Panasonic SV-MP500V Operating Instructions Manual

Digital audio player
Hide thumbs


Advertisement

Quick Links

Operating Instructions

Digital Audio Player

Model No.
Dear Customer
Thank you for purchasing this product.
Before connecting, operating or
adjusting this product, please read
these instructions completely. Please
keep this manual for future reference.
Caution
This unit is not waterproof and should not be exposed to excessive moisture.
GC GK GH
GN
En
Matsushita Electric Industrial Co., Ltd.
Web site: http://www.panasonic.co.jp/global/
Supplied accessories
1 AC Adaptor
1 Rechargeable battery with case
Recommended replacement rechargeable
battery:ZBRP-BP65HE (Nickel-metal
hydride rechargeable battery)
1 Pair of stereo earphones
1 USB Cable
1 CD-ROM (USB Driver)
1 Neck lanyard
Caution: Take care when using the neck
lanyard. If used improperly, it
can be a choking hazard.

Location of Controls

Microphone
REC/STOP
–MODE
Turn on, off (Press and hold)/
Display
Play/Stop
Example:MUSIC
Earphones jack
(3.5 mm stereo)
SV-MP500V
SV-MP510V
RQTT0658-3G
M1004SF0
Battery lid
Skip/search
Volume
HOLD
switch
USB port
Windows Media Player (Version 9.0 or later recommended) Free
download from
http://www.microsoft.com/downloads/
• Supports playback of MP3 and WMA music files
• Built-in microphone for voice recording
• Built-in FM tuner with recording function
• Portable data storage device (Plugs in directly to your PC)
• Language learning with repeat, follow and comparison.
• Total play list (MUSIC, FM RADIO, IC RECORDER) can contain
up to 383 tracks.
These tables show the mode menu items available in the MUSIC,
LEARN, FM RADIO, IC RECORDER and SYSTEM modes.
MUSIC
Mode
Options
NORMAL/ ROCK/
SOUND
JAZZ/ POP/ CLASSIC/
USER DEFINE
NORMAL/ ALL-REP/
PLAY
ONE-REP/ RANDOM
Information (Artist/
INFO.
File format/ Bit Rate)
SINGLE TRACK/
ERASE
PLAYLIST/ ALL ERASE
IC RECORDER
Mode
Options
RECORD
HQ/ SP/ LP
SPEED
LOW-NOR
SINGLE TRACK/
ERASE
ALL VOICE
Rechargeable battery (included)
1
Insert the
rechargeable battery.
2
Charge the battery.
• "CHARGING"
appears on the
display after
connecting the AC
adaptor.
• Recharging also takes place when
the player is connected to a
computer's USB port. ( → page 2)
• Operation cannot be guaranteed if you
use a USB hub or extension cable.
Battery indicator
Full
Note
• You can not play the unit while charging.
• The unit is in the standby condition when the AC adaptor is
connected. The primary circuit is always "live" as long as the AC
adaptor is connected to an electrical outlet.
• The configuration of the AC adaptor differs according to the area.
• Ensure the AC adaptor cable is kept as straight as possible. Bending
it too much may cause an accident.
• After recharging is complete, you shall wait for about 20 minutes to
remove the battery.
1
FM RADIO
Mode
Options
AUTO
Freq. set/ Channel set
PRESET
BAND STEP 50 kHz/ 100 kHz/ 200 kHz
LEARN
Mode
Options
NORMAL/ ALL-REP/
PLAY
ONE-REP
REPEAT
MANUAL REP
SET
LOW-NOR
SPEED
SINGLE TRACK/
ERASE
PLAYLIST/ ALL ERASE
SYSTEM
MODE
LANGUAGE/ AUTO OFF/
BACKLIGHT/ CONTRAST/
SOUND GRAPHIC/ SLEEP TIME
Charge before
initial use
2
1
AC Adaptor
3
To a
household
Insert so
2
mains
the arrow
socket
is facing
upwards
1
Recharging time:
Approx. 6 hours
• The display will turn off when
recharging is complete.
Empty → Recharge
3
