Page 1: Room Air Conditioner
Room Air Conditioner OPERATING INSTRUCTIONS Indoor Outdoor CS-C75KR CU-C75KR Model Model CS-C95KR CU-C95KR CS-C125KR CU-C125KR Before using your air-conditioner, please ENGLISH ........ P. 1 – P . 28 read this operating instructions carefully and keep it for future reference. F563245... -
Page 2: Table Of Contents
CONTENTS FEATURES ............... 3 Before use SAFETY PRECAUTIONS ........... 4 – 6 Installation Precautions Operation Precautions NAME OF EACH PART ........... 7 – 10 Indoor Unit When the front panel is opened Outdoor Unit Accessories Remote Control When the remote control is opened How to use the remote control When the back cover is opened PREPARATION BEFORE OPERATION .... - Page 3 CARE AND MAINTENANCE ......... 19 – 22 If necessary Cleaning the Indoor Unit and Remote Control Cleaning the Air Filter Cleaning the Front Panel Removing the front panel Fixing the front panel Cleaning the front panel Replacing the Air Purifying Filters Removing the air purifying filters Reinstalling the air purifying filters Pre-season Inspection...
-
Page 4: Features
(Refer page 21) AUTO RESTART CONTROL Automatically restart the unit after power failure. (Refer page 25) Thank you for purchasing a Panasonic Room Air Conditioner. Note: Before using your air-conditioner, please read this operating instructions carefully and keep it... -
Page 5: Safety Precautions
SAFETY PRECAUTIONS Before operating, please read the following “Safety Precautions” carefully. To prevent personal injury, injury to others and property damage, the following instructions must be followed. Incorrect operation due to failure to follow instructions will cause harm or damage, the seriousness of which is classified as follows : Warning Caution... -
Page 6: Operation Precautions
Operation Precautions Do not insert plug to operate Warning the unit. Do not pull out plug to stop the unit. This sign warns of death or serious injury. Plug in properly. Do not share outlet. Do not operate with wet hands. - Page 7 Caution Switch off the power supply if the unit is not used for a long period. This sign warns of injury. Do not pull the cord to disconnect the plug. Switch off the power supply before cleaning it. Do not wash the unit with water. Do not use for other purpose such as preservation or etc.
-
Page 8: Name Of Each Part
NAME OF EACH PART Indoor Unit Front Panel Air Intake Vent Power Supply Cord Panel Opener Signal Receptor Horizontal Airflow Direction Air Outlet Vent Louver (Manually adjusted) Operation Indicators Vertical Airflow Direction Louver POWER : Green SLEEP : Orange TIMER : Orange Economy/Powerful Indicators Economy - Green... -
Page 9: Outdoor Unit
Outdoor Unit Air Intake Vents (Rear) Connecting cable Drain Hose (Side) Piping Air Outlet Vents Ground Terminal (Inside Cover) Accessories Remote Control Holder Remote Control Two RO3 (AAA) dry-cell batteries or equivalent Air Purifying Filters (Catechin Air Purifying Filters and Deodorizing Filters) -
Page 10: Remote Control
Remote Control Operation Display Signal Transmitter OFF/ON Button (self-illuminating Button) Room Temperature Setting Button (self-illuminating Button) Powerful Mode Operation Button When the remote control cover is opened Operation Display Operation Mode Selection Button Clock Button Fan Speed Selection Button Economy Mode Operation Manual Airflow Direction Button Selection Button... -
Page 11: How To Use The Remote Control
How to use the remote control Notes • Do not throw or drop • Do not get it wet • Certain type of flourescent lamps may affect signal reception. Consult your dealer. Signal receptor • Signal received sound. One short beep or one long beep. •... -
Page 12: Preparation Before Operation
PREPARATION BEFORE OPERATION Indoor Unit Warning Ensure the power plug is securely inserted. A loose plug may cause a fire or an electric shock. Connect the power supply cord to an independent power supply. Open the front panel Remove the air filters Insert the air purifying filters Insert the air filters Close the front panel... -
Page 13: Remote Control
Remote Control Inserting batteries OPEN Slide the cover to open Be sure the directions are correct • Open the remote control cover and confirm the display 12:00 PM is flashing. Set the current time (Clock) immediately to prevent battery exhaustion. Setting the clock Press the clock button flashes... -
Page 14: How To Operate
HOW TO OPERATE Automatic, Cooling, Soft Dry, Fan Press to select the desired operation mode Display When pressed, the display changes in this order. COOL Press to start the operation Close the Cover POWER indicator LED (Green) on indoor unit will light up. -
Page 15: Adjusting Airflow Direction And Fan Speed
Adjusting Airflow Direction And Fan Speed Press to select Fan speed • The display changes in this order Automatic Medium High Selecting Vertical Airflow Direction Press AUTO, • The louver swing up and down automatically. • To stop this operation, press MANUAL button. -
Page 16: Setting The Timer
SETTING THE TIMER Ensure that the current time is correct before setting the timer. The timer cannot be set if the time display is flashing. Press ON-TIMER Flashes Example: Set the ON-TIMER to 7:00AM Press to set the time Increase by 10 minutes Decrease by 10 minutes * Press continuously for quick setting. -
Page 17: Recommended Setting Of Timer
Recommended Setting of Timer When you sleep • Set the time at which you will go to sleep with the OFF-TIMER. This prevent wastage of electricity. When you wake up • Set the time at which you will wake up with the ON-TIMER. -
Page 18: Convenience Operation
CONVENIENCE OPERATION Sleep Mode This is to obtain a comfortable room temperature while sleeping. To set the sleep mode, press SLEEP. * The sleep indicator on the indoor unit will light up. To cancel the sleep mode, press once more. Operation details Approx. -
Page 19: Economy Or Powerful Mode
Economy or Powerful Mode Economy and Powerful operation cannot be selected simultaneously. Economy Mode To save electrical power consumption. However, please use this mode when the room have reached your desired temperature. • Press ECONOMY * Economy indicator (Green) on indoor unit lights up. -
Page 20: Care And Maintenance
CARE AND MAINTENANCE Cleaning the Indoor Unit and Remote Control • Wipe gently with a soft, dry cloth. • Do not clean with water hotter than 40°C or with Caution polishing fluids. • The front panel can be removed and cleaned with Switch OFF and unplug the power cord before water. -
Page 21: Cleaning The Front Panel
Cleaning the Front Panel (Must be removed before washing) Caution • Stand on a level surface when • Do not touch the metal parts in • Do not leave water on the removing the front panel. the indoor unit after removing panel after cleaning. -
Page 22: Replacing The Air Purifying Filters
Replacing the Air Purifying Filters (Once every 3 month) • If the air conditioner operates with dirty • Do not reuse dirty filters. Consult the nearest filters:- authorized dealer. Air is not purified (Air Purifying filter No. CZ-SFD50N) Cooling capacity decreases •... -
Page 23: Pre-Season Inspection
Pre-season Inspection • Is the discharge air cold? Operation is normal if 15 minutes after the start of operation, the difference between the air intake and outlet vents temperatures is 8°C or above for cooling. • Are the air intake or outlet vents of the indoor or outdoor units obstructed? •... -
Page 24: Troubleshooting
TROUBLESHOOTING Normal Operation - Is it okay? - This is the answer. - A sound like water flowing - Air conditioner has been restarted, but does not can be heard. operate for 3 minutes. - This is the sound of - This is to protect the air conditioner. -
Page 25: Abnormal Operation
Abnormal Operation Hmmm! The air conditioner does not operate. Air conditioner operation noise too loud. • Has a circuit breaker been tripped? • Is the installation work slanted? • Has the power plug been removed from • Is the front grille closed properly? the wall outlet? •... -
Page 26: Helpful Information
HELPFUL INFORMATION Auto Operation Button Automatic Operation • If the remote control fails to function or misplaced, press Auto Operation button for Automatic operation. • The Automatic operation will be activated immediately once the Auto operation button is pressed. However, temperature cannot be adjusted in this operation. -
Page 27: Energy Saving And Operation Hints
ENERGY SAVING AND OPERATION HINTS Air Filter and Air Purifying Filter Clean the air filter every 2 weeks and change the Air Purifying Filter every 3 months. Dirty filter may reduces Setting Temperature cooling efficiency. Set the temperature 1°C higher than actually desired. Keep All Doors and Windows Approximately 10% of Closed... - Page 28 Warning 1) If the supply cord is damaged or need to be replaced, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2) Remove power plug or disconnect from the mains before servicing this appliance. 3) Do not repair by yourself.
- Page 29 Note Please remember to record the following: Model Number Serial Number Dealer’s Name Date Purchased...
