CONTENTS
Contents ................................................................... 1
Introduction .............................................................. 3
About Oregon Scientific .......................................... 3
Product Overview .................................................... 4
LCD Screen ........................................................... 4
Front View .............................................................. 5
Back View .............................................................. 6
Remote Sensor (RTGR328N) ................................ 7
Getting Started ......................................................... 8
Batteries ................................................................. 8
AC Adapter (Main Unit) .......................................... 8
Wall Mount / Stand ................................................ 9
Change Settings .................................................... 9
Remote Sensor ....................................................... 10
Thermo / Hygro Sensor Setup (RTGR328N) ....... 10
Clock .................................................................... 11
Set Radio Signal Format ...................................... 11
Sensor Data Transmission .................................. 11
Sensor Search ..................................................... 12
Clock and Calendar ............................................... 12
Radio-Controlled Clock ........................................ 12
Turn Radio-Controlled Clock ON/OFF ................. 12
Set Clock ............................................................. 13
BAR321/323HGN English R3 R
Black
Alarms ..................................................................... 13
Set Daily Alarm .................................................... 13
Set Pre-Alarm ...................................................... 14
Activate Alarm ...................................................... 14
Snooze ................................................................ 15
Barometer ............................................................... 15
View Barometer Area ........................................... 15
Select Measurement Unit .................................... 15
View Barometer History ....................................... 16
Bar Chart Display ................................................. 16
Set Altitude ........................................................... 16
Weather Forecast ................................................... 16
Weather Forecast Icons ....................................... 16
UV Measurement (with optional UVR138) ............ 17
Temperature and Humidity .................................... 17
View Temperature and Humidity Area ................. 17
Select Measurement Unit .................................... 17
Select Sensor Channel ........................................ 18
Minimum / Maximum Records ............................. 18
Temperature and Humidity Trend ........................ 18
Comfort Zone ....................................................... 18
Audio Broadcast .................................................... 19
Activate Audio Broadcast ..................................... 19
and weather forecast ........................................... 19
1
1
3/27/04, 11:25 AM
Advertisement
Table of Contents
Related Manuals for Oregon Scientific BAR321HGN
Summary of Contents for Oregon Scientific BAR321HGN
-
Page 1: Table Of Contents
Set Daily Alarm ............ 13 Contents ..............1 Set Pre-Alarm ............14 Introduction .............. 3 Activate Alarm ............14 About Oregon Scientific .......... 3 Snooze ..............15 Product Overview ............ 4 Barometer ............... 15 LCD Screen ............4 View Barometer Area ........... 15 Front View .............. - Page 2 Set Broadcast Times ........... 19 Set Volume Level ..........20 Backlight ..............20 Reset System ............20 Safety and Care ............20 Warnings ..............20 Troubleshooting ............. 21 Specifications ............22 Main unit dimensions ........... 22 Remote unit dimensions ........22 Temperature ............
-
Page 3: Introduction
Thank you for selecting the Oregon Scientific™ Visit our website (www.oregonscientific.com) to learn BAR321HGN/BAR323HGN Talking Wireless Weather more about other Oregon Scientific products such as Station. This powerful device bundles time keeping, digital cameras, hand-held organizers, health and fitness weather monitoring, and audio broadcast features into gear, and projection clocks. -
Page 4: Product Overview
PRODUCT OVERVIEW LCD SCREEN Weather Forecast Area: Animated weather forecast Clock / Alarm / Calendar Area: Radio controlled clock; alarms; calendar; battery status Temperature / Humidity / Comfort Zone Area: Readings and trend lines; comfort zone; sensor channel number; sensor battery status UVI / Barometer Area: UV level and barometric pressure bar chart;... -
Page 5: Front View
FRONT VIEW SNOOZE / LIGHT – activate 8-minute snooze or backlight LCD Display SELECT – switch Areas MODE – change settings / display UP – increase setting / activate radio-controlled clock and audio broadcast DOWN – decrease setting / deactivate radio- controlled clock and audio broadcast ALARM / -- view alarm status;... -
Page 6: Back View
BACK VIEW Speakers Slot for wall mount / stand Battery compartment (bottom) °C / °F button (in battery compartment) mb / inHg button (in battery compartment) RESET button (in battery compartment) GETTING STARTED NOTE Refer to the Battery section ( 8) for more information about the battery compartment. -
Page 7: Remote Sensor (Rtgr328N)
REMOTE SENSOR ( RTGR328N ) LCD display LED Status indicator Ventilation duct Wall mount Channel switch (1 – 5) Signal reception RESET Channel number °C / °F Low battery icon Search Time EU / UK radio signal format switch Temp (°C or °F) Battery compartment Humidity % Fold-out stand... -
Page 8: Getting Started
AC ADAPTER ( MAIN UNIT ) GETTING STARTED The AC power adapter socket is located inside the BATTERIES battery compartment of the main unit. Batteries are for Insert batteries before first use, matching the polarity as back-up purposes only; adapter is required for Audio shown in the battery compartment. -
Page 9: Wall Mount / Stand
WALL MOUNT / STAND CHANGE SETTINGS To attach the wall mount or stand, slide the insertion rod Press SELECT to switch between Areas. indicates into the slot on the back of the main unit. the selected Area. Wall Mount Most Areas have alternate display options (for example, Clock / Alarm or Barometer / UVI ) . -
Page 10: Remote Sensor
Press RESET. Then set the temperature unit. REMOTE SENSOR This product is shipped with the RTGR328N Thermo/ SWITCH OPTION Hygro Sensor and an optional UVR138 Ultraviolet Sun °C / °F Temp Ray Sensor (BAR323HGN only). The main unit can collect data from up to 6 sensors (5 Thermo/Hygro Sensors and 1 UV Sensor). -
Page 11: Clock
For best results: SET RADIO SIGNAL FORMAT • Insert the batteries and select the unit, channel, The RADIO SIGNAL FORMAT switch is located inside and radio signal format before you mount the the battery compartment. Select EU (DCF) or UK (MSF). Then, press RESET. -
Page 12: Sensor Search
RADIO-CONTROLLED CLOCK SENSOR SEARCH The time and date are automatically updated by radio- To search for a Thermo / Hygro sensor, press SELECT controlled clock signals from official time-keeping to navigate to the Temperature/ Humidity / Comfort Zone organizations in Frankfurt (Germany) and Rugby Area. -
Page 13: Set Clock
The house icon NOTE The language options are (E) English, indicates that the (F) French, (D) German, (I) Italian, and (S) Spanish. The radio-controlled language you select determines the weekday display and the spoken language for the Audio Broadcast. clock is ON. No icon means that it NOTE Audio Broadcast must be activated (... -
Page 14: Set Pre-Alarm
Press UP or DOWN to select 15, 30, 45 or 60 minutes. The beep alarm icon or talking alarm icon This is the amount of time the Pre-Alarm will sound will flash. Press UP or DOWN to confirm the BEFORE the Daily Alarm. The Pre-Alarm is alarm mode. -
Page 15: Snooze
VIEW BAROMETER AREA ICON DESCRIPTION Press SELECT to navigate to the Barometer Area. Daily Talking Alarm is activated and will is NOT shown, press MODE. broadcast the current Barometric data is shown in 2 areas at the bottom of the time at the set time. -
Page 16: View Barometer History
Press UP or DOWN to set the altitude in 10-meter VIEW BAROMETER HISTORY increments (-100m to 2500m). Navigate to the Barometer Area, then press HISTORY Press HISTORY to confirm. repeatedly to scroll through the measurements. The number shown in the HR box indicates how long ago each measurement was taken (e.g., 2 hours ago, 3 hours WEATHER FORECAST ago, etc.). -
Page 17: Uv Measurement (With Optional Uvr138)
ICON DESCRIPTION TEMPERATURE AND HUMIDITY RAINY The weather station can display the following information from any of the 5 remote sensors: SNOWY • Current, minimum, and maximum temperatures and relative humidity percentages. NOTE The nighttime icon displays from 6 PM to 6 AM. •... -
Page 18: Select Sensor Channel
SELECT SENSOR CHANNEL TREND RISING STEADY FALLING Press CHANNEL to switch between sensors 1 - 5. ICON The house icon shows the selected remote sensor. COMFORT ZONE To auto-scan between sensors, press and hold The Comfort Zone indicates how comfortable the climate CHANNEL for 2 seconds. -
Page 19: Audio Broadcast
BROADCAST CURRENT TIME, TEMPERATURE, AUDIO BROADCAST HUMIDITY AND WEATHER FORECAST This product can broadcast the current time, indoor Press SNOOZE / LIGHT for 2 seconds. Audio Broadcast temperature, humidity level and weather forecast. When must be activated for the feature to work. activated, the product can tell you this information on the hour for a specified period of time (such as 6 –... -
Page 20: Set Volume Level
OPTION DESCRIPTION RESET SYSTEM 1 Hour The Broadcast will sound once hourly The RESET button is located at the bottom of the unit. between the specified times. For Press RESET when you change the batteries and example, if you selected 6 PM as the whenever performance is not behaving as expected (for start time, and 8 PM as the end time, example, unable to establish radio frequency link with... -
Page 21: Troubleshooting
• Do not mix new and old batteries or batteries of Problem Symptom Remedy different types. Cannot auto- 1. Adjust batteries. • Do not use rechargeable batteries with this synch product. 2. Press RESET • Remove the batteries if storing this product for a long period of time. -
Page 22: Specifications
RELATIVE HUMIDITY SPECIFICATIONS Range 25% to 95% Resolution MAIN UNIT DIMENSIONS Comfort 40% to 70% L x W x H 87 x 209 x 45 mm (3.43 x 8.23 x 1.77 inches) Memory Min / max Weight 314 grams (0.69 lbs) with Trend +/- 3% battery... -
Page 23: Radio Controlled Clock
RADIO CONTROLLED CLOCK Synchronization Auto or disabled Clock display HH:MM:SS Hour format 12hr AM/PM (MSF format) 24hr (DCF format) Calendar DD/MM or MM/DD; weekday in 5 languages (E, G, F, I, S) Alarm Daily & Pre-Alarm; 2- minute crescendo Snooze 8 minutes POWER Main unit... -
Page 24: Ec Declaration Of Conformity
EC Representative of Manufacturer (Article 3.2 of the R&TTE Directive) Applied Standards EN 300 220-3: (2000) COUNTRIES RTTE APPROVAL COMPLIED All EC countries, Switzerland And Norway © 2004 Oregon Scientific. All rights reserved. BAR321/323HGN English R3 R 3/27/04, 11:26 AM Black...
