- Page 1 MEGAPOWER User’s Manual ML130 DLP PICO PROJECTOR DLP PICO PROJECTOR...
-
Page 2: Table Of Contents
Chapter 4 – Care and Maintenance -----------------------------11-12 Cleaning the Pico Projector Housing -------- 11 Cleaning the Projection Lens --------------- 12 Transporting the Pico Projector ------------ 12 Chapter 5 – Troubleshooting Guide ------------------------------ 12 Appendix 1 – Product Specifications for ML130 DLP Pico Projector ----------------------------------------------------------------- 13... - Page 3 Note: 1. The appliance inlet power supply disconnector from mains and must be anytime easily accessible. 2. The maximum noise level of the product is L ≤70dB (A) DIN 45635-19-01-KL2. 1. Der Gerätestecker Netzteiles bildet Trennvorrichtung Versorgungsstromkreis muß jederzeit leicht zugänglich sein. 2.
- Page 4 4. Fasten cables using mounting screws to ensure adequate electromagnetic interference controls. Acknowledgments The followings are registered trademark or trademarks of their respective corporations: IBM, Microsoft, TI, Apple etc.
-
Page 5: Chapter 1 - Introduction
Chapter 1 Introduction About Your DLP Pico Projector The DLP Pico Projector is a convenient, versatile, state-of- the-art presentation system. It is an effective and valuable tool for projecting computer-generated video information or full motion video signals onto a front or rear projection screen. -
Page 6: Power Adaptor
Power Source Check the power specification plate on the back of the Pico Projector. Ensure that your line voltage matches with the power adapter rating of the Pico Projector. The Power Adaptor accepts AC power 100-240V, 50-60 Hz. Power Adaptor Use only the power adaptor supplied with the Pico Projector. -
Page 7: System Contents
6. If Pico Projector exhibits distinct change performance. System Contents Handle your DLP Pico Projector carefully as you remove it from the packing box. The following items should be included in your package:- 1. DLP Pico Projector 2. AC Power Adaptor 3. -
Page 8: Chapter 2 - Installation
8. Tripod and 7. Rechargeable Audio plug adapter Battery Chapter 2 Installation Left & Right Click Buttons Mouse Pad LED Indicator Focus Adjust Knob Projector Lens... -
Page 9: Setting Up
Volume Button Source Button On/Off Power Button Micro SD Card connector Setting Up Slide the battery door open & plug the battery connector to the Pico projector, as indicated by the following sequence photos. battery compartment designed accommodate different batteries, and as sizes can vary EVA foam is used to hold the battery in place. -
Page 10: Connector Panel
will be projected. 5. Place the Projector at a suitable distance so the image size is around 20” to 40” diagonal 6. Turn the Focus Knob to bring the image into focus. 7. Navigate the Mouse Cursor with the built-in Mouse Touch Pad to operate the projector using the internal Windows CE system. -
Page 11: Connecting To Power Adaptor
Connecting to Power Adaptor When adapter is plugged into the unit the battery starts to charge. The battery can also be charged via the device USB port (only when the unit is in the off state) Presentation with Window CE 1. -
Page 12: Connecting To External Sources
micro SD card(current build require photos to reside in the PHOTO folder NAND micro card)will displayed. (d) For music, open MUSIC PLAYER. Displays music files in NAND or micro SD card (current build require music files to reside in the MUSIC folder of the NAND or micro SD card) MY DEVICE/NAND/MUSIC MY DEVICE/STORAGE CARD/MUSIC * Please note : For permanent storage of files/folders in the... -
Page 13: Connecting To Micro Sd Card
corresponding outputs of the video source. Select the CVBS option MODE SELECT window. projected image should be same as output from the video source. (c) AUDIO OUT : Connect a self-powered Audio Speaker to the AUDIO OUT port to enjoy louder sound output. The sound volume can be adjusted on the WIN CE screen or via the VOLUME CONTROL BUTTON. -
Page 14: Connecting To Usb Host Port
2.7 Connecting to USB Host Port 1. Connect USB Flash Drives or self-powered Hard Disk to expand the memory of the Pico Projector. The Pico Projector will automatically detect these external memory devices and the icon can be found by opening MY DEVICE folder on the desktop. -
Page 15: Control Buttons
Chapter 3 Using the DLP Pico Projector Control Buttons following describes control buttons Pico Projector On/Off Switch Slide the On/Off switch and hold for approx 1 second or when the red light appears then release to turn on the Pico Projector. Slide the On/Off switch in the same way to turn off the Projector. -
Page 16: Led Indicators
input signal. Vol. Press the “Vol.” button to control the volume of Pico Projector. volume will first increase and when it reaches the maximum volume, the sound volume will start to decrease. Focus Knob To adjust the image focus. Mouse Pad To control the mouse function under Window CE. -
Page 17: Chapter 4 - Care And Maintenance
Red + blue power adapter plugged in, battery charging and purple) Projector switched on Green battery fully charged (it is advisable to disconnect the adapter when battery is fully charged) Infra-red receiver remote control (Option used with DVB-T adapter TBA) Antenna connection (Option for DVB-T version TBA) Chapter 4 Care and Maintenance... - Page 18 The DLP Pico Projector is a highly sophisticated piece of electronic equipment that is sensitive to impact, excessive heat, cold and humidity. When transporting the Pico Projector, use a protective bag or use the original packing carton to minimize shock and impact. Store and transport the Pico Projector at temperature between 0 and 140 degrees Fahrenheit (-17 to 60 degrees Centigrade).
-
Page 19: Chapter 5 - Troubleshooting Guide
Chapter 5 Troubleshooting Guide If you are having problems operating the Pico Projector, first make sure you have set it up according to the instructions in Chapter 3. You should also check the adjustments and the INPUT connections. Verify that all power is switched on. Before calling for service, check the troubleshooting suggestions in this chapter. -
Page 20: Pico Projector
Appendix 1 Product Specifications ML130 Pico Projector Product Specification Display Technology DLP Technology Light Source LED RGB Resolution WVGA (854 x 480 pixels) Brightness 50 Lumens (Typical) Contrast Ratio 1000 : 1 Built in Window CE capable of playing pdf, powerpoint,...
