EnGenius EOC5611P Quick Start Manual

Quick Start Guide >>
EOC5611P is a long range outdoor wireless Access Point / Client Bridge
that operates in both 5GHz and 2.4GHz frequency. It provides high
bandwidth up to 54Mbps and features dual polarization antenna with
high transmitted output power as well as superior sensitivity.
EOC5611P extends radio coverage, avoids unnecessary roaming
between Access Points and ensures a stable wireless connection while
reduces the number of required equipments.
EOC5611P provides user friendly interface including user friendly
distance control ranges from 1KM up to 30KM and RSSI LED indicator
offering real time signal status. It comes with PoE injector for
convenient outdoor installation.
EOC5611P enforces transmission security with full support of latest
encryption mechanism including 64/128/152-bit WEP, WPA and WPA2.
With 13dBi internal antenna and superior performance, EOC5611P
makes an optimal wireless solution for both small and large scale
projects.
IP Address Configuration
The default IP address of the device is
192.168.1.1. In order to log into this device, you
must first configure the TCP/IP settings of your
PC/Notebook.
1. In the control panel, double click Network
Connections and then double click on the
connection of your Network Interface Card
(NIC). You will then see the following
screen.
2. Select Internet Protocol (TCP/IP) and then
click on the Properties button. This will
allow you to configure the TCP/IP settings
of your PC/Notebook.
3. Select Use the following IP Address radio
button and then enter the IP address
(192.168.1.21) and
(255.255.255.0). Ensure that the IP address
and subnet mask are on the same subnet as
the device.
4. Click on the OK button to close this window,
and once again to close LAN properties
window.
Logging In
1.
2.
subnet mask
Administration
1.
To configure the device through the
web-browser, enter the IP address of the
Bridge (default: 192.168.1.1) into the
address bar of the web-browser and
press Enter.
After connecting to the IP address, the
web-browser will display the login page.
Specify admin as the default User Name
and Password, and then click on the Login
button.
Click on the Administration link under the
Management section. This option allows
you to create a new user name and
password for the device. For security it is
highly recommended for security reasons.
