Page 1: Microwave Oven
MICROWAVE OVEN OWNER’S MANUAL & COOKING GUIDE MODEL : MS-324SCE MS-325SCE PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. P/NO : 3828W5A3786... -
Page 2: Precautions
PRECAUTIONS Precautions to avoid possible exposure to excessive microwave energy. You cannot operate your oven with the door open due to the safety interlocks built into the door mechanism. These safety interlocks automatically switch off any cooking activity when the door is opened; which in the case of a microwave oven could result in harmful exposure to microwave energy. -
Page 3: Table Of Contents
CONTENTS PRECAUTIONS CONTENTS UNPACKING & INSTALLING FEATURE DIAGRAM CONTROL PANEL OPERATING INSTRUCTIONS SETTING CLOCK MORE/LESS TIMED COOKING MICROWAVE POWER LEVELS CHILD LOCK SENSOR TOUCH OPERATION INSTRUCTION COOK SENSOR COOK MENU INSTRUCTIONS REHEAT SENSOR REHEAT MENU INSTRUCTIONS AUTO COOK AUTO COOK MENU INSTRUCTIONS AUTO REHEAT AUTO REHEAT MENU INSTRUCTIONS QUICK DEFROST... -
Page 4: Unpacking & Installing
UNPACKING & INSTALLING By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your oven make sure you remove all accessories and packing. Check to make sure that your oven has not been damaged during delivery. - Page 5 Plug your oven into a standard household socket. Make sure your oven is the only appliance connected to the socket. If your oven does not operate properly, unplug it from the electrical socket and then plug it back in. For ; MS-324SCE / MS-325SCE Open your oven door by pressing the DOOR OPEN button.
-
Page 6: Feature Diagram
FEATURE DIAGRAM Oven Front Plate Window Door Screen Your oven will be packed with the following Door Seal materials: Glass Tray ........1 each Display Window Owner's Manual & Cooking Guide ......1 each Control Panel Rotating Ring ....... 1 each This microwave oven is designed for Safety Door Lock System household use only. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS SETTING CLOCK MORE/LESS When your oven is plugged in for the first time or By using the MORE or LESS keys, TIMED COOK, when power resumes after a power interruption, AUTO COOK, AUTO REHEAT program can be the numbers in the display reset to 0. adjusted to cook food for a longer or shorter time. -
Page 8: Timed Cooking
OPERATING INSTRUCTIONS (CONT’D) TIMED COOKING MICROWAVE POWER LEVELS This function allows you to cook food for a desired Your microwave oven is equipped with eleven time. And in order to give you the best results, power levels to give you maximum flexibility and there are 10 power level settings in addition to control over cooking. -
Page 9: Child Lock
OPERATING INSTRUCTIONS (CONT’D) CHILD LOCK Categories: Sensor Reheat This is a unique safety feature that prevents Sensor Cook unwanted oven operation such as used by children. Once the CHILD LOCK is set, no For most Sensor Touch Cooking programs, a cooking can take place. -
Page 10: Sensor Cook Menu Instructions
OPERATING INSTRUCTIONS (CONT’D) SENSOR COOK MENU INSTRUCTIONS - VEGETABLES Standing Time Weight Initial Code Menu Instructions (minutes) Limit Temperature Jacket Potato 1 - 4 pieces Room Wash & pat potatoes dry with paper towel. Pierce 1 piece = 3 each potato 3 times with a fork. Place potatoes (175 g per 2 pieces = 5 Potatoes... - Page 11 OPERATING INSTRUCTIONS (CONT’D) SENSOR COOK MENU INSTRUCTIONS - RICE / CEREAL / PASTA Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature White Rice - 2 cups Rice : Room 3 - 5 Rice 1 cup cups 2 cups Water : Room Tap water cups...
- Page 12 OPERATING INSTRUCTIONS (CONT’D) SENSOR COOK MENU INSTRUCTIONS - DESSERTS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Cake 1 packet Room Prepare the cake following the microwave instructions on the side of the packet, ignoring the Packet cooking instructions. Place the cake, covered with a Cake Mix folded plastic wrap or single layer of wax paper loosely, onto a microwave- safe rack or upturned...
-
Page 13: Reheat
OPERATING INSTRUCTIONS (CONT’D) REHEAT This feature allows you to reheat precooked To reheat DINNER PLATE room-temperature or refrigerated foods without selecting cooking times and power levels. This feature has 6 categories : dinner plate, rice, soup, 1. Touch STOP/CLEAR. casserole, risotto, pizza. 2. -
Page 14: Auto Cook
OPERATING INSTRUCTIONS (CONT’D) SENSOR REHEAT MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Risotto 1- 4 cups Room Place the cooked risotto into a microwave- safe, heatproof dish.Cover with a lid or double layer of plastic wrap loosely.After reheating stir well before serving. -
Page 15: Auto Cook Menu Instructions
OPERATING INSTRUCTIONS (CONT’D) AUTO COOK MENU INSTRUCTIONS - MEAT Standing Time Weight Initial Code Menu Instructions (minutes) Limit Temperature Corned Beef 1.0 - 2.0 kg Refrigerated Corned beef 1 kg 1. 5 kg 2 kg 15 - 20 Warm water 3 cups 4 cups 6 cups... - Page 16 OPERATING INSTRUCTIONS (CONT’D) AUTO COOK MENU INSTRUCTIONS - MEAT Standing Time Weight Initial Code Menu Instructions (minutes) Limit Temperature Seasoned Meat 1.0 - 2.0 kg Refrigerated Apricot Lamb 15 - 20 Loin of forequarter lamb (deboned) 1 packet dried apricots 250 ml apricot nectar 1 tbs cornflour Unroll meat.
- Page 17 OPERATING INSTRUCTIONS (CONT’D) AUTO COOK MENU INSTRUCTIONS - MEAT Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Fish Fillets 0.2 - 0.6 kg Refrigerated Place each fish fillet onto a square of baking paper, 2 - 3 tuck the tail end under. Drizzle with fresh lemon or fresh lime juice and season with salt and pepper.
-
Page 18: Auto Reheat
OPERATING INSTRUCTIONS (CONT’D) AUTO REHEAT Your oven’s menu has been preprogrammed to automatically reheat food. Tell the oven what you want and how many items there are. Then let your microwave oven reheat your selections. Be sure to close the door before selecting categories. Example: To reheat two pies of pie, simply follow the step below. -
Page 19: Quick Defrost
OPERATING INSTRUCTIONS (CONT’D) QUICK DEFROST Example: To defrost 0.5 kg meat. Three Quick Defrost sequences are preset in the oven. The Quick Defrost feature provides you with the express defrosting method for 500g frozen 1. Touch STOP/CLEAR. foods. The oven automatically sets the defrosting time for each food. -
Page 20: Auto Weight Defrost
OPERATING INSTRUCTIONS (CONT’D) AUTO WEIGHT DEFROST NOTE: When you touch the START pad, the display Seven defrost sequences are preset in the oven. changes to defrost time count down. The oven The defrost feature provides you with the best will beep twice during the DEFROST cycle. At defrosting method for frozen foods. -
Page 21: Auto Weight Defrost Menu Instructions
OPERATING INSTRUCTIONS (CONT’D) AUTO WEIGHT DEFROST MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Minced Meat 0.1 - 2.0 kg Frozen Remove the meat completely from it’s wrapping. 5 - 20 Place the mince onto a microwave- safe rack over a plate or shallow dish. - Page 22 OPERATING INSTRUCTIONS (CONT’D) AUTO WEIGHT DEFROST MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Whole Chicken 1.0 - 2.5 kg Frozen Remove the chicken completely from it’s wrapping. 5 - 40 Place a thin strip of foil down the centre of the breast.
-
Page 23: Cooking Tips
OPERATING INSTRUCTIONS (CONT’D) WARNING: Do not use aluminum foil during cooking cycle. COOKING TIPS Meat Poultry 1. No special techniques are required. Meat 1. No special techniques are required. Poultry should be prepared as with conventional should be prepared as with conventional cooking. - Page 24 OPERATING INSTRUCTIONS (CONT’D) COOKING TIPS (continued) Fish 1. Arrange fish in a large shallow non-metallic dish or casserole. 2. Cover with pierced microwave plastic wrap or casserole lid. 3. Place the dish on the turntable. 4. Cook according to the instructions in the Fresh Fish Cooking Chart below. Flakes of butter can be added to the fish if desired.
- Page 25 OPERATING INSTRUCTIONS (CONT’D) To heat or reheat successfully in the microwave, it is important to follow several guidelines. Measure the amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for best results.
- Page 26 OPERATING INSTRUCTIONS (CONT’D) Cook time Standing Vegetable Amount Instructions at HIGH Time Artichokes 2 medium Trim. Add 2 tsp water and 2 tsp juice. Cover. 2-3 minutes (230 g each) 4 medium 10~13 Asparagus, 450 g cup water. Cover. 2-3 minutes Fresh, Spears Beans, Green &...
-
Page 27: Microwave-Safe Utensils
MICROWAVE-SAFE UTENSILS Never use metal or metal trimmed utensils in Paper your microwave oven Paper plates and containers are convenient and Microwaves cannot penetrate metal. They will safe to use in your microwave oven, provided that bounce off any metal object in the oven and the cooking time is short and foods to be cooked cause arcing, an alarming phenomenon that are low in fat and moisture. -
Page 28: Food Characteristics & Microwave Cooking
FOOD CHARACTERISTICS & MICROWAVE COOKING Keeping an eye on things Moisture content of food The recipes in this book have been formulated Since the heat generated from microwaves tends with great care, but your success in preparing to evaporate moisture, relatively dry food such as them depends on how much attention you pay to roasts and some vegetables should either be the food as it cooks. - Page 29 FOOD CHARACTERISTICS & MICROWAVE COOKING Stirring Standing time Stirring is one of the most important of all Foods are often allowed to stand for 3 to 10 microwaving techniques. In conventional cooking, minutes after being removed from the microwave food is stirred for the purpose of blending. oven.
-
Page 30: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read carefully and keep for future reference WARNING Please ensure cooking times are correctly set as over cooking may result in FIRE and subsequent DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any 12 Before cooking, pierce the skin of potatoes, adjustments or repairs to the door, control panel, apples or any such fruit or vegetable. -
Page 31: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read carefully and keep for future reference 24 Only use utensils that are suitable for use in 31 The oven should be cleaned regularly and any microwave ovens. food deposits removed. 25 When heating food in plastic or paper 32 Failure to maintain the oven in a clean condition containers, keep an eye on the oven due to the could lead to deterioration of the surface that... -
Page 32: Question & Answers
QUESTION & ANSWERS Q What’s wrong when the oven light will not 1 Popcorn-popping utensils designed specifically glow? for microwave cooking. A There may be several reasons why the oven light 2 Prepackaged commercial microwave popcorn will not glow. that contains specific times and power outputs Light bulb has blown. -
Page 33: Plug Wiring Information/Technical Specifications
If the supplied flexible main cord of this appliance is damaged, it be replaced using the special main cord part number : 2B72234J TECHNICAL SPECIFICATIONS MODEL MS-324SCE/MS-325SCE 230 / 240 V~ 50 Hz Power Supply Rated Power Consumption 1500 W... -
Page 34: Warranty
LG or their stoppage or loss or impairment of data arising out Authorized Service Centre (additionally we will of the use or inability to use the Product. - Page 35 FOR WARRANTY SERVICE PLEASE CONTACT LG Service on 1800-643-156. LG Electronics Australia 2 Wonderland Drive Eastern Creek NSW 2766 (ABN : 98 064 531 264) LGEAP Printed in Korea...
