TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 1 Safety Precautions 1.1. General Guide Lines 1. It is advisable to insert an isolation transformer in the AC supply before servicing a hot chassis. 2. When servicing, observe the original lead dress, especially the lead dress in the high voltage circuits.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 3 Disassembly for Service This flowchart indicates disassembly items of the cabinet parts and circuit boards in order to find the items necessary for servicing, when reassembling, perform the procedures in the reverse order.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Note: Board ground wires may have to be disconnected to disassemble some boards. All ground wires must be reconnected using jumper leads if necessary before power is applied to Receiver for service. 3.4.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 8. Note position of yoke with centering tabs and remove from 3.10. Disassembly For CRT Removal defective CRT. To facilitate CRT replacement, the complete CRT mounting 9. From the Top, remove (2) screws from the defective CRT.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 4 Service Hints 4.1. Service position for Main 4.3. Service Position for M-Board chassis 1. Remove the Top Cabinet Ass´y. 2. Remove M-Board by removing (3) screws. 1. Remove the Rear Cover (Bottom) by removing (19) screws around its perimeter.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 5 Self Check 1. Self-Check is used to automatically check the bus lines and hexadecimal code of the TV set. 2. To get into the Self -Check mode press the down ( ) button on the customer controls at the front of the set, at the same time pressing the HELP button on the remote control, and the screen will show : If the CCU ports have been checked and found to be incorrect or not located then “--”...
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 6 Service Mode Function MPU controls the functions switching for each IICs through IIC bus in this chassis. The following setting and adjustment can be adjusted by remote control in Service Mode. 6.1.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 7 CRT Set Up Caution: 7.3. Optical Lens Focus Insure yoke plugs on the A-Board are reconnected before Adjustment turning the Receiver ON to prevent damage to the horizontal output transistor and/or CRTs.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 7.4. Centering Magnet Adjustment 1. Receive a monoscope pattern. 2. Confirm that Coarse convergence data (Service mode1) for R,G and B is 0. 3. Set that Fine convergence data (Service mode1) is clear (no correction).
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 8 Deflection Adjustment Caution 8.1.3. V-Amp, V-Linear and V-Pos 1. The following adjustment have to be carried out one Adjustment with PAL signal (100i/50p) and with NTSC signal 1. Adjust Vertical amplitude for 2.5 ± 0.1 division of a scale by (60p/120i).
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 9 Adjustment Procedure 9.1. SECAM Black Level Adjustment Preparation Picture Menu: Dynamic AI: ON Adjustment 1. Receive SECAM white pattern. 2. Connect an oscilloscope to A44 pin 39(B-Y OUT) on A-Board. 3. Adjust SECAM B-Y so that H-blanking time and colour center are equal level.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 9.5. NTSC Tint Adjustment Preparation Picture Menu : Dynamic P-NR : ON C Temp : Standard Scan Mode : 100Hz (PAL) AI : ON Adjustment 1. Receive a Rainbow (NTSC 3.58Hz) pattern. 2. Connect an oscilloscope to TPLR1 on LR-Board.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 9.9. Sub Bright Adjustment Preparation Picture Menu : Dynamic P-NR : ON C Temp : Dynamic Scan Mode : 100Hz (PAL) AI : ON Cut off and White Balance Adjustment has been adjusted Adjustment 1.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10 Convergence Adjustment The convergence adjustment is set separately for each Adjust the convergence for each of the 50/100Hz and 50/100Hz/ 60/100Hz input (NTSC, PAL/ SECAM). The 60/120Hz inputs so that they are aligned with the other colours.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.2. Convergence Adjustment Procedure 1. Input a monoscope pattern of PAL. 2. Enter the Service Mode1. 3. Select the Coarse Convergence by pushing "RED" or "GREEN" buttons. Then push "YELLOW" button, and push Position and [N] buttons to set the data to zero.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3. Coarse Convergence Adjustment mode 10.3.1. Green Coarse Convergence Adjustment 10.3.1.1. Reparation Push the "SOUND" button, and select the Green Adjustment mode.Push the "2" button, and select the "Border and Cross" pattern.Push the "MUTE" button, and select the "Green" colour.
Page 32
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3.1.3. "G-SIZE (H)" adjustment Push the "TV/AV" buttons, and select the "G-SIZE (H)".Push the "Volume up/down" buttons, and adjust the boarder line on either side of test pattern is aligned with the edge of the screen frame.
Page 33
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3.1.7. "G-CORNER" adjustment Push the "TV/AV" buttons, and select the "G-CORNER".Push the "Volume up/down" buttons, and adjust the "G-CORNER" to become the following figure. 10.3.1.8. "G-KEY" adjustment Push the "TV/AV" buttons, and select the "G-KEY".Push the "Channel up/down" buttons, and adjust the "G-KEY" refer to following figure.
Page 34
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3.2. Red Coarse Convergence Adjustment 10.3.2.1. Reparation Push the "SOUND" button, and select the Red Adjustment mode.Push the "2" button, and select the "Border and Cross" pattern.Push the "MUTE" button, and select the "Yellow" colour.Push the "POSITION" button, and adjust the "R-STATIC" so that the Red color of pattern is aligned with Green colour of pattern.
Page 35
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3.2.6. "R-LINEAR" adjustment Push the "TV/AV" buttons, and select the "R-LINEAR".Push the "Volume up/down" buttons, and adjust the "R-LINEAR". (Refer to Fig. C.) 10.3.2.7. "R-PIN (V)" adjustment Push the "TV/AV" buttons, and select the "R-PIN".Push the "Channel up/down" buttons, and adjust the "R-PIN (V)". (Refer to Fig.
Page 36
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.3.3.6. "B-LINEAR" adjustment Push the "TV/AV" buttons, and select the "B-LINEAR".Push the "Volume up/down" buttons, and adjust the "B-LINEAR". (Refer to Fig. C.) 10.3.3.7. "B-PIN (V)" adjustment Push the "TV/AV" buttons, and select the "B-PIN".Push the "Channel up/down" buttons, and adjust the "B-PIN (V)" (Refer to Fig.
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.4. Fine Convergence Adjustment 10.4.1. Green Convergence Adjustment 8. Use the Position Buttons to adjust each point so that the Green Crosshatch Pattern is aligned with the vertical and 1. Select the "G-LINE CURSOR" mode by pushing "TV/AV"...
Page 38
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 10.4.2. Red Convergence Adjustment 1. Push the "MUTE" button twice and change to the Red Adjustment of Yellow Colour. 2. Repeat the same steps described for the Green Conv.Adj. in 1~16 to perform the Red Convergence Adjustment.
Page 39
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Fine Convergence Control Chart...
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 11 Location of Lead Wiring...
Page 42
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X INSERTION OF CONNECTOR LR1, LR2, LG1, LG2, LG3, LG4, LG5, LG6, LG7, LB1, LB2, LRGND1, LGGND1, LBGND1 NOTICE FOR WORE DRESSING 1. Confirm that the lead line isn’t hitting the metallic part of the neck print after CRT neck print (R, G, B) insertion.
Page 43
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X The Anode Lead 1. It inserts Anode lead tip in the back to FBT (the fly background transformer), and it makes turn on the right and it locks it. (Three insertion positions are free).
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 15 Parts location Note: The number on mechanical parts indicates Ref. No. Mechanical Replacement Parts List...
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 16 Mechanical Replacement Parts List Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TPD169564 JOINT EAST6PH12A6 SPEAKER TPDA0360-2 CUSHION(BOTTOM) EUR511229 REMOTE CONTROL TPDA0362-2 CUSHION G0F100000004...
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X 17.2. Electrical Replacement Parts List Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C482 ECA1CM102 E 1000UF, 16V A1-A3 TJSF19916 16P CONNECTOR K1KA16A00119...
Page 88
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C873 ECJ2VF1H104Z C 0.1UF, Z, 50V C1312 ECJ1XC1H181J C 180PF, J, 50V C874 ECKCNA222MEB C 2200PF, M...
Page 89
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C1465 TCUY0J335MBM C 3.3UF, 6.3V F1K0J335A003 C1802 ECJ2VF1C105Z C 1UF, Z, 16V C1466 ECJ1XC1H680J C 68PF, J, 50V...
Page 90
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C2352 ECEA1HN2R2U E 2.2UF, 50V C3002 ECA1CM101 E 100UF, 16V C2354 ECEA1HN4R7U E 4.7UF, 50V...
Page 91
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C7017 ECJ2XC1H681J C 680PF, J, 50V C9611 ECWH16473JV 0.047PF,J,1.6KV C7018 ECJ2XC1H220J C 22UF, J, 50V...
Page 92
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description D875,76 ERZV14D511 VARISTOR D884 TLP721FD4GR PHOTO COUPLER B3PAA0000222 H1,H2 TJSF17425 25P CONNECTOR K1KA25B00004 D885 MA4056H...
Page 93
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description IC7110 BA7603F L053 EXCELDR35C BEAD CHOKE IC7121 CXA1875AM LINEAR IC C0FBBD000017 L055,56 ELESE2R2KA PEAKING COIL...
Page 94
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description L1317 TALC168T6R8K CHIP INDUCTOR LC1110-13 TLK212T256AL EMI FILTER J0HAAB000012 COIL LC1114 TLK20LFA224M EMI FILTER J0HABB000004...
Page 95
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description Q1303-05 2SD601A-R TRANSISTOR 2SD0601AR Q3132 2SD601A-R TRANSISTOR 2SD0601AR Q1306 2SB709A TRANSISTOR 2SB0709A Q3351 2SB1030A TRANSISTOR...
Page 96
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R454 ERJ6GEYJ123 M 12KOHM,J,1/10W R540 ERDS2TJ104 C 100KOHM, J,1/4W R455 ERG3FJS331D M 330 OHM, J, 3W...
Page 97
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R1083,84 ERDS2TJ101 C 100 OHM, R1196 EXB38V680J RESISTOR ARRAY J,1/4W R1202 EXB38V680J RESISTOR ARRAY R1085...
Page 98
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R1344 ERJ6ENF1500 M 150 OHM, 1/10W R1415 ERJ3GEYJ102 M 1KOHM,J,1/16W R1345 ERJ3GEYJ103 M 10KOHM,J,1/16W R1417,18...
Page 99
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R1722 ERJ6GEYJ561 M 560 R1880 ERJ3GEYJ681 M 680 OHM,J,1/10W OHM,J,1/16W R1724 ERJ3GEYJ221 M 220 R1882,83...
Page 100
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R2324-26 ERJ6GEY0R00 M 0 OHM,J,1/10W R2911 ERDS2TJ271 C 270 OHM, J,1/4W R2327 ERJ6GEYJ103 M 10KOHM,J,1/10W...
Page 101
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R2986 ERDS2TJ103 C 10KOHM, J,1/4W R3326 ERJ6ENF1272 M12.7KOHM, 1/10W R2987,88 ERDS2TJ683 C 68KOHM, J,1/4W R3355 ERDS2TJ392 C 3.9KOHM,...
Page 102
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R7106-08 ERJ6ENF4702 M 47KOHM, 1/10W R7734 ER0S2CKF2490 M24.9 OHM, EROS2CKF2490 F,1/4W R7109 ERJ3GEYJ272 2.7KOHM,J,1/16W R7735...
Page 103
TX-47P500HM / TX-47P500HQ / TX-47P500HZ / TX-47P500X Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R9306 ERJ6GEYJ470 M 47 OHM,J,1/10W TJS3A9670 6P CONNECTOR K1KA06A00179 R9318 ERJ6GEYJ152 1.5KOHM,J,1/10W T501 ETH19K135AY H DRIVE TRANS...
