Laser MP4-L50 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
User's Manual
Model : MP4-L50

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP4-L50 and is the answer not in the manual?

Questions and answers

Related Manuals for Laser MP4-L50

Summary of Contents for Laser MP4-L50

  • Page 1 User’s Manual Model : MP4-L50...

  • Page 2: Table Of Contents

    Contents Features…………………………………………………………………………………………………… Precautions ……………………………………………………………………………………………… Warning……………………………………………………………………………………………………. Button & Function…………………………………………………………………………………….. Main Menu………………………………………………………………………………………………. Music Mode ……………………………………………………………………………………………… Video Mode ……………………………………………………………………………………………… Record Mode ……………………………………………………………………………………………. Voice Mode ………………………………………………………………………………………………. FM Radio Mode ………………………………………………………………………………………… Picture Mode ……………………………………………………………………………………………. System Setting ………………………………………………………………………………………….. Text Mode …………..…………………………………………………………………………………… Video Conversion Tool ………………………………………………………………………………. Trouble Shooting ………………………………………………………………………………………...

  • Page 3: Warning

    Features 1.8-inch TFT display • 128 x 160 pixels display resolution • Plays AVI (128x160), AMV video format files • Plays MP3, WMA, WAV audio format files • Picture browsing for JPEG format files • • Built in Micro-SD card slot, supports up to 8GB Built-in 300mAh Li-poly battery •...
  • Page 4 Button & Controls Micro SD card slot ON/OFF power switch VOL+ VOL- Enter –short press, Exit – long press Last/ Backward Next/Forward Play/Pause 、 H old 3 second to power ON/ OFF L50 Hand strap Hole 10. Earphone socket 11. Mini USB socket Basic Operation Power On/Power off Push [ON/OFF] button to On...

  • Page 5: Main Menu

    To charge t or disconnect L50 from PC, use the Safely Remove Device function on your computer Main menu Hold [M] button to enter main menu. Press [PRE] or [NEXT] to switch the modes. Music Select “Music” in the main menu Press [M] button to confirm selection and then press PLAY/STOP [>II] button to play the song.
  • Page 6 While music playing, press [M] button to enter sub-menu: All Songs Display all the songs Album list Display the album Artists Display the singer of the song Genre Display the genre of the song Create Playlist Create the playlist Repeat Normal, Repeat one;...

  • Page 7: Record Mode

    Movie Select “Movie” in the main menu Press [M] button to confirm selection and then press PLAY/STOP [>II] button to play the video. While playing video. press [M] button to enter sub-menu. All the operation is same as Music. Video Conversion Please see section for how to load/convert video files to L50 Record Mode...
  • Page 8 Voice Press [PRE] or [NEXT]to select the Voice mode, then press [M] to confirm the selection, press [>II] to play the recording file. Press [>II] button to pause playback, swing [PRE] or [NEXT] button to select recording files. Sub-menu while playing status: Repeat Replay mode Exit...
  • Page 9 Save Save currently tuned frequency; Record Record current preset channel; Delete delete current preset channel; Delete All delete all saved channels; Auto Search Auto search FM channel Normal Band Frequencies from 87.5MHz---108MHz; Exit exit from FM sub-menu Auto search: Holding [PRE] button or [NEXT] button for two seconds will tune frequency upward or downward until a radio station is located then it stop automatically.
  • Page 10 Delete All Delete all pictures Exit Exit from sub-menu Press [>II] (play/stop) button to display the picture automatically or manually according to previous playing setting. Note: maximum resolution for jpg files picture is 1280 x1024, might need to lower resolution jpg files if L50 displaying “...

  • Page 11: Trouble Shooting

    TEXT Select [PRE] or [NEXT] button to select Text, then press [M] to confirm, Enter TEXT mode by pressing Mode button, then you can read and edit the article in the device. The device only can recognize the article in “txt.” file format. Press [M] button again to enter sub-menu: local folder choose the folder where picture is saved;...
  • Page 12 Check to make sure that your L50 is connected to a USB port on Not charging your computer. Check if you have enough space on your to download the music file. Unable to download music. Check to make sure that the USB cable is connected to the PC and to the Digital Media Player.
