FreeLinc™
FreeMic™ 200
Product User Guide
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FreeMic 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Freelinc FreeMic 200

Summary of Contents for Freelinc FreeMic 200

  • Page 1 FreeLinc™ FreeMic™ 200 Product User Guide ™...

  • Page 2: Safety And Warranty Information

    Because each system which may use the Product is unique, FreeLinc disclaims a. Radeum, Inc., doing business as FreeLinc (“FreeLinc”), war- liability for range, coverage, or operation of the system as a rants to Purchaser that its FreeLinc manufactured products whole under this warranty.

  • Page 3: Fcc Compliance

    nonconforming Product from FreeLinc. instructions, may cause interference harmful to radio b. Purchaser shall return the nonconforming Product to the communications. place of purchase freight prepaid. IV. Limitation of Liability: This device complies with part 15 of the FCC Rules. Op- a.

  • Page 4: Safety Information

    Safety Information Caution: To reduce the risk of fire or injury to persons, read and follow these instruc- tions. Do not dispose of product in a fire. The battery cells may explode. Check with local codes for possible battery disposal instructions. Use only the supplied charging unit to charge the product from an AC voltage or wall outlet.
  • Page 5 Never submerge your product in water or other liquids. Protect your product from spills, excessive rain, and wet locations. Do not use liquid cleaners or aerosol cleaners as they may damage the product or finish of the product. Use a dry cloth to clean the external portions of the product. Do not stick anything inside the product as this may damage internal components.

  • Page 6: Table Of Contents

    Table of Contents SAFETY AND WARRANTY INFORMATION Warranty FCC Compliance Safety Information TABLE OF CONTENTS INTRODUCTION AND GENERAL INFORMATION CONTENTS IN PACKAGES PARTS OF THE PRODUCT 10-13 Diagram/Terms 10-11 Product 10-11 Product Charge Indicator Light Product Indicator Tones Product Volume Adjustment Tones GENERAL OPERATION 14-19 Operating Concepts and Terms...
  • Page 7 Step Three: Turn On Adapter Step Four: Exit Sleep Mode Step Five: Pair Product to Adapter Step Six: Establish Link (Automatic) Step Seven: Adjust Product Volume Step Eight: Ending Use VOX Operation Entering VOX Mode Operating in VOX Mode Adjusting VOX Sensitivity Exiting VOX Mode Pairing Your Product with Other Adapters Manually Initiating the Pairing Process...

  • Page 8: Introduction And General Information

    FreeLinc. practical voice and audio solutions for two-way radios. The FreeMic 200 operates in a “bubble” that envelops one to three meters of each user’s personal space, and is – by the laws of physics – fully private and secure. The result is the ability Anthony J.

  • Page 9: Contents In Packages

    PACKAGE CONTENTS FreeMic 200 (FMC-200): • One Wireless Speaker-Microphone • One AC Power Adapter • One User Guide • One Quick Start Guide • One Tether Cord...

  • Page 10: Diagram/Terms

    Parts of the Product - Diagrams FreeMic 200 (FMC-200) Product Charge Indicator LED Light Accessory/ Headphone Jack Push-to-Talk Volume/ VOX Sensitivity Button Adjustment Buttons Microphone Powerful Speaker Rugged All- Weather Design...
  • Page 11 Accessory/ Headphone Jack Charge Indicator LED Light Wall Charger Con- nection Spring-Loaded Rotating Clip...

  • Page 12: Parts Of The Product

    Parts of the Product Charge Indicator Light The charge indicator light on your FreeMic 200 speaker-microphone indicates battery charge status when plugged into the charger: LED BEHAVIOR INDICATION Red, Solid Charging Green, Solid Charging Complete The FreeMic LED will not illuminate when it is unplugged from the charger.

  • Page 13: Product Volume Adjustment Tones

    Volume Adjustment Tones When clicking the Volume Up or Volume Down buttons to adjust FreeMic volume, you will hear the following tones: INDICATION TONE Volume Up/Volume Down Buttons Single short tone Clicked Maximum Volume Reached Double short tone, high pitched Minimum Volume Reached No tone, speaker muted...

  • Page 14: General Operation

    Personal Communication Bubble ing sequence (see page 18) to pair your FreeMic The FreeMic 200 works within a small field, or with a different adapter. “bubble” of communication surrounding the user. The size of the bubble is determined by the Seek Mode distance between the FreeMic and the adapter.

  • Page 15: Sleep Mode

    Sleep Mode six hours before first use. Subsequent charges take just three hours (approximate). The charge When your FreeMic has remained in Seek Mode indicator light will turn green when the FreeMic for two minutes without finding a link, it will battery is fully charged.

  • Page 16: Using Your Product For The First Time

    General Operation Using Your FreeMic for the First Time Step Three: Turn On Adapter Turn on your portable radio and set toggle switch on your FreeLinc adapter to “On” position. Step One: Charge FreeMic Battery (see diagram) Note that this will automatically Plug the FreeMic into an electrical socket using silence the speaker on your portable radio and the included wall charger.

  • Page 17: Step Six: Establish Link (Automatic)

    taneously depress the Volume Up and Volume with which it is paired - when this occurs the Down buttons on the FreeMic. When you have adapter LED will resume flashing green, or successfully paired your FreeMic to the adapter, • Entering Sleep Mode - this occurs when no the adapter LED will turn solid green and then link is established for two (2) minutes.

  • Page 18: Vox Operation

    General Operation diagram) or turn the portable radio off. Once Adjusting VOX Sensitivity you have powered off the adapter, the link will Depending on background audio conditions, be broken and the FreeMic will move into Seek you may need to adjust the microphone sen- Mode.

  • Page 19: Pairing Your Product With Other Adapters

    Pairing Your FreeMic with Other Adapters Manually Initiating the Pairing Process To initiate pairing, hold the FreeMic close to the adapter and simultaneously depress the Volume Down and Volume Up buttons on the FreeMic. Hold the Volume Up and Volume Down buttons on the FreeMic simultaneously for two seconds.

  • Page 20: Accessories

    Accessories FreeLinc continually releases new accessories for FreeMic products. Please refer to the FreeLinc website at www.freelinc.com to see the latest offerings. Tips and Suggestions To learn more about Near-Field Magnetic Induction Technology, please visit the technology area of the FreeLinc website at http://www.freelinc.com. Specifications Wireless Technology Near-Field Magnetic Induction...
  • Page 21 Notes:...
  • Page 22 Notes:...
  • Page 23 Notes:...
  • Page 24 ™ © 2005 Radeum Inc., DBA FreeLinc. All Rights Reserved. U.S. Patents Pending. The FreeLinc FreeMic 200 may not be authorized for use in some countries.
