LORUS Y704 Instruction Manual

NREY704B
I M
NSTRUCTION
CAL. Y704 (R23 SERIES)
C H A R A C T E R I S T I C S
1 . S t o p w a t c h : Measures up to 9 hours, 59
m i n u t e s , 5 9 s e c o n d s a n d 9 9 w i t h 1 1 0 0
second readout.
• L a p t i m e m e a s u r e m e n t : U p t o 9 l a p
t i m e s c a n b e m e a s u r e d .
d i f f e r e n c e a n d t h e f a s t e s t l a p t i m e a r e
c a l c u l a t e d a n d d i s p l a y e d d u r i n g t h e
m e as ur em ent.
2 . T i m e / c a l e n d a r d i s p l a y : Hour, minutes,
seconds, month, date and day of the week.
• Automatic calendar adjustment: Calendar
a d j u s t s a u t o m a t i c a l l y f o r o d d a n d e v e n
months including February of leap years,
but not for February of common years.
• T i m e i n d i c a t i o n : Changeover between
12- and 24-hour indications is possible.
3 . D a i l y a l a r m : T h e a l a r m c a n b e s e t t o
ring on a 24-hour basis.
4 . D u a l t i m e : Time of a different time zone
can be set and displayed.
5 . S t r o k e f u n c t i o n : The watch can be set
t o b e e p a t a s e l e c t e d r a t e t o s e r v e a s a
pacemaker in jogging, etc.
6 . C o u n t d o w n t i m e r : U p t o 9 h o u r s 5 9
minutes and 59 seconds can be set in seconds.
B U T T O N S A N D D I S P L A Y S
Month (Day)
C
B
PM
mark
Hour
M i nu te s
T h e s e l ec ti o n of the d i s p la y ca n be m ad e i n
t h e f o l l o w i n g o r d e r w i t h e a c h d e p r e s s i o n o f
button "A".
A
S t o p w a t c h T i m e / c a l e n d a r
d i s p l a y d i s p l a y
A
T i m e r S t r o k e
d i s p l a y d i s p l a y
A
* A f l a s h i n g d i s p l a y m a r k i n d i c a t e s t h a t t h e
corresponding function is in use.
10-98
ANUAL
T h e l a p t i m e
D a t e
D
A l a r m
ma r k
S e co nd s
A
A
A l a r m
d i s p l a y
A
D u a l t i m e
d i s p l a y
A
H O W T O U S E T H E S T O P W A T C H
• The stopwatch can measure up to 9 hours,
5 9 m i n u t e s , 5 9 s e c o n d s a n d 9 9 i n 1 1 0 0
s e c o n d s .
* Even if the stopwatch display is changed
t o a n o t h e r w h i l e t h e m e a s u r e m e n t i s i n
progress, it continues counting properly.
After the stopwatch is used, however, be
s u r e t o r e s e t i t a s t h e b a t t e r y e n e r g y i s
consumed enormously to shorten the battery
l if e.
Stopwatch display
m a r k
C
B
Hour
M in u te s
S e c o n d s 1/100 second
S t o p w a t c h o p e r a t i o n
D e p r e s s b u t t o n " A " t o s h o w t h e s t o p w a t c h
d is p l a y.
Accumulated elapsed time measurement
D D D
S t a r t S t o p R e s t a r t
Accumulate repeatedly by
depressing button "D".
L a p t i m e m e a s u r e m e n t
• "Lap time" refers to an elapsed time required
to cover a given section of the whole distance.
1 . At the start of the activity, depress button
"D" to start the stopwatch.
2 . At the end of the first lap, depress button
"B".
The first lap time and lap number are dis-
played, though the second lap time is be-
ing measured internally.
3 . Depress button "B" to release the lap time
before the end of the second lap. The first
l a p t i m e a n d l a p n u m b e r d i s a p p e a r , a n d
the measurement in progress and "0" are
displayed in place of the lap time and lap
number, respectively.
4 . At the end of the second lap, depress but-
t o n " B " . T h e s e c o n d l a p t i m e a n d l a p
n u m b e r a r e d i s p l a y e d , t h o u g h t h e t h i r d
lap time is being measured internally.
5. Measurement and release of the lap time
can be repeated by depressing button "B".
6 . At the end of the activity, follow either of
the two methods below.
a. T o d i s p l a y t h e f i n a l l a p t i m e , d e p r e s s
b u t t o n " B " . T h e n , d e p r e s s b u t t o n " B "
to release the lap time, and depress button
"D" to stop the measurement.
* T h e t i m e d i s p l a y e d w h e n b u t t o n " D "
i s d e p r e s s e d i s n o t t h e t o t a l e l a p s e d
t i m e o f t h e a c t i v i t y , t h a t i s , t h e t i m e
t h a t e l a p s e d f r o m t h e s t a r t u n t i l t h e
e n d o f t h e a c t i v i t y b u t t h e t i m e t h a t
elapsed from the start until the stop of
the measurement.
b. To display the total elapsed time of the
activity, depress button "D" to stop the
m ea s u r em en t.
7 . Depress button "C" to reset the stopwatch.
N o t e s :
1 . W h e n a l a p t i m e m e a s u r e d i s t h e f a s t e s t
among the lap times previously measured,
a short beep rings to signal that the memory
has been updated with the new fastest lap
t im e.
2 . T h e l a p n u m b e r c o u n t s u p t o " 9 " . A f t e r
"9", the number returns to "1".
D
A
D C
S t o p
R e s e t
