- Page 1 UIDE UDIO OVER XTENDER Model: 39986(remote unit)
-
Page 2: Table Of Contents
ABLE OF ONTENTS Introduction..............................2 Features..............................3 System Requirements...........................4 Package Contents............................5 Device Overview............................6 Device Installation ............................7 Troubleshooting............................11 Technical Specifications..........................12 Cables To Go One Year Warranty......................13 Important Safety Information........................14... -
Page 3: Introduction
NTRODUCTION Thank you for purchasing the TruLink™ VGA w/Audio over Cat5 Extender Remote Unit. The Extender Remote Unit when paired with the Extender Base Unit is a robust solution that allows you to extend your VGA and audio signal up to 300 meters (1000 feet) over a Cat5E Unshielded Twisted Pair (UTP) cable. -
Page 4: Features
EATURES Extend your analog video and audio signals up to 300 meters (1000 feet) Cat5E UTP cabling enables easy and cost effective in-wall installation Supports the following resolutions using Cat5E* cabling: 100M 1280x1024 180M 1024x768 200M 800x600 300M 640x480... -
Page 5: System Requirements
YSTEM EQUIREMENTS Base Unit- Part #39984 or #39985 (sold separately) Cat5E UTP Cable HD15 and 3.5mm audio connection on computer HD15 and 3.5mm audio connection on each monitor, projector, or other display device HD 15 male to male cables for the computer and each display device connected and 3.5mm audio cables for each audio output source connected... -
Page 6: Package Contents
ACKAGE ONTENTS TruLink VGA w/Audio over Cat5 Extender Remote Unit DC 12V 600mA Power Adapter User Manual... -
Page 7: Device Overview
EVICE VERVIEW RJ45 HD15 Output 3.5mm Stereo Port to Monitor Audio Input Gain-Adjusts the brightness of the image Power Adapter Input EQ-Adjusts the picture signal strength... -
Page 8: Device Installation
EVICE NSTALLATION Note: Before installation, you will need to have a TruLink VGA w/Audio Extender Base Unit (1 or 4 port Model: #39984 or #39985 respectively), and a TruLink VGA w/Audio Extender Remote Unit (#39986). (each sold separately) Step 1... - Page 9 EVICE NSTALLATION Step 7 Connect the Extender Remote Unit HD15 female connector with a HD15 cable to your monitor. Step 8 Connect the Extender Remote Unit Audio Output connector with an audio cable to the monitor or audio receiver. Step 9 Connect the Extender Base and Remote Unit power adapters Step 10 Turn on your PC, monitors, and other equipment, and your installation is complete!
- Page 10 EVICE NSTALLATION Application Diagram 39984 39986 Cat5 cable Microphone...
- Page 11 EVICE NSTALLATION Application Diagram 39985 39986 Cat5 cable Microphone...
-
Page 12: Troubleshooting
ROUBLESHOOTING Problem Possible Solution No Operation Verify the 12V power supply is connected to the selector. Make sure all devices are powered on. No picture or signal; 1. Make sure your video display is properly set in PC mode. Poor picture. 2. -
Page 13: Technical Specifications
ECHNICAL PECIFICATIONS 39984 39985 Product Number 39986 HD-15 female x2 (1 In, 1 HD-15 female x2 (1 In, 1 VGA In/Out Out) Out) HD-15 female x1 Out Connector Audio In/Out 3.5mm Stereo Jack x1 3.5mm Stereo Jack x1 3.5mm Stereo Jack x1... -
Page 14: Cables To Go One Year Warranty
™ O ABLES ARRANTY At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device. -
Page 15: Important Safety Information
MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc. - Page 16 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.cablestogo.com . 1.0.4.9.09...
