Washing Machine
WF8804RS-02591C-01_EN.indd 1
WF8804JS(A/F/G/H/S/V/W/Z)
WF8802JS(A/F/G/H/S/V/W/Z)
WF8800JS(A/F/G/H/S/V/W/Z)
WF8704JS(A/F/G/H/S/V/W/Z)
WF8702JS(A/F/G/H/S/V/W/Z)
WF8700JS(A/F/G/H/S/V/W/Z)
user manual
imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive a more complete service, please
register your product at
www.samsung.com/register
WF8804ES(A/F/G/H/S/V/W/Z)
WF8802ES(A/F/G/H/S/V/W/Z)
WF8800ES(A/F/G/H/S/V/W/Z)
WF8704ES(A/F/G/H/S/V/W/Z)
WF8702ES(A/F/G/H/S/V/W/Z)
WF8700ES(A/F/G/H/S/V/W/Z)
WF8804RS(A/F/G/H/S/V/W/Z)
WF8802RS(A/F/G/H/S/V/W/Z)
WF8800RS(A/F/G/H/S/V/W/Z)
WF8704RS(A/F/G/H/S/V/W/Z)
WF8702RS(A/F/G/H/S/V/W/Z)
WF8700RS(A/F/G/H/S/V/W/Z)
2009-05-19 ¿ÀÈÄ 3:12:23
Advertisement
Table of Contents
Related Manuals for Samsung WF8702RSD
Summary of Contents for Samsung WF8702RSD
- Page 1 Washing Machine imagine Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WF8804RS-02591C-01_EN.indd 1 WF8804JS(A/F/G/H/S/V/W/Z) WF8802JS(A/F/G/H/S/V/W/Z) WF8800JS(A/F/G/H/S/V/W/Z) WF8704JS(A/F/G/H/S/V/W/Z) WF8702JS(A/F/G/H/S/V/W/Z) WF8700JS(A/F/G/H/S/V/W/Z) user manual the possibilities WF8804ES(A/F/G/H/S/V/W/Z) WF8802ES(A/F/G/H/S/V/W/Z) WF8800ES(A/F/G/H/S/V/W/Z) WF8704ES(A/F/G/H/S/V/W/Z) WF8702ES(A/F/G/H/S/V/W/Z) WF8700ES(A/F/G/H/S/V/W/Z)
-
Page 2: Child Lock
• Baby Care System Your Samsung washing machine includes wash programs that adds protection to the clothing of children with sensitive skin. These programs reduce skin irritation in children by minimizing detergent residue. In addition,... - Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
-
Page 4: Safety Information
It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washing machine. Samsung is not liable for damages resulting from improper use. IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS... - Page 5 To reduce the risk of fire or explosion: • Do not wash items that have been washed, soaked, or treated with gasoline, dry CAUTION cleaning solvents, or other flammable or explosive substances. They give off vapors that could ignite or explode. Rinse by hand any material that has been exposed to cleaning solvent or other flammable liquids or solids before putting in your washing machine.
- Page 6 safety information The appliance is designed for home use only. Make sure that water and electrical connections are made by qualified technicians, observing the manufacturer’s instructions (see “Installing the Washing Machine”) and local WARNING safety regulations. Before cleaning or carrying out maintenance, unplug the appliance from the electrical outlet. Always unplug the appliance and turn off the water after use.
- Page 7 A stainless washing tub does not usually rust. However if some metal such as a hair pin is left in the tub for an extended time, the tub could rust. • Do not leave water or bleach containing chlorine in the tub for an extended period of time.
-
Page 8: Table Of Contents
contents SETTING UP YOUR WASHING WASHING A LOAD OF LAUNDRY CLEANING AND MAINTAINING YOUR WASHING MACHINE TROUBLESHOOTING AND INFORMATION CODES 8_ contents WF8804RS-02591C-01_EN.indd 8 Checking the parts MACHINE Meeting installation requirements Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine Washing for the first time... -
Page 9: Setting Up Your Washing Machine
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Release lever... -
Page 10: Meeting Installation Requirements
setting up your washing machine MEETING INSTALLATION REQUIREMENTS Electrical supply and grounding To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. -
Page 11: Drain
Drain Samsung recommends a standpipe height of 18 in (46 cm). The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory. -
Page 12: Removing The Shipping Bolts
setting up your washing machine STEP 2 Removing the shipping bolts Before installing the washing machine, you must remove the five shipping bolts from the back of the unit. 1. Loosen all the bolts with the supplied wrench. 2. Hold the bolt with the spanner and pull it through the wide section of the hole. -
Page 13: Connecting The Water Supply Hose
STEP 3 Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the leveling feet in and out as necessary by hand. - Page 14 setting up your washing machine Connecting the water supply hose (selected models) 1. Remove the adaptor from the water supply hose. 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) following the arrow until there is a 5 mm gap.
- Page 15 6. Turn on the water supply and ensure that no water leaks from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water leak. This may cause electric shock or injury.
- Page 16 setting up your washing machine Connecting the drain hose The end of the drain hose can be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm.
-
Page 17: Washing A Load Of Laundry
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WASHING FOR THE FIRST TIME Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry). -
Page 18: Using The Control Panel
washing a load of laundry USING THE CONTROL PANEL DIGITAL GRAPHIC DISPLAY CYCLE SELECTOR 18_ washing a load of laundry WF8804RS-02591C-01_EN.indd 18 Displays the remaining wash cycle time, all cycle information, and error messages. Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”. - Page 19 PREWASH SELECTION BUTTON DELAY END SELECTION BUTTON TEMPERATURE SELECTION BUTTON RINSE SELECTION BUTTON SPIN SELECTION BUTTON AIR REFRESH SELECTION BUTTON INTENSIVE WASH SELECTION BUTTON EASY IRON SELECTION BUTTON START/PAUSE SELECTION BUTTON POWER BUTTON WF8804RS-02591C-01_EN.indd 19 Press this button to select pre-wash. Pre-wash is only available with: Cotton, Synthetics, Sports Wear, Baby Care, Daily Wash.
-
Page 20: Child Lock
washing a load of laundry Child lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, press the Temp. and Rinse buttons at the same time for 3 seconds. -
Page 21: Air Refresh
Air Refresh Air Refresh can refresh laundry without using water owing to its powerful airing system. Clothing that can be refreshed includes woolen coats, cotton or jumpers, sweaters and suits. (Two items or less (less than 1 kg) 1. Open the door, place the laundry into the washing machine and close the door. 2. -
Page 22: Washing Clothes Using The Cycle Selector
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. -
Page 23: Washing Clothes Manually
Washing clothes manually You can wash clothes manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the Power button on the washing machine. 3. Open the door. 4. Load the articles loosely into the drum one at a time, without overfilling it. 5. -
Page 24: Laundry Guidelines
washing a load of laundry LAUNDRY GUIDELINES Follow these simple guidelines for the cleanest laundry and the most efficient wash. Always check the Care label on clothing before washing. Sort and wash your laundry according to the following criteria: • Care Label: Sort laundry into cottons, mixed fibres, synthetics, silks, wools and rayons. -
Page 25: Detergent And Additives Information
Make sure to insert brassieres (water washable) into a laundry net (to be purchased additionally). • The metal parts of the brassieres may break through the material and damage the laundry. Therefore make sure to place them inside a fine laundry net. •... -
Page 26: Cleaning And Maintaining Your Washing Machine
cleaning and maintaining your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. DRAINING THE WASHING MACHINE IN AN EMERGENCY 1. Unplug the washing machine from the power supply. 2. Open the filter cover using a coin or a key. 3. -
Page 27: Cleaning The Detergent Drawer And Drawer Recess
CLEANING THE DETERGENT DRAWER AND DRAWER RECESS 1. Press the release lever on the inside of the detergent drawer and pull the drawer out. 2. Remove the liquid detergent divider from the detergent drawer 3. Wash all parts under running water. 4. -
Page 28: Cleaning The Water Hose Mesh Filter
cleaning and maintaining your washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least once a year, or when the error message of “4E” is displayed: 1. Turn off the water supply to the washing machine. 2. -
Page 29: Troubleshooting And Information Codes
Vibrates or is too noisy The washing machine does not drain and/or spin Door is locked shut or will not open. If the problem persists, contact your local Samsung Customer Service. WF8804RS-02591C-01_EN.indd 29 SOLUTION • Make sure your washing machine is plugged in. -
Page 30: Information Codes
Customer Service. CODE SYMBOL cE/3E For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer. 30_ troubleshooting and information codes WF8804RS-02591C-01_EN.indd 30... - Page 31 cycle chart CYCLE CHART user option) WF8804/ PROGRAM WF8802/ WF8800 Cotton Synthetics Sports Wear Delicates Wool Handwash Baby Care Daily Wash Quick 29’ PROGRAM WF8804/ WF8704 Cotton 1400 Synthetics 1200 Sports Wear 1200 Delicates Wool Handwash Baby Care 1400 Daily Wash 1200 Quick 29’...
-
Page 32: Appendix
appendix FABRIC CARE CHART The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing, and dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundering problems. -
Page 33: Specifications
SPECIFICATIONS TYPE DIMENSIONS WATER PRESSURE WATER VOLUME NET WEIGHT WASH AND SPIN CAPACITY MODEL WASHING POWER WASH AND CONSUMPTION HEATING MODEL SPIN PUMPING MODEL PACKAGE WEIGHT PAPER PLASTIC MODEL SPIN REVOLUTIONS The appearance and specifications of the product are subject to change without prior notice for purposes of product enhancement. - Page 34 memo WF8804RS-02591C-01_EN.indd 34 2009-05-19 ¿ÀÈÄ 3:12:52...
- Page 35 memo WF8804RS-02591C-01_EN.indd 35 2009-05-19 ¿ÀÈÄ 3:12:52...
- Page 36 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT 0845 SAMSUNG (7267864) www.samsung.com/uk Code No. DC68-02591C-01_EN WF8804RS-02591C-01_EN.indd 36 2009-05-19 ¿ÀÈÄ 3:12:52...
