Page 1: Washing Machine
40000622.qxd 13/09/2003 18:50 Page 1 ® Washing machine Instructions for use SE 160E... -
Page 2: Table Of Contents
40000622.qxd 13/09/2003 18:50 Page 2 Contents Page Introduction General delivery notes Safety notes Quick start Installation & testing Useful advice for the user Description of controls Detergent drawer Detergents, washing aids and amounts to use Programme selector The main wash Consumption data Programme Table Cleaning and routine maintenance... -
Page 3: Introduction
40000622.qxd 13/09/2003 18:50 Page 3 Introduction Please read and follow these instructions carefully and operate the machine accordingly.This booklet provides important guidelines for safe use, installation, maintenance and some useful advice for best results when using your machine. Keep all documentation in a safe place for future reference or for any future owners. -
Page 4: General Delivery Notes
A) Disconnect the plug from the mains supply. B) Turn off the water supply. C) Hoover equips all its appliances with earthing. Ensure that the mains power supply is earthed, if not, seek assistance from a qualified electrician. D) Do not touch the appliance when hands or feet are wet or damp. Do not use the appliance with bare feet. -
Page 5: Quick Start
40000622.qxd 13/09/2003 18:50 Page 5 K) When moving the appliance never lift it by the controls, the detergent drawer, the hoses or the power cable. To avoid damaging the door when moving the appliance never rest the door against objects e.g a trolley. L) IMPORTANT! If the appliance is installed on a carpeted floor ensure that the ventilation through the base of the appliance is not obstructed. -
Page 6: Installation & Testing
40000622.qxd 13/09/2003 18:50 Page 6 Installation & testing Remove the machine from the packaging - close to where it will finally be positioned - and proceed as follows: On the back of the machine 1) Remove the central screw A and side screws B and pull out the transit bracket C along with the red locator. - Page 7 40000622.qxd 13/09/2003 18:50 Page 7 Note: we recommend you keep the transit bracket and screws to protect the machine for future transit. The Manufacturers will not be responsible for any damage to the machine caused by not following the instructions relating to releasing the transit protection. The user is responsible for all installation costs.
-
Page 8: Water Supply Requirements
40000622.qxd 13/09/2003 18:51 Page 8 If you have no hot water supply or your hot Cold Water Supply water pressure is low: A cold fill adapter , allowing the installation of the machine with a cold water supply only can be purchased from Gias Service (Tel. -
Page 9: Testing The Installation
40000622.qxd 13/09/2003 18:51 Page 9 Testing the installation Refer to the programme guide for details of how to select programmes. 1. Turn on the water supply and check for leaks from fill hoses. 2. Switch on the electricity supply. 3. Select a spin programme and then press the START/PAUSE button to start the machine. - Page 10 Blue – NEUTRAL Brown – LIVE Green and Yellow – EARTH If the mains cord on this appliance is damaged, it must be replaced by a special cord which is only obtainable from the Hoover spares service, GIAS (01204 556111).
-
Page 11: Useful Advice For The User
ARIEL - Chosen and recommended by Hoover When we produce a new washing machine we subject it to every test possible. And one of the most important tests is the one that enables our experts to identify the most suitable detergent for solving laundry problems. -
Page 12: Description Of Controls
40000622.qxd 13/09/2003 18:51 Page 12 Description of Controls All the controls on your product’s control panel are listed as follows. The button function is selected when the button neon is lit. Carefully read the relevant descriptions detailed below: START/PAUSE START After selecting the programme press the START/PAUSE button once to start the machine. -
Page 13: Spin Speed Selector
40000622.qxd 13/09/2003 18:51 Page 13 Time Saver Button This option can be utilised on cottons and synthetics. By selecting the Time Saver option, the wash time may be reduced by up to 50 minutes, depending on the selected programme, temperature and load, without giving up a good wash quality. Creaseguard This option is available on cottons, synthetics, delicates and the Handwash special programme. -
Page 14: Detergent Drawer
40000622.qxd 13/09/2003 18:51 Page 14 Programme Time Remaining Indicator In order to better manage your time, this washing machine features an indicator light system that keeps you constantly informed on the remaining cycle time. Indicator light Start: Remaining time above 60 minutes Indicator light 60: Remaining time less than 60 minutes Indicator light 30: Remaining time less than 30 minutes Indicator light 15: Remaining time less than 15 minutes... -
Page 15: Detergents, Washing Aids And Amounts To Use
40000622.qxd 13/09/2003 18:51 Page 15 Detergents, washing aids and amounts to Choice of detergent General purpose detergents – Powder detergents, for a thorough wash, with bleaching agents, are particularly suitable for use in hot wash programmes (60°C and over), for heavily soiled and stained laundry. - Page 16 40000622.qxd 13/09/2003 18:51 Page 16 Before pouring in the detergent check that there are no foreign bodies in the detergent drawer. Dosage details are usually shown on the detergent packaging. Follow those instructions! Dosages Only use detergents which are suitable for use in a washing machine. You will obtain the best results from your wash with the minimum use of chemical products and the best care for your laundry if you take into consideration the degree of soiling as well as the type of detergent to choose.
-
Page 17: Programme Selector
40000622.qxd 13/09/2003 18:51 Page 17 Programme selector The washing machine has different programme groups according to type of wash, temperature, spin speeds and duration for handling the various types of fabric and their level of soiling (see wash programme guide). 1. -
Page 18: The Main Wash
This programme starts with a cold prewash that breaks down and loosens any excess dirt and then washes at a cool 30°C, rinses twice (one is for fabric conditioner) and spins slowly for the best care of your heavily soiled, delicate garments. Hoover has given sports items their own wash care programme. -
Page 19: Main Wash
40000622.qxd 13/09/2003 18:51 Page 19 Main wash Auto half load The washing machine is fitted with a self adjusting water level system. This system enables the machine to use the optimum amount of water needed to wash and rinse the laundry in relation to the particular load. This results in a reduction of the water and electricity used without in any way compromising the washing and rinsing performance. - Page 20 40000622.qxd 13/09/2003 18:51 Page 20 – Woollen items must be labelled with the “Pure New Wool” symbol if they are to be washed in the machine, and must also be labelled “non-matting” or “machine washable”. Please check the laundry item for the label. –...
-
Page 21: Selecting The Wash Programme
40000622.qxd 13/09/2003 18:51 Page 21 The correct way to wash Preparing the laundry A) Select and sort the laundry according to the wash care labels found on each garment. Always check the care labels. Loading the laundry B) Open the door. C) Put the laundry in the washing machine. -
Page 22: Consumption Data
40000622.qxd 13/09/2003 18:51 Page 22 Water and electricity consumption and approximate length of programmes selected Programme Water Electricity Duration consumption consumption in mins* in litres Whites normal 90°C, full load plus pre wash option Coloureds fast 60°C, full load 1.04 Coloureds non-fast 40°C, 3.0 kg load Mixed fabrics 60°C;... -
Page 23: Programme Table
40000622.qxd 13/09/2003 18:51 Page 23 Programme guide PROGRAMME FABRIC TYPE PROGRAMME FOR LOAD WATER DETERGENT TEMP °C Whites Colourfast fabrics Intensive - heavily 90° Cotton, linen, hemp soiled Whites & Cotton, colourfast Normal soiling 60° * * * Prewash mixed fibres Coloureds Cotton, mixed fabrics Normal-Light soiling... - Page 24 40000622.qxd 13/09/2003 18:51 Page 24 Programme guide PROGRAMME FABRIC TYPE PROGRAMME FOR LOAD WATER DETERGENT TEMP °C Special AA Cottons, Energy saving 40° 40°C Mixed fabrics at 40°C Daily fast Cottons, Lightly soiled 40° 44” Mixed fabrics Daily fast Cottons, Lightly soiled 40°...
-
Page 25: Cleaning And Routine Maintenance
40000622.qxd 13/09/2003 18:51 Page 25 Cleaning and routine maintenance Do not use alcohol-based scourers and /or thinners on the outside of your washing machine, just a wipe with a damp cloth will suffice. The washing machine needs very little maintenance: –... - Page 26 40000622.qxd 13/09/2003 18:51 Page 26 Cleaning the door glass Regularly clean the door glass with a damp cloth. A build up of soiling and residues from the water may result in water leaking from the door. Do not use abrasive cleaners as they can scratch the surface. Transporting or storing the appliance for long periods when appliance is not in use...
-
Page 27: Trouble Shooting
40000622.qxd 13/09/2003 18:51 Page 27 Trouble shooting What might be the cause of... Defects you can remedy yourself Before calling GIAS Service for technical advice please run through the following checklist. A charge will be made if the machine is found to be working or has been installed incorrectly or used incorrectly. - Page 28 40000622.qxd 13/09/2003 18:51 Page 28 It is unlikely that water will be visible in the drum! This is due to the latest technology that achieves the same standard of washing and rinsing but with far less water consumption. Note: The use of environmentally-friendly, phosphate-free detergents (check detergent information on pack) can have the following effects: –...
-
Page 29: Power Failure
40000622.qxd 13/09/2003 18:51 Page 29 Power failure If there is a power failure the wash cycle will be interrupted, the wash programme and functions will be suspended. When the power is restored, the wash programme and functions will re-start from the same point and complete the programme. -
Page 30: Technical Data
40000622.qxd 13/09/2003 18:51 Page 30 Technical data • Max. load of dry laundry 5.5kg • Water pressure (0.5-8 bar) 0.05-0.8 MPa • Spin speed 1600 rpm Measurements • Width 50cm • Depth 54cm • Height 85cm NB: For specifications regarding electrical data, see the data plate on the front of the washing machine (door area). -
Page 31: Customer Service
Your Guarantee Hoover guarantees all parts of this product for 5 years from the date of purchase. During that time Hoover will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear such as belts. - Page 32 Hoover Spares Service Tel: 01204 556111 Hoovercare To maintain your Hoover product in peak condition you may wish to take out a Hoovercare policy, which for an annual payment provides a comprehensive maintenance and repair scheme. For more information please call 08705 400 600.
