Installing the Enclosure in a Rack

4. Slide the front end of the right rack rail toward the inside front of the rack until

the locking latch engages with the marked hole in the front rack upright.

5. Extend the back end of the rail toward the inside rear of the rack until the locking

latch engages with the marked hole in the rear rack upright.

3-4

HP StorageWorks Modular Smart Array 20 User Guide
