WF8754S6(W/V/S/C/R)
WF8752S6(W/V/S/C/R)
WF8750S6(W/V/S/C/R)
WF8758S6(W/V/S/C/R)
WF8654S6(W/V/S/C/R)
WF8652S6(W/V/S/C/R)
WF8650S6(W/V/S/C/R)
Washing Machine
user manual
imagine
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/global/register
the possibilities
WF8658S6(W/V/S/C/R)
WF8522S6(W/V/S/C/R)
WF8520S6(W/V/S/C/R)
WF8528S6(W/V/S/C/R)
WF8452S6(W/V/S/C/R)
WF8450S6(W/V/S/C/R)
WF8458S6(W/V/S/C/R)
Advertisement
Table of Contents
Related Manuals for Samsung WF8754S6W
Summary of Contents for Samsung WF8754S6W
-
Page 1: Washing Machine
WF8754S6(W/V/S/C/R) WF8658S6(W/V/S/C/R) WF8752S6(W/V/S/C/R) WF8522S6(W/V/S/C/R) WF8750S6(W/V/S/C/R) WF8520S6(W/V/S/C/R) WF8758S6(W/V/S/C/R) WF8528S6(W/V/S/C/R) WF8654S6(W/V/S/C/R) WF8452S6(W/V/S/C/R) WF8652S6(W/V/S/C/R) WF8450S6(W/V/S/C/R) WF8650S6(W/V/S/C/R) WF8458S6(W/V/S/C/R) Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register... -
Page 2: Child Lock
features • Child Lock The Child Lock function keeps curious little hands out of the washer. This safety feature ensures, that children do not toy with the operation of the washer. It also alerts you when it is activated. • Handwash Clothes susceptible to damage, such as those made of linen or silk, can be washed just as if they were being washed by hand. -
Page 3: Safety Information
It’s your resposibility to use common sense, caution, and care when installing, maintaining, and operation your washer. Samsung is not liable for damages resulting from improper use. IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS... - Page 4 safety information Pets and small children may climb into the appliance. Check the appliance before each use. The glass door becomes very hot during the washing cycle. Keep children away from the appliance while it is in use. Do not attempt to repair the appliance yourself. Repairs made by inexperienced or unqualified persons may cause injury and/or make more serious repairs to the appliance necessary.
-
Page 5: Table Of Contents
contents INSTALLING THE WASHING Unpacking the Washing Machine MACHINE Overview of the washing machine Selecting a location Adjusting the leveling feet Removing the shipping bolts Connecting the water supply hose Positioning the drain hose Connecting the water supply hose (Option) WASHING A LOAD OF LAUNDRY Washing for the first time Putting detergent in the washing machine... -
Page 6: Installing The Washing Machine
Unpack your washing machine and inspect it for shipping damage. Also make sure that you have received all of the items shown below. If the washing machine was damaged during shipping or you do not have all of the items, contact your Samsung dealer immediately. OVERVIEW OF THE WASHING MACHINE... -
Page 7: Selecting A Location
SELECTING A LOCATION Before you install the washing machine, select a location with the following characteristics: • A hard, level surface (if the surface is uneven, see “Adjusting the leveling feet,” below) • Away from direct sunlight. ������ ��������� ���� ���������... -
Page 8: Connecting The Water Supply Hose
installing the washing machine CONNECTING THE WATER SUPPLY HOSE The water supply hose must be connected to the washing machine at one end and to the water faucet at the other. Do not stretch the water supply hose. If the hose is too short and you do not wish to move the water faucet, replace the hose with a longer, high pressure hose. -
Page 9: Positioning The Drain Hose
The drain pipe branch must be above the sink siphon so that the end of the hose is at least 60 cm above the ground. ln a drain pipe Samsung recommends that you use a 65 cm high vertical pipe; it must be no shorter than 60 cm and no longer than 90 cm. Installing the washing machine _9... -
Page 10: Connecting The Water Supply Hose (Option)
installing the washing machine CONNECTING THE WATER SUPPLY HOSE (OPTION) 1. Remove the adaptor from the water supply hose. 2. First, using a ‘+’ type screw driver, loosen the four screws on the adaptor. Next, take the adaptor and turn part(b) following the arrow until there is a 5mm gap. -
Page 11: Washing A Load Of Laundry
washing a load of laundry WASHING FOR THE FIRST TIME Before washing clothes for the first time, you must run a complete cycle without clothes. To do this: 1. Press the (On/Off) button. 2. Pour a little detergent into compartment ( ) in the detergent drawer. -
Page 12: Overview Of The Control Panel
washing a load of laundry OVERVIEW OF THE CONTROL PANEL This is a general manual. The INLAY system may be different from that of the product you purchased. For ( ), see item 6 below to select the right specifications that match your product. Digital graphic Displays the remaining wash cycle time, all of washing information and error display... - Page 13 Press the button repeatedly to cycle through the available spin speed options. WF8754S6/WF8654S6 Rinse Hold, , 400, 800, 1200, 1400 rpm WF8752S6/WF8652S6/ Rinse Hold, , 400, 800, 1000, 1200 rpm WF8522S6/WF8452S6 WF8750S6/WF8650S6/ Rinse Hold, , 400, 600, 800, 1000 rpm WF8520S6/WF8450S6 Spin selection button...
-
Page 14: Washing Clothes Using Fuzzy Logic
WASHING CLOTHES USING FUZZY LOGIC Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Logic” automatic control system. When you select a wash programme, the machine will set the correct temperature, washing time, and washing speed. -
Page 15: Washing Clothes Manually
WASHING CLOTHES MANUALLY You can wash clothes manually without using the Fuzzy Logic feature. To do so: 1. Turn the water supply on. 2. Press the (On/Off) button on the washing machine. 3. Press the Door Open button and open the door. 4. -
Page 16: Maintaining The Washing Machine
maintaining the washing machine DRAINING THE WASHING MACHINE IN AN EMERGENCY WF8754S6/WF8752S6/WF8750S6/WF8758S6/WF8654S6/WF8652S6/WF8650S6/WF8658S6 1. Unplug the washing machine from the power supply. 2. Open the filter-cover by using a coin or a key. 3. Unscrew the emergency drain cap by turning left. Grip the cap on the end of the emergency drain tube and slowly pull it out about 15 cm. -
Page 17: Cleaning The Detergent Drawer And Recess
CLEANING THE DETERGENT DRAWER AND RECESS 1. Press the release lever on the inside of the detergent drawer and pull it out. 2. Remove the cap from compartment ( ). 3. Wash all of the parts under running water. 4. Clean the drawer recess with an old toothbrush. 5. -
Page 18: Cleaning The Water Hose Mesh Filter
maintaining the washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least one time per year, or when you see the following error message on the display: To do this: 1. Turn off the water source to the washing machine. 2. -
Page 19: Troubleshooting
troubleshooting PROBLEMS AND SOLUTIONS PROBLEM SOLUTION The washing machine • Make sure the door is firmly closed. will not start • Make sure the washing machine is plugged in. • Make sure the water source faucet is turned on. • Make sure to press the Start/Pause button. - Page 20 programme chart PROGRAMME CHART user option) Max load(kg) Detergent and additives Spin speed (MAX) rpm Temp Cycle Delay Program 8754S6/ 8654S6/ (MAX) 8752S6/ 8750S6/ 8758S6/ time 8522S6/ 8452S6/ start 8752S6/ 8652S6/ Prewash Wash Softener ˚C 8754S6/ 8652S6/ 8650S6/ 8658S6/ (min) 8520S6/ 8450S6/...
-
Page 21: Appendix
appendix FABRIC CARE CHART Resistant material Can be ironed at 100˚C max Delicate fabric Do not iron Can be dry cleaned using any Item may be washed at 95˚C solvent Dry clean with perchloride, lighter Item may be washed at 60˚C fuel, pure alcohol or R113 only Dry clean with aviation fuel, pure Item may be washed at 40°C... -
Page 22: Declaration Of Conformity
appendix DECLARATION OF CONFORMITY This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. SPECIFICATION TYPE FRONT LOADING WASHER WF8754S6/WF8752S6/ WF8654S6/WF8652S6/ WF8750S6/WF8758S6 WF8650S6/WF8658S6 DIMENSION W598mm X D600mm X H844mm W598mm × D550mm × H844mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME 60 ℓ... - Page 23 TYPE FRONT LOADING WASHER WF8522S6/WF8520S6/WF8528S6 WF8452S6/WF8450S6/WF8458S6 DIMENSION W598mm × D450mm × H844mm W598mm × D404mm × H844mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME 49 ℓ 48 ℓ WF8520S6/ WF8452S6/WF8450S6/ MODEL WF8522S6 WF8528S6 WF8458S6 NET WEIGHT PAPER 67 kg 66 kg 62 kg WASH and SPIN...
- Page 24 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT VIETNAM 1 800 588 889 www.samsung.com Code No. DC68-02376M _EN...
