Summary of Contents for JVC GZ-HD5 AA
- Page 1 GUIDEBOOK HD HARD DISK CAMCORDER GZ-HD5 AA/AG/AH GZ-HD6 AA/AG/AH Dear Customers Thank you for purchasing this hard disk camera. Before use, please read the safety information and precautions contained on pages 4 and 5 to ensure safe use of this product.
- Page 2 Record in High-Definition! Select the mode which suits your purpose. • To record in full high-definition • To record in higher quality video • To record a longer time • 1440 CBR If you want to copy and edit the video as high- definition images by i.LINK output 8 To change the settings See page 66.
- Page 3 Back Up High-Definition Images on DVD Discs! Video can easily be backed up on a DVD disc by connecting to a separate DVD burner (CU-VD40). • This DVD disc can then be played in the camera or a PC, but not in a DVD player.
-
Page 4: Safety Precautions
• Do not disassemble and do not dispose of in fire. Contact your JVC dealer. Do not attempt to repair the malfunction yourself. • To prevent shock, do not open the cabinet. No... - Page 5 Do not point the lens directly into the sun. This Remember that this camera is intended for can cause eye injuries, as well as lead to the private consumer use only. malfunctioning of internal circuitry. There is also a Any commercial use without proper permission risk of fire or electric shock.
-
Page 6: Jvc Software Licence Agreement
BY THE PROGRAM, YOU SHOULD SETTLE owned by JVC and its licensor, and remain ALL SUCH PROBLEM AT YOUR OWN COST vested in JVC and such licensor. The Program is AND EXPENSE. protected under the copyright law of Japan and other countries, and related Conventions. - Page 7 CAUTION: without giving any notice to You. In this event, • Operate this equipment according to the JVC may claim against You for any damages operating procedures described in this manual. caused by Your breach. Should this Agreement • Use only the provided CD-ROM. Never use any be terminated, You must immediately destroy the other CD-ROM to run this software.
-
Page 8: Table Of Contents
Contents GETTING STARTED PLAYBACK Accessories .......... 10 Playing Back Files ........ 29 Attaching/Detaching the Lens Hood .... 10 Video Playback ........... 29 Attaching the Shoulder Strap ....... 11 Still Image Playback ........30 Preparing the Remote Control ..... 11 File Search Function ........31 Attaching the Core Filter to the USB Cable To Play Back TPD Files ....... -
Page 9: Read This First
System Requirements ......... 52 recorded data to a DVD or other recording Software Installation ........53 media for storage. (Z p. 46) JVC will not be Connecting the Camera to the PC ....55 responsible for any lost data. File Backup on the PC ......... 56... -
Page 10: Getting Started
GETTING STARTED Accessories AC Adapter Power Cord Battery Pack Component Cable AP-V14E BN-VF815U (Z p. 35) Audio/Video Cable USB Cable Shoulder Strap GZ-HD6 (Z p. 36, 50) (Z p. 46, 55, 62) Lens Hood (Z p. 11) Already attached to the camera. -
Page 11: Attaching The Shoulder Strap
Attaching the Shoulder Strap Peel off the pad and thread Thread the strap through the Position the buckle near the end of the strap through buckle, adjust its length, and use the eyelet and reattach the eyelet. the strap guide to fix it in place. the pad. -
Page 12: Index
Index NOTES • The LCD monitor can rotate 270°. • Power-linked operation You can also turn the camera on/off by opening/closing the LCD monitor. • Be careful not to cover sensors 5, < and = during shooting. - Page 13 6 Grip Strap (Z p. 18) Camera 7 USB (Universal Serial Bus) Connector [ (Z p. 46, 55, 62) ! Index Button [INDEX] (Z p. 31)/ 8 HDMI Connector [HDMI] (Z p. 35) Remaining Space Button/ 9 Component Connector [COMPONENT] Data Battery Button [ 0 / 1 ] (Z p.
-
Page 14: Indications On Lcd Monitor
Indications on LCD Monitor During both Video and Still Image During Video Recording Only Recording [ 4 h 5 9 m ] 0 : 0 4 : 0 1 200X F5.6 FOCUS 1/4000 ! Mode Indicator (Z p. 20) 1 6 : 5 5 2 0 . - Page 15 During Video Playback During Still Image Playback X - 6 0 1080p 1 0 1 - 0 0 9 8 1080p 1 : 5 5 : 0 1 1 6 : 5 5 1 6 : 5 5 2 0 . 0 1 . 2 0 0 8 2 0 .
-
Page 16: Necessary Settings Before Use
Necessary Settings before Use Be sure to configure the following 3 settings Required charging/recording time (approx.) before use. Recording Battery pack Charging time time Charging the Battery Pack GZ-HD5 BN-VF815U 1 hr. 25 min. 2 hr. 40 min. (Provided) GZ-HD6 Set the power/mode switch to OFF. -
Page 17: Language Setting
Date/Time Setting Language Setting After performing steps 1-3 (Z left column) The language on the display can be changed. Select [CLOCK ADJUST]. Set the power/mode switch to ON. Select Select the menu mode. Set the date and time. Select CLOCK ADJUST MENU DATE TIME... -
Page 18: Other Settings
Other Settings When Using a microSD Card Grip Adjustment If you want to record to a microSD card, the Open the pad and make grip adjustments. following 3 operations need to be performed. • Operations are certified on the following microSD cards. - Page 19 Q Insert a microSD card R Change the recording medium Preparation: The camera is programmed to record on the Set the power/mode switch to OFF built-in hard disk when it is shipped from the factory. You can change the recording medium to microSD card.
-
Page 20: Recording Files
RECORDING Recording Files Video Recording Preparation: Set the power/mode switch to ON. Slide the power/mode switch to Press the PLAY/REC button to MODE to select (video) mode. select the recording mode. SELECT The switch returns to MODE PLAY/REC the original position when it is released. -
Page 21: Still Image Recording
Still Image Recording Preparation: Set the power/mode switch to ON. Slide the power/mode switch to Press the PLAY/REC button to MODE to select (still image) select the recording mode. mode. SELECT PLAY/REC The switch returns to MODE the original position when it is released. -
Page 22: Zooming
Recording Files (Continued) Select the event that you want to Zooming register the file to. Preparation: To cancel the event registration, select • Select mode. [NON SECTION]. • Select the recording mode. Select VACATION 1/ 3 Zoom out Zoom in NON SECTION NEXT PAGE SELECT... -
Page 23: Checking The Remaining Space On The Recording Media
Checking the Remaining Space on the Checking the Remaining Battery Recording Media – mode only Power Preparation: Preparation: • • Set the power/mode switch to OFF. Select mode. • • Attach the battery pack. Select the recording mode. BATTERY CONDITION MAX RECORDING TIME 100% 5h00m... -
Page 24: Manual Recording
Manual Recording Manual recording mode enables you to set Program AE the focus and screen brightness etc. manually. You can record videos or still images with optimum brightness by adjusting the exposure To Change to Manual Recording and shutter speed to suit your surroundings or Mode the subject. -
Page 25: Manual Focus
Manual Focus Nightscope In the manual recording mode; Nightscope enables recording with more sensitivity in dim locations, by adjusting the shutter speed automatically. In the manual recording mode; Adjust the focus. 8 To cancel Nightscope Nightscope Move the set lever to £ (NIGHT) so that the J A N . -
Page 26: Spot Exposure Control
Manual Recording (Continued) Spot Exposure Control Manual Setting in Function Menu Use this function when backlight You can use manual recording functions compensation does not work well, or to adjust easily by selecting items in the function the brightness in the desired spot. menus. - Page 27 Menus Settings: [ ] = Factory-preset mode [AUTO]: The brightness is adjusted automatically. –6 to +6: Corrects the brightness within this range in increments of 1. Move the set lever to ¡ / ¢ to set the value. mode [±0]: The brightness is not adjusted. ADJUST BRIGHTNESS –2.0 to +2.0 (EV): Corrects the brightness within this range in Adjusts the brightness.
- Page 28 Manual Recording (Continued) Menus Settings: [ ] = Factory-preset [OFF]: No effect is used. SEPIA: The image has a brownish tint like old photos. MONOTONE: The image becomes black and white like old EFFECT movies. Enables you to record videos or still images with CLASSIC FILM*: This effect skips frames to give images of an special effects.
-
Page 29: Playback
PLAYBACK Playing Back Files Video Playback Select the playback mode. Select (video) mode. MODE The switch returns to SELECT VIDEO PLAY/REC the original position when it is released. SELECT SORT lamp on the camera lights up. The index screen appears. (The lens cover closes automatically.) Select the desired file. -
Page 30: Still Image Playback
Playing Back Files (Continued) Still Image Playback Select (still image) mode. Select the playback mode. MODE The switch returns SELECT IMAGE PLAY/REC to the original position when it is released. SELECT SORT lamp on the camera lights up. The index screen appears. (The lens cover closes automatically.) Select the desired file. -
Page 31: File Search Function
Event Screen – mode only File Search Function You can search the desired file by the event You can switch the index screen to the that you registered the file to when recording. date index screen or event screen for the (Z p. -
Page 32: To Play Back Tpd Files
Playing Back Files (Continued) To Play Back TPD Files Playback with Special Effects – mode only Playback effects TPD files (demonstration files, etc.) are stored in the EXTMOV folder. Add effects that, for example, alter the colour If you copy videos recorded on this camera tones of images. - Page 33 8 Items for EFFECT setting • SEPIA: The image is given a brownish tint like an old photo. • MONOTONE: The image becomes black and white like an old movie. • CLASSIC FILM*: The image is given an old movie atmosphere by the effect of skipping frames.
- Page 34 Playing Back Files (Continued) Wipe or fader effects – ! mode only 8 Items for WIPE/FADER setting • FADER-WHITE: Add effects at the beginning and end of Fades in or out with a white screen. videos. These effects cannot be set for still images.
-
Page 35: Watching Images On Tv
Watching Images on TV This camera is designed to be used with 8 To connect using the COMPONENT connector high-definition or PAL-type colour television signals. It cannot be used with a television of a different standard. To AC Outlet AC Adapter Connection with TV You can output videos from the HDMI COMPONENT... -
Page 36: Playback Operation
Watching Images on TV (Continued) 8 To connect using the AV connector Playback Operation To AC Outlet After the connection with TV is AC Adapter completed DC Connector Turn on the camera and the TV. Set the TV to its VIDEO mode. (Only when connecting the camera to the VCR/DVD recorder) Turn on the VCR/DVD recorder, and... -
Page 37: Editing/Printing
EDITING/PRINTING Managing Files CAUTION Select [EXECUTE]. Do not remove the recording medium or Select perform any other operation (such as turning DELETE? off the power) while accessing files. Also, REMAINING FILES: 0008 be sure to use the provided AC adapter, as EXECUTE CANCEL the data on the recording medium may be... - Page 38 Managing Files (Continued) Deleting/Protecting Files Deleting/Protecting All Files After performing steps 1-2 (Z p. 37) After performing steps 1-2 (Z p. 37) Select [FILE SELECT]. Select [DELETE ALL] or [PROTECT ALL]. Select DELETE Select CURRENT DELETE FILE SELECT DELETE ALL CURRENT FILE SELECT DELETE ALL...
-
Page 39: Viewing File Information
Histogram – mode only Viewing File Information File Information A histogram is a graph indicating the image’s Preparation: brightness. • mode: Pause the playback. By checking the image and its histogram, you Otherwise, select the file on the index can see the exposure level pattern and the screen. -
Page 40: Changing The Event Registration Of Video Files After Recording
Managing Files (Continued) 8 To cancel the event registration Changing the Event Registration of Select [DELETE AND QUIT]. Video Files after Recording – mode only To Extract a Still Image File from a Preparation: Video File – mode only • Select mode. -
Page 41: Dpof Print Setting
Select the number of prints (max. DPOF Print Setting – # mode only 15 prints). The number of prints to make of a still image Select recorded on a microSD card can be set. This feature is useful when taking the microSD card to a photo lab for printing. - Page 42 Managing Files (Continued) Setting All Files Together (One Print for Each) FUNCTION Select [DPOF]. Select DELETE PROTECT COPY MOVE EFFECT DPOF Select [ALL1]. Select DPOF SELECT IMAGES ALL 1 CHECK SETTINGS RESET SELECT QUIT Select [EXECUTE]. Select ALL1 EXECUTE CANCEL SELECT 8 To exit the screen Press the FUNCTION button.
-
Page 43: Playlists
Playlists – ! mode only It is a list that enables you to organise Select the file to add to playlist. recorded videos in order of preference. Select EDIT Preparation: TOTAL • 00h00m Select mode. • Select the playback mode. SELECT REGISTER •... -
Page 44: Playing Back Playlists
Playlists – ! mode only (Continued) Playing Back Playlists NOTES • A maximum of 99 playlists can be created. • Each playlist can consist of a maximum of 99 scenes. • If you delete the original files, the corresponding files are also deleted from the playlist. -
Page 45: Other Operations Of Playlists
Deleting Playlist Other Operations of Playlists Original files are not deleted even if you You can perform additional editing and delete delete the playlist. files in a created playlist. Preparation: Select [DELETE]. Perform steps 1-2. (Z p. 43) Select a playlist you want to delete. Adding/Deleting Files in Playlist To delete all playlists at once, select [DELETE ALL]. -
Page 46: Copying
COPYING Copying Files Types of Copying and Connectable Device Using a DVD Burner to Copy Files from the Camera The Camera You can copy still images The files in the camera can be backed up to a between the HDD and DVD disc using a DVD burner. - Page 47 Backup All Files Select [EXECUTE] or [EXECUTE AND FINALIZE]. Preparation: By selecting [EXECUTE AND FINALIZE], • Connect the camera to the DVD burner. the disc is finalised after the files are • Select mode. copied. The following illustrations of display Select screens are examples of when backing up DVD(DL)
- Page 48 Copying Files (Continued) Select Files for Backup Select [ALL]. CREATE BY EVENT Preparation: • Connect the camera to the DVD burner. • 01.01.2007 12:04 Select mode. 01.01.2007 12:15 01.02.2007 12:04 01.02.2007 12:15 SELECT SORT The following illustrations of display screens are examples of when backing up Select the desired menu.
-
Page 49: Using A Vcr/Dvd Recorder To Dub Files From The Camera
NOTES of copying the file, not of the actual recording. • Be sure to use the optional JVC VC- VDV206U or VC-VDV204U i.LINK cable depending on the connector type (4 or Using a VCR/DVD Recorder to Dub 6 pins) of the VCR/DVD recorder. - Page 50 Copying Files (Continued) 8 To connect using the AV connectors Start playback on the camera. • (analog dubbing) To play back videos • To play back playlists To AC Outlet 1) Press the FUNCTION button. 2) Select [DUBBING PLAYBACK]. AC Adapter 3) Move the set lever to ¤.
-
Page 51: Copying/Moving Still Image Files
Set the file unit ([ALL] or [FILE]) to Copying/Moving Still Image Files copy/move. You can copy or move still image files between the HDD and microSD card. Preparation: • Select mode. • • [FILE]: Select the playback mode. • Select this to transfer the selected files. Make sure that microSD card is inserted in 1) Select the desired file. -
Page 52: Pc Operation
PC OPERATION File Backup on a Windows ® Install the software that came with the camera For the compatible drives: to your PC. http://jp.cyberlink.com/english/products/ You can back up your files on your PC with a powerproducer/4/comp_dvd_drive.jsp simple one-touch operation, edit your files on For the compatible BD drives: your PC, and also create discs. -
Page 53: Software Installation
Digital Photo Navigator 1.5 Software Installation Allows you to change the format of still image The following software is included in the CD- files backed up on your PC. ROM that came with your camera. You can find the latest information on the CyberLink BD Solution provided software program at CyberLink’s world wide web server at http://www2.cli. - Page 54 File Backup on a Windows ® (Continued) Select the desired language and click When installation is completed [OK]. The installed software is displayed in [All Programs] – [CyberLink BD Solution]. Click [Yes]. The software installation starts. The backup destination folder [MyWorks] for files is created on the hard disk drive that has the most free space.
-
Page 55: Connecting The Camera To The Pc
8 When you have finished operation Connecting the Camera to the PC Always follow the procedures below when disconnecting the camera, or turning off the Preparation: camera/PC power. Set the camera’s power/mode switch to OFF. Failing to do so may cause damage to the camera and PC. -
Page 56: File Backup On The Pc
File Backup on a Windows ® (Continued) File Backup from the specified media File Backup on the PC Preparation: This method uses the software on the CD- • Install the software. ROM to back up files onto your PC. • Connect the camera to the PC. -
Page 57: File Backup On The Pc Without Using Software
Select the folder that you want to File Backup on the PC without Using back up, and drag & drop it into the Software folder you created in step 1. • Preparation: SD_VIDEO: Folder that contains video files. If you Connect the camera to the PC with the USB cable. -
Page 58: Other Windows ® Pc Operations
Other Windows PC Operations ® Click the media that contains desired Playing Back Files on the PC files. Preparation: • Install the software. • Connect the camera to the PC. Set the camera’s power/mode switch to ON. On the camera, select [PLAYBACK ON PC]. -
Page 59: Creating Discs/Editing Files
Click the check box of the desired Creating Discs/Editing Files file. The s mark appears in the check box. Preparation: • To select other files, repeat this step. Install the software. • Connect the camera to the PC. Set the camera’s power/mode switch to ON. -
Page 60: Getting More Use Of The Software
Other Windows PC Operations ® (Continued) NOTES Digital Photo Navigator 1.5 • You can use following discs: The User’s Guide is included on the CD-ROM - BD-RE, BD-R - DVD-R/DVD+R (Unused discs) in PDF format. - DVD-RW/DVD+RW (They need to be formatted before recording. -
Page 61: File Backup On A Macintosh
File Backup on a Macintosh If the software on the provided CD-ROM is Click [Continue]. installed, the backed up file can be viewed in QuickTime Player or edited in iMovie HD or Final Cut Pro. (Several functions will not be accessible.) You can find the latest information on the provided software program at our world wide... -
Page 62: Connecting The Camera To The Macintosh
File Backup on a Macintosh (Continued) 8 When you have finished operation Connecting the Camera to the Always follow the procedures below when Macintosh disconnecting the camera, or turning off the camera/computer power. Preparation: Failing to do so may cause damage to the Set the camera’s power/mode switch to OFF. -
Page 63: File Backup On The Macintosh
Select the folder that you want to File Backup on the Macintosh back up, and drag & drop it into the folder you created in step 1. Preparation: • Connect the camera to the computer with the SD_VIDEO: USB cable. (Z p. 64) Folder that contains video files. -
Page 64: Folder Structure And Extensions
Folder Structure and Extensions X = number Recording medium Contains the still image folders. [DCIM] [XXXJVCSO] [PIC_XXXX.JPG] Still image file [PIC_XXXX.JPG] [XXXJVCSO] [XXXJVCSO] [SD_VIDEO] Contains the video file folders. Management information* for the media as a [MGR_INFO] whole [PRGXXX] Management information* [PRGXXX.PGI] Video file [MOVXXX.TOD]... -
Page 65: Customer Support Information
Contact us for information on the provided software Use of this software is authorized according to the terms of the software licence. When contacting the nearest JVC office or agency in your country (refer to the JVC Worldwide Service Network at http://www.jvc-victor.co.jp/english/worldmap/index-e.html) about this software, please have the following information ready. -
Page 66: Further Information
FURTHER INFORMATION Changing the Menu Settings Select the menu mode. Select the desired second menu item. For details on each menu, see below. Select GENERAL MENU DISPLAY DISPLAY ON TV LANGUAGE CLOCK ADJUST Select the desired first menu item. DATE DISPLAY STYLE SELECT QUIT ! : VIDEO... - Page 67 Menus Settings: [ ] = Factory-preset [10X] / 40X / 200X ZOOM ZOOM NOTE Sets the maximum zoom ratio. Optical zoom is used up to 10X. Digital zoom is used from more than 10X up to the selected zoom ratio. OFF: Disables the function.
- Page 68 Changing the Menu Settings (Continued) Menus Settings: [ ] = Factory-preset [OFF]: Disables the function. ON: Activates the function. BRACKETING: Activates the bracket shooting function. In addition to an image with the exposure set by the camera, two other images are recorded with exposure values shifted to the +0.3 EV and 0.3 EV –...
- Page 69 Menus Settings: [ ] = Factory-preset BRIGHT BRIGHT Adjust the brightness of the display by moving the set Sets the brightness of the LCD lever to £ / ¤, then press down. monitor. BRIGHTER / STANDARD / [AUTO] MONITOR BACKLIGHT NOTE Enables you to adjust the When you select [AUTO], the brightness will automatically...
- Page 70 Changing the Menu Settings (Continued) Menus Settings: [ ] = Factory-preset VIDEO OUTPUT Set the aspect (16:9/4:3) to [16:9] / 4:3 the screen of the connected television when outputting videos from the AV connector. COMPONENT OUTPUT [576i]: Outputs at 576i. Sets the definition of the video output from the COMPONENT 1080i: Outputs at 1080i.
- Page 71 Menus Settings: [ ] = Factory-preset Connect the AC adapter. EXECUTE: Performs this function. Select [OK] when CLEAN-UP HDD Writing speed to HDD tends to completed. become slow after long periods [CANCEL]: Cancels this function. of repeated use. Execute cleanup NOTE periodically to regain the writing speed.
-
Page 72: Troubleshooting
If the problem is not solved, reset the functioning properly. camera. (Z p. 76) • If the problem persists, please consult your The following phenomena are not nearest JVC dealer. malfunctions. • The camera heats up when it is used for a long time. •... - Page 73 Trouble Action • The recorded subject Set the backlight compensation to [OFF] if it is being used. • is too bright. Set the brightness to the [–] side. • Cannot use spot Keep the zoom ratio below 10X. exposure control. •...
- Page 74 • or whitish. The LCD monitor may be reaching the end of its service life. Consult your nearest JVC dealer or the JVC customer service. • The LCD monitor is The LCD monitor may be difficult to see if used in bright areas such as under direct sunlight.
- Page 75 Trouble Action • The following functions cannot be used for a backup DVD. [When playing back video] - Special playback (forward slow motion, reverse slow motion, frame-by-frame forward, frame-by-frame back) Some functions - Saving still images from video playback cannot be used when - Search index by date playing back a backup - Playback effects...
- Page 76 $ If this does not solve the problem, perform the disc check function from a PC after formatting. % If this does not solve the problem, contact the JVC customer service for repairs. 8 To reset the camera ! Set the power/mode switch to OFF and remove the power supply (battery pack or AC adapter) from the camera, then reattach it.
-
Page 77: Warning Indications
Warning Indications Indication Meaning/Action • Erase files. Move onto media such as a computer. HARD DISK DRIVE IS FULL • Erase files. Move onto media such as a computer. Replace MEMORY CARD IS FULL with a new microSD card. • COMMUNICATING ERROR Detach the battery pack once and re-attach it firmly. - Page 78 RECOVER? • Set the video media in the video menu to [HDD]. • CANNOT USE IN VIDEO Replace the microSD card. (Cards that have been recorded on using anything other than JVC high-definition hard disk movies MODE cannot be used.)
-
Page 79: Cleaning
Cleaning Before cleaning, turn off the camera and remove the battery pack and AC adapter. 8 To clean the exterior Wipe gently with a soft cloth. If the camera is particularly dirty, dip the cloth into diluted mild soap and wring it out well. After wiping with the wet cloth, wipe again with a dry cloth. 8 To clean the LCD monitor Wipe gently with a soft cloth. -
Page 80: Specifications
Specifications 8 For still image Camera Format JPEG 8 For general Image size Power supply 4 modes: 1920 x 1080 DC 11 V (Using AC adapter) 1440 x 1080 DC 7.2 V (Using battery pack) 1024 x 768 Power consumption 640 x 480 Approx. - Page 81 Dimensions (W x H x D) Remote Control 42 mm x 14.5 mm x 91 mm Weight Power supply Approx. 30 g DC 3 V (incl. battery) Battery life Approx. 1 year Design and specifications subject to change (depending on the frequency of use) without notice.
-
Page 82: Cautions
Cautions Battery Packs Recording Medium • Be sure to follow the guidelines below The supplied battery pack is Terminals to prevent corruption or damage to your a lithium-ion battery. Before recorded data. using the supplied battery • Do not bend or drop the recording medium, or pack or an optional battery subject it to strong pressure, jolts or vibrations. - Page 83 • To prevent the unit from dropping, Main Unit • Attach the shoulder strap securely and fasten the grip belt securely. • • When using the camera with a tripod, attach the For safety, DO NOT camera to the tripod securely..
-
Page 84: Terms
Terms AC Adapter ............16 Macintosh ............61 Adjust Brightness ..........27 Manual Recording ........... 24 Aperture Priority ..........27 Menu Settings ..........66 AV Connection ........36, 50, 70 microSD Card ..........18 Monitor Backlight ..........69 Backlight Compensation ........25 Battery Pack ........
