Summary of Contents for Laser Groove Mate V10
- Page 1 www.LaserCo.net...
-
Page 2: Table Of Contents
Index___________ Precautions·········································································································································3 Characteristics····································································································································5 About the Player ································································································································6 Basic Operation··································································································································7 Funtions ·············································································································································9 Music ·············································································································································9 Video············································································································································10 FM Tuner ··································································································································· 11 Photo Browser······························································································································12 Text ············································································································································13 Voice Recording ···························································································································14 Navigation····································································································································15 Game Function·····························································································································15 Setting ··········································································································································15 USB Disk ·········································································································································16 Convert Video File ···························································································································18 Upgrade Player Firmware ···············································································································20 Troubleshooting ·······························································································································22 Specifications···································································································································23 www.LaserCo.net... -
Page 3: Precautions
Precautions This manual contains important safe and correct operational information. Please read all the information carefully before you use the device in order to avoid any unexpected accidents and faults. Do not put the player in the condition of high temperature, humidity or dust. - Page 4 B. Further power on the player when the system is powered off automatically, but it powers off soon. C. No response with the pressing keys. Laser reserves the right for the improvement of the product. It is subject to any change on the specifications and designs without further notice!
-
Page 5: Characteristics
Characteristics 2-inch real colored TFT display Multi music formats as MP3, WMA, and real audio frequency display MPEG-4 video format play, full-screen play display, exterior-sound speaker play High-definition JPEG picture browse function FM Tuner function, can store 20 stations at the most Digital recording Energy-saving setting, brightness adjustable, customised power off time Support 3D EQ surrounding effect, customised EQ... -
Page 6: About The Player
About the Player www.LaserCo.net... -
Page 7: Basic Operation
Basic Operation Power On/Off Power On: Push the power switch to ON position, long press key for 3 seconds, the player will display the boot interface, then main menu. Power Off: Long press for 3 seconds to power off. The system will power off automatically if the battery is not enough. Push the power switch to OFF position Power Reset If your player is frozen, you can push [ON/OFF] power switch to restart the player. - Page 8 Volume Control • When playing music, press the “VOL” until the red speaker icon is flashed at the corner of the right side in the screen, then press to adjust the volume. • When playing video, press the “VOL” until the red speaker icon is flashed at the corner of the left side in the screen, then press to adjust the volume Main Menu...
-
Page 9: Funtions
Music In Music Play menu, connect the earphone with player, double press “M” key to see the play list, select the desired music file by pushing leftwards or rightwards key, then short press “M” key to begin the playing, short press key to pause and resume. -
Page 10: Video
Lyric Display The player only supports the Lyric Synchronous Display that the file shares the same name as LRC file of MP3 format, e.g., music file is named as “Angel.mp3”, the LRC file must be named as “Angel.Irc”, what’s more, they have to be in the same directory. Video In video play menu, select the video file by press key, then short press “M”... -
Page 11: Fm Tuner
FM Radio Short press “M” key to enter FM menu, short press key to highlight: manual, auto, memories, preset, delete, short press “M” to confirm the chosen function press to change the frequent manually, long press “M” to exit. • Auto: Press “M”... -
Page 12: Photo Browser
FM recording : When you listen the FM music, long press “VOL” key to enter FM record mode, short press key to record and pause selecting, short press “M” key to save the music as file and long press “M” key to exit FM record mode. -
Page 13: Text
Text • Download TXT File Connect the player to PC, select the desired file to download and save the file as TXT format. • Read File In main menu, press “M” enter Text option, press key to select the file, then short press “M”... -
Page 14: Voice Recording
Voice Recoding In main menu, press “M” to enter record mode, short press key to start recording and pause recording, short press “M” key to save the recorded file. Long press “M” key to exit the recording mode. www.LaserCo.net... -
Page 15: Navigation
Navigation Navigation function let you see the list of all files in player. Short press “M” to play the music (or video, or photo, or recorded file), long press “M” to return to main menu Game Built-in Game- Russian Diamond In main menu, enter Game mode by short press “M”... -
Page 16: Usb Disk
USB Disk USB Display Mode The player has a high-speed USB2.0 port with the transmission speed of 5M/S, and is a standard USB disk, supports the systems including Windows98 (it needs to install the driver), over Windows2K (it’s unnecessary to install the driver), Mac OS 10.3 and over, Linux Redhat 8.0 and over. - Page 17 hours). www.LaserCo.net...
-
Page 18: Convert Video File
Convert Video File This player can convert the AVI, VOB, DAT, RMVB or RM into AVI video format via the attached video convert software. 1) Click and run the program of “AV Converter.exe”, shown as follows: 2) Click "add ", show dialog as follows: www.LaserCo.net... - Page 19 3) Select and set your desired parameters, select your desired video/audio file and AVI video file routine to be generated, click [Start to Convert] button, then begin to convert to AVI file. The successfully converted AVI video file can be played in MP4 player. After converting to AVI files, enter Video Play menu, select the corresponding file, short press “M”...
-
Page 20: Upgrade Player Firmware
Upgrade Player Firmware The player can upgrade or resume the damaged player firmware via the tool software in the attached disk. 1) For the first upgrading of computer, insert the drive disk into the CD-ROM of computer, then connect the MP4 player with computer (it requires you to press and hold the key), till it appears the program Installation Interface. - Page 21 5) Connect the player to PC via USB cable (press and hold the key before the On-line operation), then click [Burnt Firmware] till the Auto Upgrading is achieved. Note: Firmware upgrade is to improve and optimize the performance of the player. The normal work of the player would not be affected even if the firmware isn’t upgraded.
-
Page 22: Troubleshooting
Troubleshooting If the player can not be played normally, please check as follows: Troubles Solutions Check whether the player is powered on or not and whether the machine It cannot be turned on program is damaged or not The player is blocked Push the power switch to restart the player Check whether the machine is powered on or not Confirm the volume is not in “0”... -
Page 23: Specifications
Product Specifications Items Specifications LCD display real colored TFT display, Diagram ( 220*176 ) Language support Multiple languages Data transmission speed High speed USB2.0 (about 4M Byte/s) Supportable file format Music: MP3, WMA; Record: WAV; Picture: JPEG Supportable video format AVI, RM, VOB, DAT, RMVB (All should be converted) 85dB Max.
