Summary of Contents for TRUlink 29597
- Page 1 UIDE USB S IRELESS UPERBOOSTER XTENDER Model: 29597...
-
Page 2: Table Of Contents
ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements..........................4 Package Contents............................5 Device Overview Wireless USB Host Adapter.......................6 Wireless USB Device Adapter......................7 Software/Device Installation........................8 Using the Wireless USB Kit........................14 Frequently Asked Questions........................18 Technical Specifications..........................19 Cables To Go Warranty..........................20 Important Safety Information........................21 FCC Statement............................22... -
Page 3: Introduction
NTRODUCTION Thank you for purchasing the TruLink™ Wireless USB* Superbooster Extender. This product utilizes robust wireless technology, so you can connect an USB enabled device such as a printer, scanner, digital camera, or interactive whiteboard up to 150 feet away from your PC. With a highly reliable connection you can use this product in settings such as corporate offices, classrooms, or in your home office/entertainment system. -
Page 4: Features
EATURES Wireless connectivity up to 150 feet Reliable connection in the same room, in another room, or on another floor Easy setup, with software included Wireless specification: 2.4GHz, DSSS, internal antenna... -
Page 5: System Requirements
YSTEM EQUIREMENTS PC with available USB Port CD-ROM drive for driver installation Windows® XP or Vista® At least 5MB free drive space... -
Page 6: Package Contents
ACKAGE ONTENTS Wireless USB Host Adapter for your computer Wireless USB Device Adapter for USB device AC Power Adapter Quick Start Guide Driver CD User Manual... -
Page 7: Device Overview
EVICE VERVIEW USB H IRELESS DAPTER 1. Link: Data Connection Indicator • LED is on when transfer device is connected... -
Page 8: Wireless Usb Device Adapter
EVICE VERVIEW USB D IRELESS EVICE DAPTER 1. Reset Button • This allows the device to be put in its default setting 2. Infra LED Indicator • Not active on this device 3. Link LED Indicator • This is a status indicator that the device adapter is active 4. -
Page 9: Software/Device Installation
OFTWARE EVICE NSTALLATION IMPORTANT NOTE: • Please do not connect the USB PC Adapter into your computer’s USB port until the software prompts you to do so in the install process outlined below. • The screenshots in this user guide are specific to Windows XP Service Pack 3 (SP3). If you are not using Service Pack 3, the screens may slightly differ. - Page 10 OFTWARE EVICE NSTALLATION OFTWARE NSTALLATION Insert the CD supplied into the CD-ROM drive on your computer. The CD should automatically start and display a menu screen. Note: It the CD does not start automatically, click the Start button on the bottom left of your desktop screen, click Run, and type D:/Autorun.exe (“D”...
- Page 11 OFTWARE EVICE NSTALLATION Click Next. Do not change any of the address settings. If you change the address settings, you might not be able to connect. Click Install.
- Page 12 OFTWARE EVICE NSTALLATION Plug in your USB Host Adapter to an available USB port on your PC. Click Yes.
- Page 13 OFTWARE EVICE NSTALLATION Click Finish to exit the Installation Wizard. The USB Link utility will open, search, and find your USB Device Adapter. Your USB device that is connected to the Wireless USB Device Adapter will have its name displayed in the USB Link manager window.
- Page 14 OFTWARE EVICE NSTALLATION ERIFY ONNECTION To verify connection, upon installation of the software, you should see a new Wireless Network Connection (Figure: Wireless Network Connection Icon) that represents the Wireless USB Superbooster Extender in your Windows icon tray. You can float your mouse across the icon to view the status information or you can double click it to view the information (Figure: Wireless Network Connection Status).
-
Page 15: Using The Wireless Usb Kit
USB S SING THE IRELESS UPERBOOSTER XTENDER USB L The USB Link manager allows you to monitor the connection of your Wireless USB Device Adapter. Here you can see the current data transfer rate, and change settings of your Wireless USB Host Adapter or Device Adapter. - Page 16 USB S SING THE IRELESS UPERBOOSTER XTENDER USB L PTIONS Within the USB Link manager, you can adjust settings to personalize your configuration (Figure: USB Link- Options). Figure: USB Link-Options Choose Device Server If you have multiple Wireless USB Device Adapters connected, you can choose which Device Adapter you want to use in this window (Figure: Choose Device Server).
- Page 17 USB S SING THE IRELESS UPERBOOSTER XTENDER Configure Device Server You have the ability to change characteristics of your Device Adapter in the Configure Device Server window (Figure: Configure Device Server). SSID- Is the name that will appear for your Device Adapter. You may change this name by typing in a different name that is recognizable to you.
- Page 18 USB S SING THE IRELESS UPERBOOSTER XTENDER Configure Wireless PC Adapter In this window (Figure: Configure Wireless PC Adapter), you can configure your Wireless USB Host Adapter to settings that will work best for your application. SSID- Is the name that will appear for your Wireless USB Host Adapter.
-
Page 19: Frequently Asked Questions
REQUENTLY SKED UESTIONS What do I do if I get disconnected from my Wireless Device Adapter? If you get disconnected or can no longer connect to your device, you can right-click the USB Link icon in the Windows icon tray, select Choose Device Server from the Options, and highlight your USB Device Adapter. -
Page 20: Technical Specifications
ECHNICAL PECIFICATIONS Operating System Support Microsoft Windows XP/Vista Operating Range Up to 150 feet Frequency 2.4 GHz Number of Channel 11 channels Interface USB type A x 1, full speed Wireless Specification 2.4 GHz, DSSS, Internal Antenna Association Mode Pre-Association, Searchable Association Reset Switch Used to put unit in default settings Power Adapter... -
Page 21: Cables To Go Warranty
™ W ABLES ARRANTY TATEMENT At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device. -
Page 22: Important Safety Information
MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc. -
Page 23: Fcc Statement
FCC S TATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. - Page 25 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.6.25.09...
