7. Install the drive into the bay until it snaps into position.
8. Continue at "Connecting drives."

Connecting drives

The steps to connect a drive are different depending on the type of drive. Use one
of the following procedures for your drive connection.

Connecting the first optical drive

1. The drive requires two cables; a power cable that connects to the power supply
2. Locate the three-connector signal cable that comes with your computer or with
3. Locate the PATA IDE connector on the system board. See "Identifying parts on
4. Connect one end of the signal cable to the drive and the other to the PATA IDE
5. Locate the extra four-wire power connector labelled P4 and connect it to the
Connecting an additional optical drive, or parallel ATA hard
disk drive
1. Locate the extra connector on the three-connector signal cable that is attached
2. Connect the extra connector in the signal cable to the new drive.
20
User Guide
and a signal cable that connects to the system board.
the new drive.
the system board" on page 11.
connector on the system board. To reduce electronic noise, use the connectors at
the end of the cable only.
drive.
to the PATA IDE connector on the system board. See "Identifying parts on the
system board" on page 11.
