Quick Check 2D Print
Quality Assessment
Applies to the following products:
IT4410, IT4710, IT4600, IT4800, IT4X80

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IT4410 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hand Held Products IT4410

  • Page 1 Quick Check 2D Print Quality Assessment Applies to the following products: IT4410, IT4710, IT4600, IT4800, IT4X80 ™...
  • Page 2 Disclaimer Hand Held Products, Inc. d/b/a HHP (“HHP”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HHP to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HHP.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1 - Introduction User Operation... 1-1 Reading Techniques... 1-1 Symbology/Parameter Specifics... 1-2 2D PQA Reporting ... 1-3 Full Report ... 1-3 Screening Report... 1-3 Identifying Symbol Content... 1-4 2D Stacked / Multi-row ... 1-5 PDF417 ... 1-5 MicroPDF417...
  • Page 4 Symbology... 1-19 Useful Row Height ... 1-19 X-dimension ... 1-20 Chapter 2 - Quick*View Quick*View Demonstration Software Instructions ... 2-1 Setting Up the Imager and the Quick*View Software ... 2-1 Installing Quick*View from the Web ... 2-1 Temporary Quick*View Configuration ... 2-2 Using the Quick*View Software ...
  • Page 5: User Operation

    • IT4410/4710: Hold the imager 5.0 in (12.7 cm) for LR models, 2.0 in (5.1 cm) for the HD, and 7.0 in (17.8 cm) for the LX from the bar code symbol. This distance is measured from the imager's front window to the reading surface.
  • Page 6: Symbology/Parameter Specifics

    • The hand-held imager has a view finder that projects a bright aiming beam that corresponds to the imager’s horizontal field of view. The aiming beam should be centered over the bar code and positioned horizontally over the code (no tilt, skew, or rotation). If the symbol surface is shiny, the reader may have to be held several degrees below the normal position to avoid specular reflections.
  • Page 7: 2D Pqa Reporting

    If one or more of the measured parameters fail to meet the MAG, the PQA message is also sent with a beep. Note: With the IT4410/4710, screening mode outputs are also accompanied by a single beep if all parameters are okay or a triple beep if one or more of the measured parameters fail to meet the MAG.
  • Page 8: Identifying Symbol Content

    If your imager is in keyboard wedge mode, enable Screening by scanning the following bar codes. Minimum Acceptable Grade = A Minimum Acceptable Grade = C You can exit both Full Report and Screening modes by either typing the menu command, 2D_PQA0, if you are using Quick*View, or by scanning the following bar code: Identifying Symbol Content...
  • Page 9: 2D Stacked / Multi-Row

    While the details are explained below, this general format includes: • the encoded data (the usual output message) in the first line. • a banner " >>> PQA from HHP <<<" identifying the start of the 2D PQA report. • the symbology, its features, and approximate size.
  • Page 10 {5} [A] < Row Height = 3.1 X {6} [A] < Useful Row Height = 2.5 X (82% Row) {7} [A] < Data Safety Margin = 100% (0 Erasures & 0 Errors) {8} [B] < Edge Accuracy = 59% {9} [C] < Print Growth = -43% of X where: {1} is always the Encoded Message, the usual data output.
  • Page 11 if Useful Height >= 1.0 X, else otherwise In Screening modes, this parameter is reported as "Useful Row Height is Too Short (1.5X)" when that is the case. {7} lists the Data Safety Margin, which is the ratio of the unused error correc- tion words to the recommended (!) number of such words.
  • Page 12: Micropdf417

    In rare instances where neither a valid Start nor Stop pattern is measurable, yet the symbol is somehow read, lines {8} and {9} are replaced by a message to that effect. The message is either: "[F] < Start/Stop Decode Fails" in a Full Report or "Start/Stop Characters are Bad"...
  • Page 13: 2D Matrix

    if Row Height >= 1.5 X, otherwise. {6} lists the Data Safety Margin. Because MicroPDF's error correction level is fixed, this parameter is just the "Unused Error Correction" and always between 0 and 100%. {7} lists the Edge Accuracymeasured in multiple scans through the Row Address Patterns.
  • Page 14: Data Matrix

    Note: The reported X-dimension is approximate and based upon use of the IT4410LR at 4.7 in (12 cm) (see "Reading Techniques" on page 1-1). If you use different image engines, the X-dimension will vary. If you hold the reader closer than 4.7 in (12 cm), it will have the effect of reporting a larger than true X-dimension.
  • Page 15: Qr Code

    {7} [A] < Data Safety Margin = 100% {8} [A] < Horizontal Print Growth = +10% of X {9} [A] < Vertical Print Growth = +12% of X {1} is the Encoded Message. {2} is the Banner heading. {3} identifies the Symbology (DATA MATRIX) and lists the symbol's ECC and size.
  • Page 16: Maxicode

    {3} QR CODE: Model 2 Version 3 (29 x 29 modules) {4} Mask Pattern Reference #3, Error Correction Level "M" {5} Data Field: 44 data & 26 checks in 1 block(s) of GF(256) {6} X roughly = 0.025" {7} [A] < Data Safety Margin = 100% {8} [A] <...
  • Page 17: Postal (Height-Modulated) Bar Code Symbologies

    {4} X roughly = 0.043" {5} [A] < Data Safety Margin = 100% {6} [A] < Horizontal Print Growth = +2% of X {7} [A] < Vertical Print Growth = -1% of X {1} is the Encoded Message. {2} is the Banner heading. {3} identifies the Symbology (MAXICODE) and lists the symbol's Mode.
  • Page 18 {7} [A] (Ok) < Bar Widths = 0.022 in. {8} [A] (Ok) < Inter-Bar Gaps = 0.023 in. {1} is the Encoded Message. {2} is the Banner heading. {3} identifies the Symbology, (POSTNET or PLANET Code), and lists also the symbol's size and allowed range of measured width.
  • Page 19: 4-State Codes

    4-State Codes The Full Report from a typical scan looks like the following (line numbers have been added in curly brackets): {1} B15AJ6T >>> PQA from HHP <<< {3} 4-STATE(British): 34 Bars, nominally from 38.5 to 42.3 mm. in Width {4} Bar Sequence: ADHTATDAHDDAADADAADTHTADHHDATHTADH {5} [A] (Ok) <...
  • Page 20: Parameter Interpretation

    Note: For the Canadian and Australian 4-State symbologies only, any bar error that has invoked their error correction triggers an additional PQA parameter line: "[F] < One or more Bars are in Error!" in a Full Report or "One or more Bars are in Error!" in a Screening mode. Table 1: Dimensional Tolerances for the Various 4-State Bar “Tall”...
  • Page 21: Bar Sequence

    Bar Sequence Bar Sequence is the bar height pattern within a height modulated, multi-state, postal-type symbology. In a 2-state symbol, a "1" represents a tall or full height bar and a "0" represents a short or half height bar. In a 4-state symbol, "A" rep- resents the ascending bars, "D"...
  • Page 22: Encoded Message

    Encoded Message The encoded message is the information (alpha, numeric, and/or control char- acters) or message contained within the bar code symbol and output as part of the decoding process. This information precedes the calculated PQA parame- ters. This information must be manually compared to the characters that should be encoded.
  • Page 23: Module Errors

    Module Errors Module Errors are individual errors within fixed pattern/data areas. Although often benign, Module Errors in the fixed regions of a symbol can signal a fault that, in some instances, will prevent proper decoding. They can generally be corrected by using a larger X-dimension and/or cleaning up the print process to eliminate stray ink, voids, and other causes of inconsistency in the print.
  • Page 24: X-Dimension

    height, giving more leeway to symbols printed with above minimum row heights (e.g., 4.0 X). A poor grade here is corrected by either stretching the symbol ver- tically or correcting the print condition (e.g., turning down the thermal burn set- ting or adjusting inking) that causes rows to interfere.
  • Page 25: Chapter 2 - Quick*View

    Quick*View Quick*View Demonstration Software Instructions Quick*View is a Microsoft Windows messages and captures images (for instance, ID photographs) from the imager. Bar code information and images are displayed in the Quick*View window. Note: For additional information about Quick*View, please refer to the user’s guide for your imager.
  • Page 26: Temporary Quick*View Configuration

    Note: If you have a unit capable of keyboard wedge mode, scan the bar code below. The unit will communicate in RS-232 mode, allowing it to work with Quick*View through an appropriate serial cable. To convert the imager back to keyboard wedge communication, cycle the power. IT4600/4800/4X80 IT4410/4710 2 - 2 Quick*View Quick*View...
  • Page 27: Using The Quick*View Software

    Using the Quick*View Software Upon startup, the Quick*View splash screen appears for approximately three seconds. Quick*View will then attempt to establish communications with the Imager. If Communication Cannot Be Established This message appears if communication cannot be established: Quick*View defaults to com 1 as the communications port. If you have plugged the Imager into another com port, you must Cancel out of this message.
  • Page 28: Scan Data Window

    Scan Data Window Once successful communication has been established, you can scan codes and display the bar code data in a window. Select View - Scan Data Window. As you scan bar codes, the data appears in the Serial Scan Data Window. You can alter the font in this window by using the Font button, or clear all data in the window with the Clear button.
  • Page 29: Chapter 3 - Customer Support

    Customer Support Obtaining Factory Service HHP provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, return the unit to HHP (postage paid) with a copy of the dated purchase record attached. Contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product.
  • Page 30: Technical Assistance

    Technical Assistance If you need assistance installing or troubleshooting your imager, please call your Distributor or the nearest HHP technical support office: North America/Canada: Telephone: (315) 685-2476, Option 4 (8 a.m. to 6 p.m. EST) or in the U.S. (800) 782-4263 Fax number: (315) 685-4960 E-mail:...
  • Page 32 QC2DPQA-UG Rev B...
