- Page 1 Owner’s Manual ULTRA-POWER II ACCU-POWER & ACCU-POWER ONBOARD Solid State Fully Automatic Chargers Manual Number 1017361 Edition Code 0493B0101A...
-
Page 2: General Information
GENERAL INFORMATION ∆ WARNING • Only trained technicians should repair or service the charger. Consult your nearest Club Car distributor/dealer. • Do not use the charger near water. • Always wear safety glasses or eye protection when servicing the vehicle or charger. - Page 3 • Do not operate the charger if it has received a sharp blow, was dropped or otherwise damaged in any way. Contact your nearest Club Car Distributor/dealer. • Ventilation openings must not be blocked or covered and must have at least two inches of clearance.
-
Page 4: Light Display
Light Display The Ultra-Power II features a range indicator that consists of three red lights and a manual stop button. This feature gives an indication of the vehicle's expected range as well as providing a diagnostic tool. -
Page 5: Range Indicator
Develop your own guidelines for the brand of batteries you are using. For best battery life, Club Car recommends that electric vehicles not be used for more than 36 holes before recharging to avoid deep cycling of the batteries. Charging between rounds will also extend battery life. -
Page 6: Diagnostic Tool
It should be noted that Figure 1, Page 5 is to be used as a guideline only. Results may vary due to terrain and playing conditions. The results are also based on batteries that are well maintained and in good working con- dition. See the section on Batteries in your vehicle's Owner's Manual or contact your local Club Car Distribu- tor/Dealer. -
Page 7: Troubleshooting Guide
If the warning tag has been removed from the DC cord, have it replaced. A Club Car vehicle supplied with an onboard charger is also equipped with a DC receptacle connected to the batteries. This allows for charging the batteries with a stationary charger in an emergency. If a stationary charger is used, refer to and follow the warnings and instructions provided for that type of charger. -
Page 8: Charger Does Not Turn On
AC power. If AC power is present and still no transformer hum can be heard, the charger is malfunctioning. If the relay clicks on and the transformer hums, but no charge rate is indicated on Accu-Power models, or the CHARGER ON light doesn't light up on Ultra-Power II models, the charger is mal- functioning. -
Page 9: Ac Line Fuse Or Circuit Breaker Blows
23 amps within 30 minutes. This may also result if a 36 volt battery system is wired incorrectly or if the battery polarity markings are reversed. Have a qualified service technician check the wiring of the batteries and the charger receptacle. Ultra-Power II, Accu-Power, and Accu-Power Onboard Battery Chargers Page 9... - Page 10 The limited warranty with respect to parts and labor only covers defects in material and workmanship for a period of three years from the date of purchase. Such repair labor shall be performed only by CLUB CAR or by an authorized distributor or dealer.
- Page 11 Ultra-Power II, Accu-Power, and Accu-Power Onboard Battery Chargers...
- Page 12 P.O. Box 204658 Augusta, Georgia 30917-4658 USA Telephone: 1-800-ClubCar (258-2227) www.clubcar.com...
