- Page 1 Screwdriver MODEL 6807 003556 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
SPECIFICATIONS Model 6807 High 6 mm (1/4”) Self drilling screw 8 mm (5/16”) Capacities High 5 mm (3/16”) Drywall screw 5 mm (3/16”) High 0 - 2,200/min. No load speed (RPM) 0 - 1,000/min. Overall length 318 mm (12-1/2”) Net weight 2.0 kg (4.4 lbs) -
Page 3: Personal Safety
still does not fit, contact a qualified elec- 13. Do not overreach. Keep proper footing trician to install a polarized outlet. Do not and balance at all times. Proper footing and change the plug in any way. Double insula- balance enables better control of the tool in unexpected situations. -
Page 4: Specific Safety Rules
22. Use only accessories that are recom- SERVICE mended by the manufacturer for your 23. Tool service must be performed only by model. Accessories that may be suitable for qualified repair personnel. Service or main- one tool, may become hazardous when used tenance performed by unqualified personnel on another tool. - Page 5 5. Do not touch the bit or the workpiece immediately after operation: they may be extremely hot and could burn your skin. SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. SYMBOLS USD201-2 The followings show the symbols used for tool.
-
Page 6: Functional Description
FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Depth adjustment 003557 The depth can be adjusted by turning the locking sleeve. Turn it in “A” direction for less depth and in “B” direction for more depth. - Page 7 Switch action 003560 CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released. To start the tool, simply pull the switch trigger. Tool speed is increased by increasing pressure on the switch trigger.
- Page 8 CAUTION: • Do not turn the knob while the tool is running at full speed. Malfunction of the tool may result. ASSEMBLY CAUTION: • Always be sure that the tool is switched off and unplugged before carrying out any work on the tool. Installing or removing the bit 003563 To remove the bit, first pull the locator out of the locking...
-
Page 9: Operation
CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 10 Memo...
- Page 11 Memo...
- Page 12 Memo...
- Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
- Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
- Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
- Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
