Locate the left rudder (red tap) and the right one (green tap). As shown, line up the rudder pintles
1
(metal pegs on the hulls) with the rudder castings (holes with plastic bushings). Push the rudder cas-
The rudders are locked in the down position by pushing the rudder arm aft which will seat the rudder.
Push the arm down to engage the locking cam. To release, lift the arm, then pull the arm forward until the
rudder is in the "up" position. Place the arm down to engage the upper casting with the lower casting.
Beaching will automatically release the rudders.
Keep a small amount of lubricating grease on the plunger and cam mechanism. If this assembly be-
comes dry, it will inhibit proper function.
2
11
TILLER CROSSBAR & EXTENSION
Locate the tiller crossbar
1
and identify the left and
right hand ends. NB: the tiller
crossbar (1) locates on top of
the tiller/rudder arms (2).
1
Locate the tiller connector kits
and install as shown on the
photographs.

RUDDER ASSEMBLY

Locate the tiller extension and secure
3
it to the tiller crossbar using the clevis
pin and ring clip provided.
Insert the retainer
2
pins to lock the rud-
ders in place. The pins
will prevent the rudders
from falling off the boat
in the event of a capsize.
