Summary of Contents for Freelinc FMT100
- Page 1 ® FreeLinc ® FMT100 Headset User Guide...
-
Page 3: Table Of Contents
Table of Contents Introduction..... . 1 – Welcome and Product Overview FMT 100 Headset Diagram..3 Operating Concepts and Terms. -
Page 4: Introduction
Introduction Welcome Congratulations, and thank you for choosing FreeLinc products to enhance your two- way radio communications. The FreeLinc DualMuff Headset uses cutting-edge Near Field Magnetic Induction (NFMI) wireless technology. NFMI supports mobility, freedom-of-motion, exceptional battery life, audio integrity, ease of use, durability, secure communications and comfort. - Page 5 Introduction Product Overview The FreeLinc FMT100 Headset works within a small area surrounding the user. The size of the area is determined by the distance between your headset and the adapter. If your headset and adapter are close together, the area shrinks in diameter – just...
-
Page 6: Fmt 100 Headset Diagram
FM100 Headset Diagram Noise Canceling Michrophone On/Off Switch Status Indicator Light Charging Dock... - Page 7 FM100 Headset Diagram Volume Buttons Replaceable Ear Gels...
-
Page 8: Operating Concepts And Terms
Operating Concepts and Terms Adjusting the Ear Hooks... -
Page 9: Charging
Operating Concepts and Terms Charging... -
Page 10: Headset Tones
Operating Concepts and Terms Headset Alert Tones When the link between the FreeLinc FMT100 Headset and the adapter is broken, you will hear the following alert tones: TONE INDICATION Three double beeps Link is broken Continuous series Push-to-Talk button of beeps... - Page 11 Operating Concepts and Terms Pairing Before your headset can communicate with an adapter, it must establish a link. To establish a link, your headset and adapter must exchange a randomly generated software ID code, which is stored in each device. This process is called “pairing. ” Your headset and adapter remain paired until you initiate the manual pairing sequence with a different adapter (see Step Four: Pair Headset to Adapter under...
- Page 12 Operating Concepts and Terms Linking After entering Seek Mode and finding the adapter with which it is paired, your headset will establish a link, and communication can occur. This link will remain active until you turn off the adapter or radio, at which point the headset will return to Seek Mode.
-
Page 13: Getting Started
Using Your Headset for the First Time Step One: Attach Adapter Attach your FreeLinc adapter to the accessory interface of your portable radio (see your portable radio’s user manual if you need assistance locating the accessory interface). If your adapter has a mounting clip on top, use the clip and locking screw to secure the adapter to your radio. - Page 14 Status Indicator Light will flash green, indicating a successful pairing. CAUTION: When pairing, make sure that there are no other FreeLinc products within 6 feet of the devices being paired.
- Page 15 Getting Started Step Five: Establish Link (Automatic) Once you pair your headset to an adapter, the two devices establish a communication link. This occurs automatically after pairing, and the link persists as long as your headset remains within the communication area. If you move your headset outside the defined area, the link is lost and the unit returns to Seek Mode.
-
Page 16: Additional Information
Keep in mind that your headset can only be paired with one adapter at a time. CAUTION: When pairing, make sure that there are no other FreeLinc products within 6 feet of the devices being paired. -
Page 17: Specifications
Additional Information Specifications Near-Field Magnetic Wireless Technology Induction Battery Type LiPp 3.7v 2200mAh Up to 20 hours Battery Life talk time Range Up to 5 feet 1.25m Operating -20 C to +60 C Temperature -22 F to +140 F 95% @ 8 hours Humidity (non-condensing) Microphone... -
Page 18: Frequently Asked Questions
Additional Information Frequently Asked Questions What happens if I go out of range and lose the link between my headset and my adapter? When your headset is out of range of the adapter, the headset will beep and the indicator light on the adapter will blink red. - Page 19 Do I need to modify my radio in any way for my headset or adapter to work? No. The only requirement is that the FreeLinc adapter must fit on your radio model. For a complete list of the radio models FreeLinc supports, please refer to the FreeLinc website at www.freelinc.com.
- Page 20 Tips and Suggestions For up-to-date troubleshooting information, or to get help with a specific problem, or to contact a customer service representative, please visit www.freelinc.com, and click the “support” link or call 1-866-467-1199. Accessories FreeLinc continually releases new accessories for its products.
-
Page 21: Safety Information
Saftey Information Caution: To reduce the risk of fire or injury, please read and follow the instructions below. • Do not dispose of product in a fire; the battery cells may explode. Check with local codes for possible battery disposal instructions. •... - Page 22 Saftey Information • Do not stick anything inside the product as this may damage internal components. • This product conforms to the following safety standards: ANSI/UL 60950-1 1st Ed. CAN/CSA C22.2 No. 60950-1-03 EN 60950-1 1st Ed.
-
Page 23: Warranty And Fcc Compliance
(the “Warranty Period”). b. Rechargeable batteries will be replaced during the warranty period if the battery develops leakage. c. FreeLinc, at its option, will at no charge either repair, replace, or refund the purchase price for warranted Product during the warranty period provided it is returned in accordance with the terms of this warranty to the place of purchase. - Page 24 FreeLinc. FreeLinc assumes no obligations or liability for additions or modifications to this warranty unless made in writing and signed by an officer of FreeLinc. Unless made in a separate written agreement between FreeLinc and the original end user purchaser, FreeLinc does not warrant the installation, maintenance or service of warranted Product.
- Page 25 A product which, due to illegal or unauthorized alteration of the software/firmware in the Product, does not function in accordance with FreeLinc’s published specifications or the FCC type acceptance labeling in effect for the Product at the time the Product was purchased.
- Page 26 Purchaser shall return the nonconforming Product to the place of purchase freight prepaid. IV. Limitation of Liability: a. This warranty sets forth the full extent of FreeLinc’s responsibilities regarding the Product. Repair, replacement, or refund of the purchase price, at FreeLinc’s option, is the exclusive remedy.
- Page 27 Warranty and FCC Compliance c. FREELINC SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PRODUCT, EVEN IF FREELINC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. d. EXCEPT FOR CLAIMS FOR BODILY INJURY...
- Page 28 Warranty and FCC Compliance FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 29 Warranty and FCC Compliance reception, which can be determined by comparing the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •...
- Page 30 Protected by one or more of the following U.S. patents: 7.149.552, 7.254.366, 7.236.741, 7.215.924, 7.142.811, 7.035.608, 6.819.762, 6.459,882, 5.982.764, 5.912.925, 5.771.438 7.732.901, 7.565.187, 7.574.173 The FMT100 Headset may not be authorized for use in some countries. Engineered in USA Manufactured in USA Rev. 0809...
