...
Music mode • Supported file formats (p. 69) The thumbnail of music folders in the SD Card will be displayed. INPUT SD CARD Example : Thumbnail - [Folder view] • MENU ASPECT DIRECT TV REC To display the information of the Media Player Music Folder view...
Connect the equipment supporting VIERA Link to the TV’s HDMI1 or HDMI2 terminal via an HDMI cable. • For information about using HDMI cables for connecting Panasonic HD Video Camera or LUMIX Camera, read the manual of the equipment. VIERA Link (HDMI and SCART connections)
VIERA Link (HDMI and Audio out connections) Connected equipment Player theatre with Blu-ray Disc theatre with Amplifier with VIERA Link VIERA Link function VIERA Link function function Features Analogue channel download – – – ∗ ∗ Easy playback – Power on link –...
Q-Link Preparations • Connect the DVD Recorder / VCR with the following logos: “Q-Link”, “NEXTVIEWLINK”, “DATA LOGIC (a trademark of Metz Corporation)”, “Easy Link (a trademark of Philips Corporation)”, “Megalogic (a trademark of Grundig Corporation)” or “SMARTLINK (a trademark of Sony Corporation)” •...
Control™” ∗ VIERA Link “ ∗ Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function. This TV supports “HDAVI Control 5” function. Connections to the equipment (DIGA Recorder, HD Video Camera, Player theatre, Amplifier, etc.) with HDMI and SCART cables allow you to interface them automatically (p. 58, 59).
Page 62
Reduce unnecessary power consumption in standby [Standby Power Save] Set Standby Power Save [On] in the Setup Menu to use this function [Standby Power Save] (p. 31) The power consumption in Standby mode of the connected equipment is controlled in synchronization with the TV On / Off state.
Page 63
Pause Live TV programme [Pause Live TV] You can pause the live TV programme and resume the programme later. The live TV programme will be recorded on HDD of the connected DIGA Recorder. • This function is available with a DIGA Recorder which has HDD. •...
Select the equipment you want to access The type of the connected equipment is displayed. Select the type of the equipment and access. VIERA Link Menu select Pause Live TV Start Direct TV Rec Start access VIERA Link Control Recorder Speaker Selection Home Cinema [Recorder] / [Player] / [Home Cinema] / [Video Camera] / [LUMIX] / [Digital Camera] / [Other]...
Page 65
Speaker control [Speaker Selection] You can control the home theatre speakers with this TV remote control (point the remote control at the TV’s signal receiver). • If you cannot operate, check the settings and the equipment “Summary of Q-Link and VIERA Link features” (p. 58, 59), “Preparations” (p. 61) Display [VIERA Link Menu] INPUT SD CARD...
External Equipment These diagrams show our recommendations for connection of your TV to various pieces of equipment. For other connections, consult the instructions for each piece of equipment, the table below, and the specifications (p. 79). Types of connectable equipment to each terminal Terminal AUDIO DIGITAL...
To watch DVDs (Listening) DVD Player (Viewing) HDMI equipment • HDMI connection (p. 70) Recorder / Player Fully wired HDMI compliant cable Camcorder Camcorder / Game equipment (Viewing) Camcorder (Listening) Game equipment To listen with speakers Optical digital audio cable Amplifier with RCA cable speaker system To enjoy the sound from the external equipment in...
Technical Information Auto Aspect The optimum size and aspect can be chosen automatically, and you can enjoy finer images. (p. 17) Aspect Control Signal [WIDE] will appear in the top left of the screen if a Widescreen signal (WSS) or a Control signal through SCART / HDMI terminal is found.
Back up the recorded data at regular intervals in case of deteriorated or damaged data 24 mm or erratic operation of the TV. (Panasonic is not liable for any deterioration or damage of recorded data.) Supported file format in Media Player ■...
Characters table for numeric buttons You can enter characters by using numeric buttons for free input items. Press the numeric button repeatedly until you reach the desired User input character. Name pqrs wxyz A B C D E F G H I J K L M N O P Q R S T •...
Page 71
Input signal that can be displayed COMPONENT (Y, P ), HDMI Signal name COMPONENT HDMI 525 (480) / 60i, 60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i 1,125 (1,080) / 60p, 50p, 24p Mark : Applicable input signal PC (from HDMI terminal) Signal name...
FAQs Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer or Panasonic Customer Care Centre for assistance. For details (p. 80) Block noise, frozen or disappearing image occurs in digital mode / White spots or shadow image (ghosting) occurs in Analogue mode / Some channels cannot be tuned •...
Page 73
Problem Actions • Set [P-NR] in the Picture Menu (to remove noise). (p. 28) • Chaotic image, noisy Check nearby electrical products (fluorescent lamp, DECT phones, mobile phones, microwave, etc.). • No image can be Is [Contrast], [Brightness] or [Colour] in the Picture Menu set to the minimum? (p. 28) •...
Temperature rises of parts of the front, top and rear panels will not pose any problems in terms of performance or quality of the TV. • Follow the message’s instructions. An error message • If the problem persists, contact your local Panasonic dealer or the authorized Service appears Centre. On screen messages Message Meaning / Action •...
Page 75
Please check aerial or local signal • Please also refer to p. 72. availability. • If channels are still not found, consult your local Panasonic dealer. Press OK to start Auto Setup. • No module inserted Check the CI module is inserted completely (p. 49).
■ Media Player Message Meaning / Action • The file is damaged or unreadable. • Cannot read file The TV does not support the format. (For the applicable formats and data p. 69) • No SD card inserted Confirm the SD Card is inserted correctly. •...
LLC in the United States and other countries. • HDAVI Control™ is a trademark of Panasonic Corporation. • “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. • x.v.Colour™ is a trademark. • Manufactured under license from Dolby Laboratories.
Specifications TX-P42U30B TX-P50U30B Power Source AC 220-240 V, 50 / 60 Hz Rated Power Consumption 255 W 295 W 0.40 W Standby Power Consumption 15.00 W (With monitor out recording) 1,023 mm × 671 mm × 288 mm 1,212 mm × 782 mm × 324 mm Dimensions (W ×...
Page 80
• Or go on line through our Internet Accessory ordering application at www.pas-europe.com. • Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd. • It couldn’t be simpler! •...
