Freelinc FreeMotion 200 User Manual

Hide thumbs Also See for FreeMotion 200:
Table of Contents

Advertisement

Quick Links

Download this manual
FreeLinc™
FreeMotion™ 200
Headset User Guide
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FreeMotion 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Freelinc FreeMotion 200

Summary of Contents for Freelinc FreeMotion 200

  • Page 1 FreeLinc™ FreeMotion™ 200 Headset User Guide ™...

  • Page 2: Safety And Warranty Information

    Warranty and FCC Compliance warranted Product. e. FreeLinc is not responsible in any way for any ancillary equip- Warranty ment not furnished by FreeLinc which is attached to or used in connection with Product, or for operation of the Product with any ancillary equipment and all such equipment is I.

  • Page 3: Fcc Compliance

    IV. Limitation of Liability: ference harmful to radio communications. a. This warranty sets forth the full extent of FreeLinc’s responsi- bilities regarding the Product. Repair, replacement, or refund of the purchase price, at FreeLinc’s option, is the exclusive There is no guarantee however, that interference will remedy.

  • Page 4: Safety Information

    Safety Information Caution: To reduce the risk of fire or injury to persons, read and follow these instruc- tions. Do not dispose of headset in a fire. The cells may explode. Check with local codes for possible battery disposal instructions. Use only the supplied charging unit to charge the headset from an AC voltage or wall outlet.
  • Page 5 Never submerge your headset in water or other liquids. Protect your headset from spills, excessive rain, and wet locations. Do not use liquid cleaners or aerosol cleaners as they may damage the headset or finish of the headset. Use a dry cloth to clean the external portions of the headset. Do not stick anything inside the product as this may damage internal components.

  • Page 6: Table Of Contents

    Table of Contents SAFETY AND WARRANTY INFORMATION Warranty FCC Compliance Safety Information TABLE OF CONTENTS INTRODUCTION AND GENERAL INFORMATION CONTENTS IN PACKAGES PARTS OF THE PRODUCT 10-13 Diagram/Terms 10-11 Headset 10-11 Headset Charge Indicator Light Headset Indicator Tones Headset Volume Adjustment Tones GENERAL OPERATION 14-19 Operating Concepts and Terms...
  • Page 7 Step Two: Turn On Adapter Step Three: Exit Sleep Mode Step Four: Pair Headset to Adapter Step Five: Establish Link (Automatic) Step Six: Adjust Headset Volume Step Seven: Ending Use VOX Operation Entering VOX Mode Operating in VOX Mode Adjusting VOX Sensitivity Exiting VOX Mode Pairing Your Headset with Other Adapters Manually Initiating the Pairing Process...

  • Page 8: Introduction And General Information

    FreeLinc. The FreeMotion 200 operates in a “bubble” that envelops one to three meters of each user’s personal space, and is – by the laws of physics – fully private and secure. The result is an easier Anthony J.

  • Page 9: Contents In Packages

    PACKAGE CONTENTS FreeMotion 200 (FM-200): • One Headset • One AC Power Adapter • One User Guide • One Quick Start Guide • Six Ear Gels...

  • Page 10: Parts Of The Product

    Parts of the Product - Diagrams FreeMotion 200 (FM-200) Headset Flexible Neck Earpiece swivels for use with either left or right ear Push-to-Talk Button Noise-Canceling Microphone...
  • Page 11 Ear Gel (removable) Volume/ VOX Sensitivity Adjustment Buttons USB Power Adapter Connection Charge Indicator LED Light...

  • Page 12: Headset

    Parts of the Product - Headset Headset Charge Indicator Light The charge indicator light on your FreeMotion 200 headset indicates battery charge status when plugged into the charger: LED BEHAVIOR INDICATION Red, Solid Charging Green, Solid Charging Complete The headset LED will not illuminate when it is unplugged from the charger.

  • Page 13: Headset Volume Adjustment Tones

    Headset Volume Adjustment Tones When clicking the Volume Up or Volume Down buttons to adjust headset volume, you will hear the following tones: INDICATION TONE Volume Up/Volume Down Buttons Single short tone Clicked Single short tone, high pitched Maximum Volume Reached Single short tone, low pitched Minimum Volume Reached...

  • Page 14: General Operation

    Personal Communication Bubble ing sequence (see instructions below) to your The FreeMotion 200 works within a small field, headset with a different adapter. or “bubble” of communication surrounding the user. The size of the bubble is determined by the Seek Mode distance between the headset and the adapter.

  • Page 15: Sleep Mode

    To awaken your headset set battery using a USB cable other than the USB from Sleep Mode, depress the PTT button, which cable provided by FreeLinc. Failure to comply activates Seek Mode. may result in decreased battery capacity.

  • Page 16: Using Your Headset For The First Time

    General Operation Using Your Headset for the First tions to the headset. Time Step Three: Exit Sleep Mode Your headset will be in Sleep Mode when you Step One: Attach Adapter take it out of the box for the first time. To awak- Fit adapter to the accessory interface of the en your headset from Sleep Mode, depress the portable radio (see your portable radio’s user...

  • Page 17: Step Five: Establish Link (Automatic)

    Step Five: Establish Link (Automatic) Use the Volume Up and Volume Down keys on your headset to increase or decrease the volume Once you have paired your headset to an adapt- level. Depress Volume Up or Volume Down once er, the two devices can establish a communica- for each level you want the volume to increase tion link.

  • Page 18: Vox Operation

    General Operation Exiting VOX Mode VOX Operation To exit VOX mode, depress the Volume Down button on headset for six seconds. The adapter Entering VOX Mode LED will change from flashing orange to flashing To enter VOX mode, depress the Volume Down green.

  • Page 19: Pairing Your Headset With Other Adapters

    Pairing Your Headset with Other Adapters Manually Initiating the Pairing Process To initiate pairing, hold the headset close to the adapter and simultaneously depress the Volume Down and Volume Up buttons on the headset. Hold the Volume Up and Volume Down buttons on headset simultaneously for 10 seconds.

  • Page 20: Accessories

    -30 C to +60 C Humidity 95% @ 8 hours (non-condensing) Troubleshooting For up-to-date troubleshooting information, to get help with a specific problem, or to contact a customer service representative, please visit www.freelinc.com, and click the “support” link or call 1-866-467-1199.
  • Page 21 Notes:...
  • Page 22 Adapter The indicator light on your FreeMotion 200 adapter indicates wireless communication status as follows: LED BEHAVIOR INDICATION Red, Flashing 2x per second Seek mode Green, Solid Mate found, pairing/linking in progress Green, Flashing 2x per second Link active Orange, Flashing 2x per second...
  • Page 23 Exiting VOX Mode - Depress the Volume Down button on headset for six seconds. The adapter LED will change from flashing orange to flashing green. Charge Indicator Light Headset The charge indicator light on your FreeMotion 200 headset indicates battery status when plugged into the charger: LED BEHAVIOR INDICATION Red, Solid...
  • Page 24 ™ © 2005 Radeum Inc., DBA FreeLinc. All Rights Reserved. U.S. Patents Pending. The FreeLinc FreeMotion 200 may not be authorized for use in some countries. Developed using: ® US Patents 5771438A, 5982764A, 5972925A, 6459882B1 . Additional patents pending. LibertyLink and Aura are registered trademarks of Aura Communications Technology, Inc.
